6. OPTIONAL: DYNAMIC POWER SHARING
INSTALLATION FORM
For this Dynamic Power Sharing
successful, please follow and complete the form below
during the installation.
Position Serial number
1 09 _ _ _ _ _ _
2 08 _ _ _ _ _ _
3 08 _ _ _ _ _ _
4 08 _ _ _ _ _ _
5 08 _ _ _ _ _ _
6 08 _ _ _ _ _ _
7 08 _ _ _ _ _ _
8 08 _ _ _ _ _ _
9 08 _ _ _ _ _ _
10 08 _ _ _ _ _ _
11 08 _ _ _ _ _ _
12 08 _ _ _ _ _ _
Table 1. Installation form.
Charge capacity settings
Max amperage per phase
all charge points combined
Max amperage per phase
each charge point
Table 2. Information regarding the group charge capacity.
