Trotec TA400 Operating Manual page 5

Technical data
Parameter Value
Model TA400
Dimensions of the 210 x 75 x 50 mm
device
(height x width x depth)
Weight of the device 540 g
incl. Pitot tube and
battery
Length of the Pitot tube 335 mm
Diameter of the Pitot 8 mm
tube
Hose lengths 850 mm each
Operating conditions 0 °C to +50 °C, < 90 % RH
Storage conditions 0 °C to +50 °C, < 90 % RH
Power supply 1 x 9 V battery
Air pressure
Accuracy ± 0.3 % at +25 °C
Pressure range 0 to 5000 Pa
Pressure, max. 5000 Pa
Measuring range PSI: 0.7252
mbar: 50.00
inH
mmH
Pa: 5000
Resolution PSI: 0.0001
mbar: 0.01
inH
mmH
Pa: 1
Air velocity
Measuring range m/s: 1 to 80.00
ft/min: 200 to 15733
km/h: 3.6 to 288.0
MPH: 2.24 to 178.66
knots: 2.0 to 154.6
Resolution m/s: 0.01
ft/min: 1
km/h: 0.1
MPH: 0.01
knots: 0.1
Accuracy m/s: ±2.5 % at 10 m/s
ft/min, km/h, MPH, knots: The
accuracy depends on the air velocity
and the size of the air duct.
EN
O: 20.07
2
O: 509.8
2
O: 0.01
2
O: 0.1
2
Parameter
Air volume flow
Measuring range
Resolution
Temperature
Measuring range
Resolution
Accuracy
Scope of delivery
• 1 x Device
• 1 x 9 V battery
• 1 x Pitot tube
• 1 x Tube, white
• 1 x Tube, black
• 1 x Transport case
• 1 x Mini USB cable
• 1 x CD-ROM with software
• 1 x Quick guide
dynamic pressure anemometer TA400
Value
3
CFM: 0 ft /min to 99,999 ft
3
CMM: 0 m /min to 99,999 m
CFM: 0.0001 to 100
CMM: 0.001 to 100
°C: 0 °C to 50 °C
°F: 32.0 °F to 122.0 °F
°C: 0.1
°F: 0.1
°C: ± 1.0 °C
°F: ± 2.0 °F
TA400
3
/min
3
/min
5
