Seicane S127305 Upgrade Installation Replacement Instruction

2011 2012 2013 ford c max focus aftermarket car radio

Download this manual

www.seicane.com

Seicane S127305 2011 2012 2013 Ford C Max Focus aftermarket

car radio upgrade installation replacement instruction

Seicane S127305 2011 2012 2013 Ford C Max Focus head unit after installation

Before and during installation, you should notice:

1.Before connecting, please make sure the ignition is off to avoid short circuit.

2.Ensure connect the yellow and red power cable at last.

3.Ensure that all loose wires are isolated with electrical tape

4.Ensure don't tangle the wire when tighten the moving parts(Such as seat rails).

5.Ensure that all ground is connected to the same place.

6.Using the improper fuse may cause damage of fire, so when replace the fuse, please consult

the professional.

7. For your convenience, here's the recommended tools for removal and installation from

Seicane, please check for more details:

http://www.seicane.com/car-dvd-dismantling-device-srd-

400

Need help?

Do you have a question about the S127305 and is the answer not in the manual?

Page 1 Seicane S127305 2011 2012 2013 Ford C Max Focus aftermarket car radio upgrade installation replacement instruction Seicane S127305 2011 2012 2013 Ford C Max Focus head unit after installation Before and during installation, you should notice: 1.Before connecting, please make sure the ignition is off to avoid short circuit.
Page 2 Focus 2011 Ford C Max head unit installation instruction 1. The original car radio. 2 Remove the screws under the front panel. 3. Use a lever to pry along the edges of the front panel and loosen it with your hands.
Page 3 4. Take the front panel out of the dash. 5. Disconnect the connector at the back of the front panel. Then put front panel aside. 6. Unscrew two screws holding the factory radio into the dash with a screwdriver.
Page 4 7. Gently take the factory radio out of the dash. 8. Check all the accessories for the new Seicane head unit. 9. Connect the harnesses to the back of the new Seicane head unit.
Page 5 10. Connect the Seicane head unit to your original car radio 's plugs, and put the new Seicane head unit into the dash. 11. Turn on the new Seicane head unit and check whether the radio is working properly.
