REV A

Test Procedure

1 Turn the key switch to the PCON position. Pull
out the red Emergency Stop buttons to the on
position at the GCON and PCON.
2 At the PCON, raise the platform until it stops
and the alarm sounds. Release the platform up
and function enable buttons.
3 Press and hold the function enable and
platform up buttons.
Result: The alarm continues to sound and the
platform will not raise. Continue to step 4.
Result: The alarm continues to sound and the
platform continues to raise.
Lower the platform to the stowed position and
repeat the software update procedure or
contact the Genie service department.
Tip-over hazard. An improper
operating system will compromise
machine stability and cause the
machine to tip over, resulting in
death or serious injury.
Part No. 218116
4 Press and hold the outrigger enable and extend
5 Lower the platform to the stowed position.
6 Extend the outriggers until the individual
7 Fully raise the platform.
8 Lower the platform to the stowed position and
GS-3232 Smartlink Software Update
buttons.
Result: The alarm continues to sound and the
outriggers do not extend. Continue to step 5.
Result: The alarm continues to sound and the
outriggers extend.
Lower the platform to the stowed position and
contact the Genie service department.
Tip-over hazard. An improper
operating system will compromise
machine stability and cause the
machine to tip over, resulting in
death or serious injury.
outrigger lights turn solid green and a long
beep is heard.
Result: The platform raises to full height and
the alarm is not activated. Continue to step 8.
Result: The platform stops before full height
and the alarm is activated.
Lower the platform to the stowed position and
contact the Genie service department.
retract the outriggers.
Installation Instructions
PROCEDURE
