  • Page 1 www.duma-rent.com Operator's Manual Serial Number Range -1530/32 ™ from GS30P-200101 from GS32P-200101 from GS46P-200101 -1930/32 ™ from GS30D-40101 from GS32D-10101 from GS46D-20101 -1932 XH ™ -2032 ™ -2632 ™ with -3232 ™ Maintenance -2046 Information ™ -2646 ™ -2646 XH ™...

  • Page 2: Table Of Contents

    The Netherlands Copyright © 1997 Terex Corporation Eleventh Edition: Second Printing, November 2020 Genie is a registered trademark of Terex South Dakota, Inc. in the U.S.A. and many other countries. “GS” is a trademark of Terex South Dakota, Inc. Complies with EC Directive 2006/42/EC See EC Declaration of Conformity ™...

  • Page 3: Introduction

    www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Introduction Introduction About this manual Intended Use and Familiarization Guide Genie appreciates your choice of our machine for your application. Our number one priority is user The intended use of this machine is to lift personnel, safety, which is best achieved by our joint efforts.
  • Page 4 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Introduction Platform controls symbology and related Ground controls symbology and related machine movement: machine movement: Lift function enable button Lift function enable button Drive function enable button Platform up/down button Outrigger function button Sequential functions and movement: Platform up/down (when lift function •...
  • Page 5 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Introduction Bulletin Distribution and Compliance Contacting the Manufacturer Safety of product users is of paramount importance At times it may be necessary to contact Genie. to Genie. Various bulletins are used by Genie to When you do, be ready to supply the model communicate important safety and product number and serial number of your machine, along...
  • Page 6 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Introduction Safety Sign Maintenance Replace any missing or damaged safety signs. Keep operator safety in mind at all times. Use mild soap and water to clean safety signs. Do not use solvent-based cleaners because they may damage the safety sign material.
  • Page 7 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Introduction Hazard Classification Decals on this machine use symbols, color coding, and signal words to identify the following: Safety alert symbol–used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 8: Symbol And Hazard Pictorials Definitions

    www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Symbol and Hazard Pictorials Definitions Symbol and Hazard Pictorials Definitions Read the operator’s Read the service Crush hazard Crush hazard Collision hazard manual manual Tip-over hazard Tip-over hazard Tip-over hazard Tip-over hazard Electrocution hazard Electrocution hazard Explosion hazard...
  • Page 9 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Symbol and Hazard Pictorials Definitions Do not set up where it Maintain required Access by trained and Use a piece of Lower the platform. cannot be leveled clearance authorized personnel cardboard or paper to with outriggers only search for leaks...
  • Page 10 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Symbol and Hazard Pictorials Definitions Tiedown Release brakes Engage brake Pressure rating for air Voltage rating for line to platform power to platform Maximum capacity Indoor Outdoor Manual force Platform overloaded ™ ™...

  • Page 11: General Safety

    www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual General Safety General Safety GS-1530, GS-1532, GS-1930, GS-1932, GS-1932 XH ™ ™ ™ Part No. 1307633GT -30 • GS -32 • GS...
  • Page 12 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing General Safety GS-1530, GS-1532, GS-1930, GS-1932, GS-1932 XH ™ ™ ™ -30 • GS -32 • GS Part No. 1307633GT...
  • Page 13 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual General Safety GS-1530, GS-1532, GS-1930, GS-1932, GS-1932 XH ™ ™ ™ Part No. 1307633GT -30 • GS -32 • GS...
  • Page 14 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing General Safety GS-2032, GS-2632, GS-3232 ™ ™ ™ -30 • GS -32 • GS Part No. 1307633GT...
  • Page 15 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual General Safety GS-2032, GS-2632, GS-3232 ™ ™ ™ Part No. 1307633GT -30 • GS -32 • GS...
  • Page 16 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing General Safety GS-2032, GS-2632, GS-3232 ™ ™ ™ -30 • GS -32 • GS Part No. 1307633GT...
  • Page 17 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual General Safety GS-2046, GS-2646, GS-2646XH, GS-3246, GS-3246 XH, GS-4046 ™ ™ ™ Part No. 1307633GT -30 • GS -32 • GS...
  • Page 18 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing General Safety GS-2046, GS-2646, GS-2646XH, GS-3246, GS-3246 XH, GS-4046 ™ ™ ™ -30 • GS -32 • GS Part No. 1307633GT...
  • Page 19 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual General Safety GS-2046, GS-2646, GS-2646XH, GS-3246, GS-3246 XH, GS-4046 ™ ™ ™ Part No. 1307633GT -30 • GS -32 • GS...

