MOUNTING THE DEVICE
Chapter 7 – Mounting the Device
Mounting the Device
The device ships with a mounting bracket.
You will need
Mounting bracket
MTCAP2
Four #6 screws, with anchors (not provided)
Screwdriver
Drill
Determining Location
Follow these guidelines for best performance:
For optimal performance, place the MTCAP2 at a level higher than the end devices.
Angle the antenna so it is not parallel to the surface. It does not need to be perpendicular to the surface,
but it should not be flat.
20
Mounting Bracket
®
Conduit
AP MTCAP2-LSP3-915x-042-POE and MTCAP2-915x-042-POE User Guide
