Seicane S168069 Replacement Instruction

Car stereo head unit upgrade installation

Advertisement

Seicane S168069 2007-2015 Mazda CX-9 aftermarket car stereo
head unit upgrade installation replacement instruction
2007-2015 Mazda CX-9 aftermarket car stereo after installation

Tips about the installation:

1.Please disconnect the power before the installation.
2.Please prepare a lever and a screwdriver before the removal and the installation.
3.Please keep all the separate parts from the car. Please take great care of the dashboard to avoid
scratching it during its detachment and installation. Please keep handy any parts from the car
and make use of all the original screws from the car as much as possible. so each related part of
the unit can be fixed securely.
4. For your convenience, here's the recommended tools for removal and installation from
Seicane, please check for more details:
srd-400
www.seicane.com
http://www.seicane.com/car-dvd-dismantling-device-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S168069 and is the answer not in the manual?

Questions and answers

Summary of Contents for Seicane S168069

  • Page 1 Seicane S168069 2007-2015 Mazda CX-9 aftermarket car stereo head unit upgrade installation replacement instruction 2007-2015 Mazda CX-9 aftermarket car stereo after installation Tips about the installation: 1.Please disconnect the power before the installation. 2.Please prepare a lever and a screwdriver before the removal and the installation.
  • Page 2 2007-2015 Mazda CX-9 aftermarket car stereo installation guide 1) Pry on both sides panels of the radio. 2 ) Open the cup holder and pry on the shifter panel, pull it out slowly. Watch out the wiring behind it.
  • Page 3 4)Pull out the panel under the radio and disconnect the wiring behind it. 5)Remove two screws on the both sides of the radio. 6)Pull out the dash cover on the radio slowly and unplug the wiring behind the dash cover.
  • Page 4 9)Disconnect all connectors at the back of the original car radio. 10)Check all the accessories for the new Seicane car stereo. 11)Connect the harnesses to the back of the new Seicane car stereo. 12)Connect the Seicane car stereo to your original car radio 's plugs.
  • Page 5 13)Turn on the new Seicane stereo to have a careful check if everything works well. If it doesn't, please check whether all the cables are connected correctly. 14)Put the new Seicane stereo into the dash. 15)Put everything into their original place.