  • Page 20: Personal Safety

    www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Personal Safety Personal Safety Personal Fall Protection Personal fall protection equipment (PFPE) is not required when operating this machine. If PFPE is required by job site or employer rules, the following shall apply: All PFPE must comply with applicable governmental regulations and must be inspected and used in accordance with the manufacturer’s...

  • Page 21: Work Area Safety

    www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Work Area Safety Work Area Safety Tip-over Hazards Electrocution Hazards Occupants, equipment and materials shall not This machine is not electrically insulated and will exceed the maximum platform capacity or the not provide protection from contact with or maximum platform capacity of the platform proximity to electrical current.
  • Page 22 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Work Area Safety If the tilt alarm sounds: The weight of options and accessories, such as Lower the platform. Move the machine to a firm, panel carriers, will reduce the rated platform level surface.
  • Page 23 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Work Area Safety Do not operate the Do not push off or pull machine in strong or gusty toward any object outside of winds. Do not increase the the platform. surface area of the platform or the load.
  • Page 24 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Work Area Safety Do not alter or disable the limit switches. Do not place or attach fixed or overhanging loads Do not alter or disable machine components that in to any part of this machine. any way affect safety and stability.
  • Page 25 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Work Area Safety Crushing Hazard Operation on Slopes Hazards Keep hands and limbs out of scissors. Do not drive the machine on a slope that exceeds the slope and side slope rating of the machine. Keep hands clear when folding rails.
  • Page 26 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Work Area Safety Fall Hazards Collision Hazards The guard rail system provides fall protection. If Be aware of limited sight occupant(s) of the platform are required to wear distance and blind spots personal fall protection equipment (PFPE) due to when driving or operating.
  • Page 27 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Work Area Safety Explosion and Fire Hazards Do not lower the platform unless the area below is Do not operate the machine or charge the battery clear of personnel and in hazardous locations or locations where obstructions.
  • Page 28 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Work Area Safety Battery Safety Component Damage Hazard Do not use any battery charger greater than 24V to Burn Hazards charge the batteries. Batteries contain acid. Electrocution/Burn Hazards Always wear protective clothing and eye wear when Connect the battery charger to a working with batteries.

  • Page 29: Legend

    www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Legend Legend Platform guard rails Lanyard anchorage points Platform controls Platform extension Manual storage container Foot switch (if equipped) Flashing beacon Transport tie-down Steer tire 10 Forklift pocket 11 Pothole guard 12 Ground controls 13 LCD readout 14 Non-steer tire 15 Auxiliary lowering knob...
  • Page 30 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Legend Platform guard rails Lanyard anchorage points Platform controls Platform extension Manual storage container Foot switch (if equipped) Inverter (optional) Flashing beacon Tilt alarm 10 Transport tie-down 11 Auxiliary lowering knob 12 Steer tire 13 Outrigger (GS-3232 only) 14 Forklift pocket 15 Pothole guard...
  • Page 31 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Legend Platform guard rails Lanyard anchorage points Platform controls Platform extension Manual storage container Foot switch (if equipped) Inverter (optional), GS-46 Flashing beacon Tilt alarm 10 Transport tie-down 11 Auxiliary lowering knob 12 Steer tire 13 Pothole guard 14 Forklift pocket...

