- Page 1 Fast operation of Analogue Villa System V 1.0...
- Page 2 Contents System Structure ........................3 Operation Steps ......................... 3 Install lock and unlock button ....................3 3.1 VTO5x00C ..........................3 3.1.1 Install electric lock and unlock button ..............4 3.1.2 Install Door sensor ....................4 3.2 VTO5110B ..........................4 3.2.1 Install electric lock and unlock button ..............4 3.2.2 Install door sensor ....................
-
Page 3: System Structure
1 System Structure Power for VTO is DC24V/2.5A Figure 1-1 2 Operation Steps Wait until system connection is complete. Plug VTO to power and wait about 1 second. VTH’s power indicator turns on, and press monitor button on VTH. You will see scene in front of VTO and this means test is complete. - Page 4 General types of lock in market are unlocking with power and unlocking without power. Here make electric lock and Magnetic lock as example. 3.1.1 Install electric lock and unlock button 1. When connect VTO to electric lock, make electric lock + toward VTO NO-end (03.3-pin 1) and electric –...
-
Page 5: Issue Card
1. When VTO connects to electric lock, make electric lock + end toward VTO (03. 3-pin 1) NO end, and make electric lock – end toward VTO (03. 3-pin 1) COM end. 2. When VTO connects to unlock button, make unlock button’s one end toward VTO (04.
