Tools Required; Observe And Obey; Before Starting Installation; Glossary Of Terms - Terex Genie GS-3232 Installation Instructions Manual

Installation Instructions
Introduction

Observe and Obey:

This procedure shall be completed by a person
trained and qualified on the repair of this
machine.
Immediately tag and remove from service a
damaged or malfunctioning machine.
Repair any machine damage or malfunction
before operating the machine.

Before Starting Installation:

Read, understand and obey the safety rules
and operating instructions in the appropriate
operator's manual.
Be sure that all necessary tools and parts are
available and ready for use.
Read this procedure completely and adhere
to the instructions. Attempting shortcuts may
produce hazardous conditions.
Indicates that a specific result is expected after
performing a series of steps.
Indicates that an incorrect result has occurred
after performing a series of steps.
Note: These installation instructions only apply to
the machine listed below as required by Safety
Notice 120009.
• GS-3232
2

Tools required:

Laptop or desktop computer with an Ethernet Port
and Internet Browser
Torx T10 screw driver
CAT5 Ethernet Cable of suitable length

Glossary of terms

ECM - Electronic Control Module.
GCON - Ground Controller. This ECM is located at
the ground controls.
PCON - Platform Controller. This ECM is located
at the platform controls.
CAT5 Cable - Standard Ethernet cable used for
networking purposes.
Components of Kit 218136
(optional)
Printing instructions
Genie part number 218132
Qty. 1
Thumb drive
Genie part number 218093
Qty 1
Includes:
Software SL1000, APP
Genie part number 137641
Qty 1
Smartlink Software Update Installation Instruction
Genie part number 218116
Qty 1
GS-3232 Smartlink Software Update
REV A
Part No. 218116