  • Page 32: Controls

    www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Controls Controls The ground control station is to be used as a means to raise the platform for function tests and for storage purposes. The ground control station can be used in the event of an emergency to rescue an incapacitated person in the platform.
  • Page 33 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Controls 1283810 A 1283810 A 1283810 A 1283810 A Platform Control Panel Red Emergency Stop button Horn button Push in the red Emergency Stop button to the Press the horn button and the horn off position to stop all functions.
  • Page 34 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Controls Proportional control handle and function Thumb rocker switch for steer function enable switch for drive, steer, lift and outrigger Press the left side of the thumb functions rocker and the machine will turn in Lift function: Press and hold the function the direction the blue triangle enable switch to enable the lift function on the...
  • Page 35 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Controls 10 Outdoor use button Press this button for outdoor use Note: Selecting outdoor use permits elevating to maximum outdoor platform height. Refer to specification pages. 11 Outrigger indicator lights During outrigger extension, lights flash green.

  • Page 36: Inspections

    www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Inspections Inspections Pre-operation Inspection Fundamentals It is the responsibility of the operator to perform a pre-operation inspection and routine maintenance. The pre-operation inspection is a visual inspection performed by the operator prior to each work shift. Do Not Operate Unless: The inspection is designed to discover if anything is apparently wrong with a machine before the...
  • Page 37 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Inspections Pre-operation Inspection  Safety arm  Platform extension  Be sure that the operator’s, safety, and  Scissor pins and retaining fasteners responsibilities manuals are complete, legible and in the storage container located in the ...
  • Page 38 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Inspections Function Test Fundamentals The function tests are designed to discover any malfunctions before the machine is put into service. The operator must follow the step-by-step instructions to test all machine functions. A malfunctioning machine must never be used.
  • Page 39 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Inspections At the Ground Controls Test the Up/Down Functions The audible warnings on this machine and the Select a test area that is firm, level and free of standard horn all come from the same central hazards.
  • Page 40 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Inspections Test Auxiliary Lowering At the Platform Controls 15 Activate the up function by pressing the lift Test Emergency Stop enable button and platform up button, and raise the platform approximately 2 ft. / 60 cm. 19 Push in the platform red Emergency Stop button to the off position.
  • Page 41 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Inspections Test the Function Enable Switch and the 29 Release the control handle. Up/Down Functions Result: The platform should stop raising. 22 Do not hold the function enable switch on the 30 Press and hold the function enable switch on control handle.
  • Page 42 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Inspections GS-2632: Result: The platform should raise to Test the Outdoor Use Button a maximum of 19 ft/5.79 m and stop. The 31 Do not press and hold the function enable alarm should sound. The platform controls LED switch on control handle.
  • Page 43 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Inspections Test the Drive Function Button Test Drive and Braking 35 Press the drive function button. 41 Press the drive function button. 36 Wait seven seconds for the drive function to 42 Press and hold the function enable switch on time out.Slowly move the control handle in the the control handle.
  • Page 44 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Inspections Test the Tilt Sensor Operation Test Drive Tilt Cutout (GS-3232 only) Note: Perform this test from the ground with the platform controller. Do not stand in the platform. Note: Perform this test from the ground with the platform controller.
  • Page 45 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Inspections 61 Drive the machine onto a slope where the pitch 68 Fully lower the platform. angle is greater than 1.5° side to side. 69 Drive the machine. Result: The machine should stop once the Result: The machine should drive.
  • Page 46 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Inspections Test the Pothole Guards 80 Press the drive function button. Note: The pothole guards should automatically deploy when the platform is raised. The pothole guards activate limit switches that allow the machine to continue to function.
  • Page 47 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Inspections 92 Press the drive function button. Test the Outrigger Function (GS-3232) 93 Press and hold the function enable switch on 88 Press the outrigger function button. the control handle. On the LCD screen, a circle below the outrigger function symbol will 94 Slowly move the control handle in the direction turn on.
  • Page 48 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Inspections 102 Wait seven seconds for the outrigger function enable to time out. 103 Slowly move the control handle in the direction indicated by the blue arrow, then in the direction indicated by the yellow arrow. Result: The outriggers should not retract.
  • Page 49 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Inspections Workplace Inspection Checklist Be aware of and avoid the following hazardous situations:  drop-offs or holes  bumps, floor obstructions, or debris  sloped surfaces Do Not Operate Unless:  unstable or slippery surfaces ...
  • Page 50 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Inspections Inspection for Decals with Part No. Decal Description Symbols GS-1530, GS-1532, 1278704 Label — Battery Charger Indicator 1281174 Label — Lanyard Anchorage Point, Fall GS-1930 and GS-1932 Arrest/Fall Restrained Determine whether the decals on your machine 1283810 Label —...
  • Page 51 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Inspections ™ ™ ™ Part No. 1307633GT -30 • GS -32 • GS...
  • Page 52 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Inspections Inspection for Decals with Part No. Decal Description Symbols GS-2032, GS-2632 and 1278704 Label — Battery Charger Indicator 1281174 Label — Lanyard Anchorage Point, Fall GS-3232 Arrest/Fall Restrained Determine whether the decals on your machine 1283810 Label —...
  • Page 53 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Inspections ™ ™ ™ Part No. 1307633GT -30 • GS -32 • GS...
  • Page 54 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Inspections Inspection for Decals with Part No. Decal Description Symbols GS-2046, GS-2646, 1283810 Label — Platform Control Panel 1283878 Label — Tech Pro Link GS-3246 and GS-4046 1284982 Warning — Explosion Hazard, Determine whether the decals on your machine Accumulator have words or symbols.
  • Page 55 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Inspections ™ ™ ™ Part No. 1307633GT -30 • GS -32 • GS...

