Seicane S085991 Upgrade Installation Replacement Instruction

For 2001-2011 mercedes-benz e class g class cls class

Advertisement

Seicane S085991 2001-2011 Mercedes-Benz E Class G Class CLS Class aftermarket
car stereo head unit upgrade installation replacement instruction
Seicane S085991 2001-2011 Mercedes-Benz E Class G Class CLS Class car stereo after installation
Please note:
This unit can be suitable for the following cars which are also with the same installation steps
as follows.
2002-2008 Mercedes-Benz E Class E200 E220 E240 E270 E280
2001-2008 Mercedes Benz G Class W463 G550 G500 G400 G320
2004-2011 Mercedes Benz CLS Class W219 CLS350 CLS500 CLS55

Before and during installation, you should notice:

1.Before connecting, please make sure the ignition is off to avoid short circuit.
2.Ensure connect the yellow and red power cable at last.
3.Ensure that all loose wires are isolated with electrical tape
4.Ensure don't tangle the wire when tighten the moving parts(Such as seat rails).
5.Ensure that all ground is connected to the same place.
6.Using the improper fuse may cause damage of fire, so when replace the fuse, please consult
the professional.
7. For your convenience, here's the recommended tools for removal and installation from
Seicane, please check for more details:
srd-400
www.seicane.com
http://www.seicane.com/car-dvd-dismantling-device-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S085991 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Seicane S085991

  • Page 1 Seicane S085991 2001-2011 Mercedes-Benz E Class G Class CLS Class aftermarket car stereo head unit upgrade installation replacement instruction Seicane S085991 2001-2011 Mercedes-Benz E Class G Class CLS Class car stereo after installation Please note: This unit can be suitable for the following cars which are also with the same installation steps as follows.
  • Page 2 2001-2011 Mercedes-Benz E Class G Class CLS Class car stereo installation guide 1. The original car radio. 2. Use a lever to release the decoration panel and remove the cigarette lighter. 3. Remove two screws under the 6-disc CD changer and take out the CD changer.
  • Page 3 5. Check all the accessories for the new Seicane car radio. 5. Connect the cables in the package. a. Connect with the power cable in the car. b. Socket for the speaker cable plug in the car. c. Connect CAN-H, CAN-L with CAN-BUS...
  • Page 4 6. Remove the baffle-plate under the assistant driver seat, connect the CAN-H, CAN-L cable (green)③ with the CAN-BUS socket marked in the picture. 7. Pry the decoration panel beside the driver's seat, change fuse from 5A TO 10A. 8. Remove the screws for fastening the car pc in the left of the trunk.
  • Page 5 10. Remove the amplifier in the car. 11. Connect the speaker cable with the speaker socket ②. 12. Turn on the new Seicane stereo to have a careful check if everything works well. If it doesn't, please check whether all the cables are connected correctly.
