Electrical Installation
3.6.10 Allocation of Connector Pins
The position of the connector pins for sensors, transmitters, serial communication, etc. is shown in Illustration 3.19.
NOTE
All connections are seen from the cable side
4
3
4
3
2
1
2
1
EEV_2
EXT_FAN
1 Ground
1 Ground
2 + (RS485)
2 0-10V
3 - (RS485)
3 PWM
4 +24V
4 not used
Illustration 3.19 Allocation of Connector Pins
®
VLT
Inverter Scroll CDS 801 Operating Instructions
2
2
2
1
1
1
S_AMBIENT, S_AUX, S_D
P_O
1 PT1000
1 Ground
2 PT1000
2 Signal
3 +5V
4 not used
®
MG10V402 - VLT
is a registered Danfoss trademark
4
3
4
3
2
1
2
1
P_C
1 Ground
2 Signal
3 +5V
4 not used
3
2
1
RLY_1
1 NC
2 COM
3 NO
21
3
3