  • Page 56: Operating Instructions

    www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Operating Instructions Operating Instructions Fundamentals The Operating Instructions section provides instructions for each aspect of machine operation. It is the operator’s responsibility to follow all the safety rules and instructions in the operator’s, safety, and responsibilities manuals.
  • Page 57 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Operating Instructions Emergency Stop Operation from Platform Push in the red Emergency Stop button to the off Be sure the battery pack is connected before position at the ground controls or the platform operating the machine.
  • Page 58 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Operating Instructions Note: If the outrigger enable and extend buttons To Position Outriggers (GS-3232 models) are released too soon during extension, the To Extend Outriggers: outrigger indicator lights will continue to flash green, indicating the outriggers are not contacting the Press the outrigger function button.
  • Page 59 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Operating Instructions To Steer To Drive Press the drive function button. On the LED Press the drive function button. On the LED screen, a circle below the drive function symbol screen, a circle below the drive function symbol will turn on.
  • Page 60 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Operating Instructions To determine the slope grade: To select drive speed Measure the slope with a digital inclinometer OR The drive controls can operate in two different drive use the following procedure. speed modes.
  • Page 61 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Operating Instructions Operational indicator codes Platform Overload If the platform controls LED or ground controls LCD If the platform controls LED diagnostic readout diagnostic readout displays an operational displays a flashing OL and the ground controls indicator code such as LL, the fault condition must LCD diagnostic readout displays OL: Platform repaired or removed before resuming machine...
  • Page 62 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Operating Instructions Tilt Sensor Activation Settings Battery Level Indicator Tilt Sensor Activation Settings Use the LED diagnostic readout to determine the battery level. Chassis Angle (side to side) 1.5° Chassis Angle (front to back) 3°...
  • Page 63 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Operating Instructions At the rear of the main deck, remove the two How to Use the Safety Arm main deck lock pins. Raise the platform approximately 8ft/2.4 m to Keep hands free of pinch points. 13 ft/4.0 m from the ground.
  • Page 64 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Operating Instructions GS-2046, GS-2646, GS-3246 How to Raise the Guardrails The platform railing system consists of three fold Follow the fold down instructions but in reverse down rail sections for the extension deck and three order, ensuring all lock pins are in place and sections for the main deck.
  • Page 65 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Operating Instructions Lift Tools Pipe Cradle Observe and Obey: Instructions  Lift Tools Pipe Cradle must be mounted on the inside of the platform. The Lift Tools Pipe Cradle assembly consists of 2 pipe cradles positioned at either side of the ...
  • Page 66 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Operating Instructions Lift Tools Pipe Cradle Operation Large pipe cradle capacity: 6” Maximum diameter. See load chart for weight capacity. Place the load so that it rests in both Lift Tools Do not operate unless you are adequately Pipe Cradles.
  • Page 67 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Operating Instructions Panel Carrier Instructions Observe and Obey:  The Lift Tools Panel Carrier assembly consists of a Lift Tools Panel Carrier must be mounted on carrier assembly and a strap assembly. the left side of the platform.
  • Page 68 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Operating Instructions Installation of Panel Carrier Strap Maximum Lift Tools Panel Carrier Capacity Load Chart Open the clamp and install it on the mounting tab with the 1/4" x 0.75" bolt (6). GS-1530, GS-1532, GS-1930, 100 lbs GS-1932, GS-1932 XH...
  • Page 69 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Operating Instructions Lift Tools Work Tray Instructions Observe and Obey: Lift Tools Work Tray Installation The Lift Tools Work Tray assembly consists of one tray and two mounting brackets with hardware.  Lift Tools Work Tray must be installed on the inside of the platform.
  • Page 70 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Operating Instructions Lift Tools Work Tray Operation Platform Height Restriction Instructions Place the load so that it rests inside the Lift Tools Work Tray. Platform Height Restriction allows the platform to be limited to a specific height. The Lift Tools Work Tray assembly weighs 4 lbs/1.8 kg.
  • Page 71 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Operating Instructions To test the platform height restriction: Platform Height Restriction Operation Press and hold the lift function enable button, and press the platform up button. To limit height: Result: The platform should raise to the previously set height.
  • Page 72 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Operating Instructions Standard Batteries Remove the battery vent caps and check the battery acid level. If necessary, add only enough distilled water to cover the plates. Do not overfill prior to the charge cycle. Replace the battery vent caps.

