  • Page 1 _________ l � -' -------- - - ИБП Borri UPsaver - руководство по эксплуатации. Юниджет Постоянная ссылка на страницу: https://www.uni-jet.com/catalog/istochniki- besperebojnogo-pitaniya/on-line-ibp-100-kva/borri-upsaver.html...
  • Page 2 UPS OPERATING MANUAL UPSaver 400-1600 kVA...
  • Page 3 WARNING: This is a product for commercial and industrial application in the second environment - installation restrictions or additional measures may be needed to prevent disturbance...
  • Page 4 UPS OPERATING MANUAL Index of the sections Code 1 – WARNINGS AND GENERAL INFORMATION OMH44148 2 – INSTALLATION AND START-UP OMH44149 3 – UPS USER MANUAL OMH44150 Descrizione Data Emesso Approvato Lingua Pagina di Pag. Rev. Description Date Issued Approved Language Page of Pag.

  • Page 6: Table Of Contents

    Warnings and general information WARNINGS AND GENERAL INFORMATION Index     CONVENTIONS USED ................ 3     DOCUMENTATION NOTES ..............4     CONTACTS ..................4     FACTORY WARRANTY ..............5     LIMITATION OF LIABILITY ..............7 Descrizione Data Emesso Approvato...
  • Page 7 Warnings and general information OMH44148 REV. A...

  • Page 8: Conventions Used

    Warnings and general information Thank you for choosing a Borri product. This section of the manual contains indications regarding the symbols used in the UPS documentation as well as basic information about the product, including the factory warranty terms. CONVENTIONS USED The following symbols have been used to indicate potential dangers and to highlight useful information, so as to minimize the risks to persons and property.

  • Page 9: Documentation Notes

    In the event that the information provided in this manual is not sufficiently exhaustive, please contact the manufacturer of the device, whose details are available in the “Contacts” section. CONTACTS For any information about the UPS systems manufactured by BORRI, please contact: Borri S.p.A. Via 8 Marzo, 2 52010 Soci - Bibbiena AREZZO Tel.

  • Page 10: Factory Warranty

    CLASS III COLUMN B. Modes required a) In the event of a fault covered by the warranty, the customer shall notify Borri S.p.A. in writing of the occurred fault, providing a short description of the fault. b) The customer shall also provide documents showing the validity of the warranty (receipt/purchasing invoice with serial number of the product –...
  • Page 11 Responsibility a) In no event shall Borri S.p.A. be liable for direct or indirect damage, or any damage whatsoever connected with the execution of warranty services (e.g. possible voltage interruptions during the repair period or assembly and dismantling costs), except for the cases provided for by mandatory laws.

  • Page 12: Limitation Of Liability

    LIMITATION OF LIABILITY All the information contained in the present documentation is the exclusive property of Borri S.p.A. Written consent by Borri S.p.A. is required in order to wholly or partially publish or disclose this information.  The present manual constitutes an integral part of the product technical support documentation.
  • Page 14 UPSaver installation and start-up UPSAVER INSTALLATION AND START-UP Index   APPLICABILITY .................. 8     SAFETY RULES AND WARNINGS ............ 9   2.1  USING THE DEVICE ....................9  2.2  SYSTEM RATING ...................... 10  2.2.1  Actual power configuration ................11  2.3  SPECIAL SAFETY WARNINGS ................
  • Page 15 UPSaver installation and start-up 3.3.5  Environmental installation conditions ............37  3.4  SYSTEM POSITIONING AND INSTALLATION ............39  3.4.1  Positioning the I/O module ................39  3.4.2  Floor fixing ......................40  3.4.3  Connection of the interconnection cables ............41  3.4.4  Positioning the power modules ............... 42  3.4.5 ...
  • Page 16 UPSaver installation and start-up Index of the pictures     Picture 1 – UPSaver rating plate ......................10     Picture 2 – Actual power configuration plates ..................11     Picture 3 – Panels removal on I/O module ..................... 18  ...
  • Page 17 UPSaver installation and start-up     Picture 36 – Cable routing base ......................39     Picture 37 – Installation of cable routing bases on 800 kVA UPSaver ..........39     Picture 38 – Floor fixing ........................40    ...
  • Page 18 UPSaver installation and start-up     Picture 74 – Location of the UPSaver interface cards ................70     Picture 75 – Touch screen start-up image .................... 75     Picture 76 – I/O module start-up ......................75     Picture 77 –...
  • Page 19 UPSaver installation and start-up     Picture 112 – Module start-up ......................... 95     Picture 113 – Module start-up ......................... 95     Picture 114 – Module start-up completed ....................96 OMH44149 REV. C...
  • Page 20 UPSaver installation and start-up OMH44149 REV. C...

