Service and Repair Manual
GS
-1530/1532
™
GS
-1930/1932
™
GS
-2032/2632/3232
™
GS
-2046/2646/3246
™
GS
-4047
™
Serial Number Range
Refer to the
inside cover
This manual includes:
Repair procedures
Fault Codes
Electrical and
Hydraulic Schematics
For detailed maintenance
procedures, refer to the
appropriate Maintenance
Manual for your machine.
Part No. 1272217GT
Rev E
March 2021