  • Page 73: Transport And Lifting Instructions

    www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Transport and Lifting Instructions Transport and Lifting Instructions  The machine must be on a level surface or secured before releasing the brakes.  Do not allow the rails to fall when the snap pins are removed.
  • Page 74 Push the red Emergency stop button at both the ground and platform controls to the off position. Towing the Genie GS-1530, GS-1532, GS-1930, GS-1932, GS-1932 XH, GS-2032, GS-2632, GS-3232, GS-2046, GS-2646, GS-2646 XH, GS-3246, GS-3246 XH, and the GS-4046 is not recommended.
  • Page 75 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Transport and Lifting Instructions Inspect the entire machine for loose or unsecured Securing to Truck or Trailer for items. Transit Use chains or straps of ample load capacity. Always use the extension deck lock when the machine is transported.
  • Page 76 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Transport and Lifting Instructions Lifting the Machine with a Forklift Be sure the extension deck, controls and component trays are secure. Remove all loose items on the machine. Fully lower the platform. The platform must remain lowered during all loading and transport Observe and Obey: procedures.
  • Page 77 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Transport and Lifting Instructions Lifting Instructions, GS-30 Fully lower the platform. Be sure the extension deck, controls and component trays are secure. Remove all loose items on the machine. Determine the center of gravity of your machine using the table and the picture on this page.

  • Page 78: Maintenance

    www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Maintenance Maintenance Check the Hydraulic Oil Level Maintaining the hydraulic oil at the proper level is essential to machine operation. Improper hydraulic Observe and Obey: oil levels can damage hydraulic components. Daily checks allow the inspector to identify changes in oil ...
  • Page 79 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Maintenance Check the Batteries Scheduled Maintenance Maintenance performed quarterly, annually and every two years must be completed by a person trained and qualified to perform maintenance on Proper battery condition is essential to good this machine according to the procedures found in machine performance and operational safety.

