3. PRODUCT OVERVIEW
3.2 TECHNICAL SPECIFICATIONS
Serial number format Business Pro View
Serial number format Business Lite View
Maximum number of Business Pro in one group
Models allowed in group
Maximum number of Business Lites per Business Pro
Maximum charge capacity
Standard configured charge capacity
Electric safety category
DC-fault current protection
Dimensions (H x W x D)
Weight
Standard colours
IEC-62262 IK code (robustness)
IEC-60529 IP code (protection class)
EN-50470 M-class
EN-50470 E-class
Certificates
kWh measurement
INSTALLATIEHANDLEIDING – P7
INSTRUCTION MANUAL – P7 | P7
09 5_ _ _ _ _
08 5_ _ _ _ _
1
Business 2.0 and Business 2.1 chargepoints
Daisy chain configuration: 15
Star configuration: 40
1-phase 32A (7,4 kW)*
3-phase 32A (22kW)*
1-phase 16A (3,7kW)**
3-phase 16A (11kW)**
Class I & Class II****
Built-in 6mA DC fault current protection
503.5 x 200 x 137 mm
± 4.2 kg
Rear side RAL 7031 (grey)
Front side RAL 9010 (white)
IK10
IP54 (for indoor and outdoor use)
M1
E2
IEC-61851-1
IEC-61851-22
EV-Ready & ZE-Ready
IEC-62262 -> IK10
IEC-60529 -> IP54
IEC-62955 -> 6mA DC-fault protection
MessEV & MessEG
MID certified (accuraccy class B)
M&E certified