  • Page 21: Applicability

    UPSaver installation and start-up APPLICABILITY The instructions contained in the operating manual are applicable to the UPS systems of the UPSaver series, in all their possible power configurations. Storing documentation This manual and any other supporting technical documentation relating to the product must be stored and made accessible to personnel in the immediate vicinity of the UPS.

  • Page 22: Safety Rules And Warnings

    SAFETY RULES AND WARNINGS USING THE DEVICE Congratulations on choosing a product from Borri S.p.A. for the safety of your equipment. To obtain the best performance from your UPSaver system, we suggest that you take your time to read the following manual.

  • Page 23: System Rating

    Made in According to ISO9001:2008 ITALY ISO14001 Service: www.borri.it Picture 1 – UPSaver rating plate Check the technical characteristics Before carrying out any installation or start-up operation on the UPS, make sure its technical characteristics are compatible with the AC supply line and with the output loads.

  • Page 24: Actual Power Configuration

    UPSaver installation and start-up System ratings related to the I/O module The data indicated in the rating plate are related to the maximum power configuration of the I/O module. Refer to the following paragraph for further information. 2.2.1 Actual power configuration The UPSaver system is, by definition, a modular UPS, that can be initially configured for a certain power, which can be increased at a later stage by adding power modules.

  • Page 25: Special Safety Warnings

    UPSaver installation and start-up SPECIAL SAFETY WARNINGS 2.3.1 General warnings The UPSaver UPS is provided with various stickers with indications regarding specific dangers. These stickers must be always well visible and replaced in case they are damaged. The present documentation must be always available in proximity to the device. In case of loss we recommend to request a copy to the manufacturer, whose details are available in the “Contacts”...

  • Page 26: Electrical Connection

    UPSaver installation and start-up  Never let a liquid or foreign body penetrate inside the device;  Never block the ventilation grates;  Never expose the device to direct sunlight or place it near a source of heat. Special environmental conditions The UPSaver UPS is designed for normal climatic and environmental operating conditions as defined in the technical specification: altitude, ambient operating...

  • Page 27: Operation

    UPSaver installation and start-up Check the conformity to the Standards The UPS must be installed in compliance with the standards in force in the country of installation. IT system The UPS is also designed to be connected to an IT power distribution system. All the electrical connections must be carried out by authorized personnel.

  • Page 28: Maintenance

    UPSaver installation and start-up The settings can only be changed using the original interface software. Injury hazard due to electric shock! During operation, the UPSaver UPS converts power characterized by high voltages and currents.  All the doors and the covers must remain closed. Injury hazard due to contact with toxic substances The battery supplied with the UPS contains small amounts of toxic materials.

  • Page 29: Storage

     fungus, insects, vermin. ENVIRONMENTAL PROTECTION 2.4.1 ISO 14001 certification Borri S.p.A. is particularly sensitive to the environmental impact of its products. That is why the UPSaver UPS has been manufactured with cutting-edge eco-design criteria (ISO 14001 certification). Special care was taken in using fully recyclable materials and in reducing the amounts of raw materials used.

  • Page 30: Installation

    UPSaver installation and start-up INSTALLATION RECEIPT OF THE UPS Please inspect the device before installing it. In case any damage is noticed from the conditions of the package and/or from the outside appearance of the equipment, contact the shipping company or your dealer immediately. The damage statement must be made within 6 days from receipt of the product and must be notified to the shipping carrier directly.

  • Page 31: Handling The Ups

    UPSaver installation and start-up HANDLING THE UPS The various parts composing the UPS are packed on wooden pallet; they are handled from the transport vehicle to the installation (or storage) place by a fork lift. The device has a heavy weight ...
  • Page 32 UPSaver installation and start-up Picture 4 – Handling of the I/O module In order to handle the power module remove the front and rear covers and the two front triangular supports which would otherwise obstruct the way to the fork lift's forks. Picture 5 –...
  • Page 33 UPSaver installation and start-up Picture 6 – Handling of the power module OMH44149 REV. C...