  • Page 80: Specifications

    www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Specifications Specifications Model GS-1530 Operating temperature Height, working outdoor 18 ft 8 in 5.86 m -20°F -29°C Minimum Height, platform outdoor 12 ft 8 in 3.86 m 120°F 48.9°C Maximum Height, working indoor 21 ft 1 in 6.61 m Airborne noise emissions...
  • Page 81 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Specifications Model GS-1532 Operating temperature Height, working outdoor 18 ft 8 in 5.86 m -20°F -29°C Minimum Height, platform outdoor 12 ft 8 in 3.86 m 120°F 48.9°C Maximum Height, working indoor 21 ft 1 in 6.61 m Airborne noise emissions...
  • Page 82 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Specifications Model GS-1930 Operating temperature Height, working outdoor 20 ft 8 in 6.30 m Minimum -20°F -29°C Height, platform outdoor 14 ft 8 in 4.47 m Maximum 120°F 48.9°C Height, working indoor 25 ft 3 in 7.85 m Airborne noise emissions Height, platform indoor...
  • Page 83 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Specifications Total vibration value to which the hand/arm system is Model GS-1932 subjected does not exceed 2.5 m/s Height, working outdoor, dual zone 20 ft 8 in 6.30 m Highest root mean square value of weighted acceleration Height, platform outdoor, dual zone 14 ft 8 in 4.47 m to which the whole body is subjected does not exceed...
  • Page 84 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Specifications Model GS-2032 Operating temperature Height, working outdoor 22 ft 6.88 m Minimum -20°F -29°C Height, platform outdoor 16 ft 4.88 m Maximum 120°F 48.9°C Height, working indoor 26 ft 1 in 8.13 m Airborne noise emissions Height, platform indoor 20 ft1 in 6.13 m...
  • Page 85 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Specifications Model GS-2632 Operating temperature Height, working outdoor 25 ft 7.79 m Minimum -20°F -29°C Height, platform outdoor 19 ft 5.79 m Maximum 120°F 48.9°C Height, working indoor 32 ft 1 in 9.96 m Airborne noise emissions Height, platform indoor...
  • Page 86 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Specifications Hydraulic pressure, maximum 2300 psi 159 bar Model GS-3232 (E-drive) Height, working outdoor on 24 ft 7.49 m Tire size 15 x 5 in 38 x 13 cm outriggers Total vibration value to which the hand/arm system is Height, platform outdoor on 18 ft 5.49 m...
  • Page 87 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Specifications Model GS-2046 Operating temperature Height, working outdoor 22 ft 4 in 6.98 m Minimum -20°F -29°C Height, platform outdoor 16 ft 4 in 4.98 m Maximum 120°F 48.9°C Height, working indoor 26 ft 1 in 8.13 m Airborne noise emissions Height, platform indoor...
  • Page 88 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Specifications Maximum hydraulic pressure 2800 psi 193 bar Model GS-2646 (functions) Height, working outdoor, dual zone 25 ft 8 in 7.99 m Tire size 15 x 5 in 38 x 13 m Height, platform outdoor, dual zone 19 ft 8 in 5.99 m Vibration value does not exceed 2.5 m/s...
  • Page 89 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Specifications Maximum hydraulic pressure 2600 psi 179 bar Model GS-3246 (functions) Height, working outdoor, dual zone 28 ft 8.71 m Tire size 15 x 5 in 38 x Height, platform outdoor,dual zone 22 ft 6.71 m 13 cm Height, working outdoor, XH...
  • Page 90 www.duma-rent.com Operator's Manual Eleventh Edition • Second Printing Specifications Model GS-4046 Operating temperature Height, working outdoor 29 ft 9.01 m Minimum -20°F -29°C Height, platform outdoor 23 ft 7.01 m Maximum 120°F 48.9°C Height, working indoor 45 ft 0 in 13.89 m Airborne noise emissions Height, platform indoor...
  • Page 91 www.duma-rent.com Eleventh Edition • Second Printing Operator's Manual Specifications Contents of EC Declaration of Conformity <Manufacturer’s name> hereby declares that the machinery described below complies with the provisions of the following Directives: 1. EC Directive 2006/42/EC, Machinery Directive, under consideration of harmonized European standard EN280 as described in EC type-examination certificate <variable field>...
  • Page 92 www.duma-rent.com...
