Chapter 2 System Specifications

2.1 3Com Router 5009 Router

2.1.1 Appearance

1) SLOT0
3) SLOT2
5) ETHERNET
7) POWER
Figure 2-1 Front view of 3Com Router 5009 Router
1) Power switch
3) Grounding terminal
5) Auxiliary port (AUX)
7) Synchronous/asynchronous serial interface (SERIAL)
8) SLOT1 (MIM slot)
10) SLOT2 (SIC slot)
Figure 2-2 Rear view of 3Com Router 5009 Router

2.1.2 Panel LEDs

Seven LEDs are provided on 3Com Router 5009 Router. Their meaning is explained in
the following table:
2) SLOT1
4) SERIAL
6)SYSTEM
2) Power socket
4) Console port (CON)
6) 10/100 Mbps Ethernet interface (ETHERNET)
9)) Fastening screw of the chassis
11) SLOT3 (SIC slot)