  • Page 34: Information For The Installation

    UPSaver installation and start-up INFORMATION FOR THE INSTALLATION The UPSaver UPS must be installed indoor, in a clean and dry room, preferably without dust or humidity infiltrations. For the environmental conditions in the place of installation, in compliance with the current legislation, please refer to the “Wall clearances and ventilation” section.

  • Page 35: Base Plan, Static Load And Weights

    UPSaver installation and start-up DSB  Distributed Static Bypass switch Each power module which compose the UPSaver UPS is provide with its own bypass static switch. 3.3.2 Base plan, static load and weights Picture 7 – Power module base plan Picture 8 –...
  • Page 36 UPSaver installation and start-up Picture 9 – 800-1200kVA I/O module base plan The previous picture, for what concern the 1200 kVA I/O module, is strictly related to the system configuration with distributed battery static switch (DB + DSB / DB + CSB). Picture 10 –...
  • Page 37 UPSaver installation and start-up Picture 11 – 1400kVA I/O module base plan Picture 12 – 1600kVA I/O module base plan OMH44149 REV. C...

  • Page 38: System Layout And Overall Dimensions

    UPSaver installation and start-up The supporting base of the UPS must be designed to carry the UPS weight and to ensure its steady and safe support. Its carrying capacity must be adequate to the static loads indicated in the table below. Weight Static load [kg]...
  • Page 39 UPSaver installation and start-up Picture 14 – UPSaver I/O module up to 600 kVA Picture 15 – UPSaver 800 kVA and 1200kVA (DB+DSB / DB+CSB) I/O module OMH44149 REV. C...
  • Page 40 UPSaver installation and start-up Picture 16 – UPSaver 1000-1200 kVA I/O module with centr. battery st. sw. (CB+DSB / CB+CSB) Picture 17 – UPSaver 1200 kVA I/O module top cable entry with centr. battery and distributed static switches (CB+DSB) OMH44149 REV. C...
  • Page 41 UPSaver installation and start-up Picture 18 – UPSaver 1400 kVA I/O module top cable entry with centr. battery and distributed static switches (CB+DSB) Picture 19 – UPSaver 1600 kVA I/O module with distributed static switches (DB+DSB) OMH44149 REV. C...
  • Page 42 UPSaver installation and start-up Picture 20 – I/O module breakers position (up to 800kVA) Picture 21 – I/O module breakers position (1000-1200kVA) OMH44149 REV. C...
  • Page 43 UPSaver installation and start-up Picture 22 – I/O module breakers position (1200-1400kVA) Picture 23 – I/O module breakers position (1600kVA) OMH44149 REV. C...
  • Page 44 UPSaver installation and start-up Picture 24 – I/O module distribution columns breakers position (up to 1200kVA) Picture 25 – 1400kVA I/O module distribution columns breakers position OMH44149 REV. C...
  • Page 45 UPSaver installation and start-up Picture 26 – 1600kVA I/O module distribution columns breakers position Picture 27 – 400kVA UPSaver layout Picture 28 – 600kVA UPSaver layout OMH44149 REV. C...
  • Page 46 UPSaver installation and start-up Picture 29 – 800kVA UPSaver layout Picture 30 – 1000kVA UPSaver layout Picture 31 – 1200kVA UPSaver layout OMH44149 REV. C...
  • Page 47 UPSaver installation and start-up Picture 32 – Battery centralized 1200kVA UPSaver layout Picture 33 – Battery centralized 1400kVA UPSaver layout Picture 34 – 1600kVA UPSaver layout OMH44149 REV. C...
  • Page 48 UPSaver installation and start-up UPSaver rating (kVA) Config. ↓ 1000 1200 1400 1600 CB+CSB 6400 4850 5450 CB+DSB Width (mm) 2350 2950 3900 DB+CSB 4500 5100 DB+DSB 7000 7600 Depth (mm) Height (mm) 2100 2150 The 1600kVA I/O module is provided of an additional iron frame (h = 50 mm) for the routing of the interconnection cables with the power modules.

  • Page 49: Wall Clearances And Ventilation

    UPSaver installation and start-up 3.3.4 Wall clearances and ventilation The UPS must be so installed as to ensure its serviceability and to allow a correct air flow as much as possible. With regard to the minimum distances from the walls, for all of the UPS sizes the same installation conditions apply as indicated in the table below.

