INSTALLATION MANUAL

Level of Difficulty

Easy

Pintle Weight Capacity

Gross trailer weight (GTW)

Ball Weight Capacity

Gross trailer weight (GTW)

Parts List

Item Qty Description
1
1
Pintle hitch

Tools Required

Torque wrench
Ratchet
Socket, 3/4"
Wrench, 3/4"

Torque Specifications

Hitch ball
450 ft-lbs.
1/2" bolt
90 ft-lbs.
Use above torque setting unless otherwise noted

Product Registration

CURT Group stands behind our products
with industry-leading warranties. Provide
feedback and help us to improve our
products by registering your purchase at:
warranty.curtgroup.com/surveys
CURTMFG.COM
NEED ASSISTANCE?

WARNING

Never exceed the vehicle manufacturer's recommended towing capacity.
Do not modify this pintle in any way. Unauthorized modification may impair the
function and / or safety and could affect the life of the product and void the warranty.
Maintain adequate vertical down (tongue) load to have control of the
trailer (generally 10%), but do not exceed the specified rated capacities.
20,000 lbs.
Trailers and equipment are designed for on-road towing within the stated capacities.
For off-road applications, reduce the capacities listed in the specifications table by 25%.
Keep safety chains in place and in working order. Never operate
the product without the safety chains attached to vehicle.
10,000 lbs.
Product Photo
CAUTION
Check for damaged parts before each use. Carefully check that the product will operate
properly and perform its intended function. Replace damaged or worn parts immediately.
Never operate the product with a damaged part.
NOTICE
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
To help prevent damage to the product or vehicle, refer to the specified
torque specifications when securing hardware during the installation process.

Maintenance

Inspect the unit for proper operation, and worn, damaged or missing parts.
Replace as required or when the unit's wear exceeds 1/8" from the original surface.
Check the hardware torque specification after the first
200 miles of towing and every 400 miles after that.
877.287.8634
48411-INS-RA
PAGE 1
