MTCAP2-915-042

Note:
Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source
when determining product load.
Maximum Power: MTCAP LoRa connection to MTXDOT running TXP =20 and at+txdr=2. The
MTXDOT was initialized to send packets by joining MTCAP and rapidly sending packet to the MTCAP.
Tx Pulse: The average peak current.
Inrush Charge: The total inrush charge at power on.
Voltage
5 VDC
56 VDC
47 VDC
Phihong POE P.S. 47 mA

Antenna

Your device ships with the following antenna. Any replacement antenna should fall with in the same specifications.

Antenna Compliance

This radio transmitter [IC: 125A-0061] has been approved by Innovation, Science and Economic Development
Canada to operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna
types not included in this list that have a gain greater than the maximum gain indicated for any type listed are
strictly prohibited for use with this device.
Le présent émetteur radio [IC: 125A-0061] a été approuvé par Innovation, Sciences et Développement économique
Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les
types d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué pour tout type
figurant sur la liste, sont strictement interdits pour l'exploitation de l'émetteur.

Pulse Electronics Antenna

Manufacturer:
Description:
Model Number:
MultiTech Part Number:
MultiTech ordering information:
Ordering Part Number
AN868-915A-1HRA
AN868-915A-10HRA
®
Conduit AP MTCAP2-LSP3-915x-042-POE and MTCAP2-915x-042-POE User Guide
Idle Current Average
Measured
Current at
Maximum Power
145 mA 448 mA
41 mA 98 mA
47 mA 109 mA
109 mA
Pulse Electronics
868-928 MHz RP-SMA Antenna, 8"
W1063
45009830L
Quantity
1
10
SPECIFICATIONS AND HARDWARE INFORMATION
TX Pulse Peak Total Inrush
Current for no Charge
radio model
792 mA 1.60 mC
180 mA 1.18 mC
192 mA 1.17 mC
192 mA 1.09 mC
Total Inrush
Charge Duration
3.90 mS
6.92 mS
7.09 mS
6.50 mS
