1.
A. For left hand pedestal applications
break off the tab marked "R".
B. For right hand pedestal applications
break off this tab, keeping the tab
marked "R".
NOTE: Right hand pedestal application
shown in step 2.
2.
Place the filler against the back of the
pedestal. Line up the top hole and bottom
hole of the filler with the pilot dimples on the
top and bottom of the back of the pedestal.
2
1a
FILLER
1b
FILLER
PILOT
DIMPLE
PILOT
DIMPLE
