System Description - 3Com 5000 Series Installation Manual

3Com Router 5000 Family
Installation Guide
Table 2-1 LEDs of 3COM ROUTER 5009 Router
LED
SLOT1
SLOT2
SLOT3
SERIAL
ETHERNET
SYSTEM
POWER

2.1.3 System Description

Table 2-2 System description of 3Com Router 5009 Router
Fixed interface
Slot
CPU
Boot ROM
SDRAM
Flash memory
MIM LED. ON indicates that the interface module is in position. OFF
indicates that no module is installed in the current slot or the module
cannot operate properly.
SIC LED. ON indicates that the interface card is in position. OFF
indicates that no interface card is installed in the current slot or the
interface card cannot operate properly.
SIC LED. ON indicates that the interface card is in position. OFF
indicates that no interface card is installed in the current slot or the
interface card cannot operate properly.
Fixed synchronous/asynchronous serial interface LED is used to
show the status of data transceiving on the serial interfaces. OFF
means no data is being transceived. Blinking means data is being
transceived.
Fixed Ethernet interface LED: shows the status of data transmission
on fixed Ethernet interface. OFF means no data is being
transmitted. Blinking means data is being transmitted.
Hardware system operating LED. Blinking means that the system is
operating normally. Steady ON or steady OFF means that the
system is operating abnormally.
Power LED. It is ON after power-on.
Item
One Console port (CON)
One AUX port (AUX)
One Synchronous/asynchronous serial interface
One 10/100 Mbps Ethernet interface
One MIM slot
Two SIC slots
MPC8241 200 MHz
512 KB
128 MB
32 MB
3Com Corporation
