Koso BA005000 Instruction

A/F meter
Thank you for purchasing A/F meter, before operating the unit, please read these instructions thoroughly and retain them for future
reference.
Notice
1.The LCD meter is made for DC 12V..
P.S. The oxygen sensor will start to detect the signal after starting the engine over one minute.
2.When installing the meter, please use the attached signal wire to avoid the electromagnetic wave interference caused by the wire.
3.For installation, please follow the steps described in manual. Any damage caused by wrong installation shall be imputed to the users.
4.To avoid a short circuit, please don't pull the wire when installing. don't break or modify the wire terminal.
5.Do not disassemble or change any parts in the manual description.
6.The interior examination or maintenance should be executed by our professionals.
7.This unit is for Tuning purposes only.
SYMBOL NOTE:
You could get the installation details from the information behind the mark.
Some processes must be followed to avoid the damage caused by wrong installation.
WARNING!
Some processes must be followed to avoid damages to yourself or the public.
CAUTION! Some processes must be followed to avoid damage to the vehicle.
1-1
Accessories
1
Meter X 1
5
Bung cap X1
9
Steel gasket X 1
13
Connect terminal X 1
Please contact the local distributor if the items you open are not the same, with the above-listed one.
1-2
Option accessory
Sensor adapter X1
1
(For 2 strokes engine only!)
Some option accessories are not sold in some area. Please check with your dealer for more information.
INsTRUCTION
2
Signal connect wire X 1
6
Meter bracket X 1
M5X18L Hexhead
10
screw X 2
14
M3 wrench X 1
3 3
Oxygen sensorX1
7
Rubber gasketX 1
11
M5 washer X 2
15
M4 wrench X 1
PRESS THE PRESS THE
BUTTON ONE TIME BUTTON 3
SECONDS
4
Sensor bung X 1
8
Rubber gasket X 1
12
M5 spring washer X2