  • Page 50: Environmental Installation Conditions

    UPSaver installation and start-up 3.3.5 Environmental installation conditions The air is classified by the EN 60721-3-3 standard (Classification of environmental parameters and their severities – Stationary use at weather-protected locations) based on climatic and biological conditions as well as on mechanically and chemically active substances. Therefore the place of installation must meet specific requirements to ensure compliance with the conditions for which the UPS was designed.
  • Page 51 UPSaver installation and start-up  Classification of chemically active substances (EN 60721-3-3) Class Environmental parameter 3C1R 3C1L Salt Salt Salt Sea salt 0,01 Sulphur dioxide [mg/m Hydrogen sulphide 0,0015 0,01 0,01 [mg/m 0,001 0,01 Chlorine [mg/m 0,001 0,01 ydrochloric acid [mg/m 0,001 0,003...

  • Page 52: System Positioning And Installation

    UPSaver installation and start-up SYSTEM POSITIONING AND INSTALLATION 3.4.1 Positioning the I/O module The UPSaver system can be positioned on an iron base specifically prepared and placed on the base of a floating floor. In this case the space underneath the UPS bearing surface is used as a opening to where the interconnection cables between the I/O module and the power modules can be laid.

  • Page 53: Floor Fixing

    UPSaver installation and start-up 3.4.2 Floor fixing The floor fixing method for the various modules which compose the UPSaver system varies depending on the UPS bearing surface, being it a concrete floor or a iron base. Picture 38 – Floor fixing Picture 39 –...

  • Page 54: Connection Of The Interconnection Cables

    UPSaver installation and start-up 3.4.3 Connection of the interconnection cables After having positioned the I/O module the cable routing bases (if provided) it is necessary to lay and connect the interconnection cables among the modules. The pictures which follow show the cable routing on the metal bases;...

  • Page 55: Positioning The Power Modules

    UPSaver installation and start-up Picture 42 – Routing of the interconnection cables 3.4.4 Positioning the power modules When the interconnection cables connection and routing are completed it is possible to proceed to the positioning of the power modules; pay attention to place the module in such a way that the fixing holes in the module frame coincide with the holes prearranged on the cables routing bases or on the iron base.

  • Page 56: Cabinets Alignment And Fixing

    UPSaver installation and start-up 3.4.5 Cabinets alignment and fixing Before connecting the power cables to the various modules it is strongly advised to align the cabinets and proceed with the mechanical fixing. The triangular metal supports placed laterally down at each cabinet are provided with threaded holes, specifically arranged to mechanically connect the frames.
  • Page 57 UPSaver installation and start-up Picture 46 – UPS cabinets upper fixing OMH44149 REV. C...

  • Page 58: Power Modules Electrical Connection

    UPSaver installation and start-up 3.4.6 Power modules electrical connection In order to connect the interconnection cables of the power module it is necessary to remove:  front socket cover (A);  terminals protection plate (B);  cables passage covering plate (C). In order to ease cables connection work it is advisable to remove the lower power conversion module (D) and the side protection plate (E).
  • Page 59 UPSaver installation and start-up Picture 49 – Power module cables terminals OMH44149 REV. C...
  • Page 60 UPSaver installation and start-up Interconnection terminals I/O module Power module  L1INP - Mx 1-L1  L2INP - Mx 1-L2 RECTIFIER  L3INP - Mx 1-L3  NING - Mx  L1BYP - Mx 2-L1  L2BYP - Mx 2-L2 BYPASS ...

  • Page 61: Connecting The Bus Cable

    UPSaver installation and start-up 3.4.7 Connecting the bus cable The connection of the bus cable is the last operation to be performed to accomplish the installation of the UPSaver system. For the cable routing specific raceways above the cabinet front doors are provided, that must be removed.
  • Page 62 UPSaver installation and start-up Picture 52 – Bus cable connection cards The cable must be connected so as to form a loop, thus to guarantee the first-fault system immunity. Picture 53 – Connecting the bus cable OMH44149 REV. C...
  • Page 63 UPSaver installation and start-up Once the cable has been connected, fix it to the cabinet upper cross-bars and put the metal raceways back in place. Picture 54 – Raceways re-positioning OMH44149 REV. C...

  • Page 64: Parallel Cards Dip-Switch Setting

    UPSaver installation and start-up 3.4.8 Parallel cards dip-switch setting The parallel card, where the bus cable is connected, is provided with dip-switches that are used to supply and/or terminate the data connection among the modules. Picture 55 – Detail of the parallel card dip-switches The dip-switches must be set according to the physical position of the device within the system.
  • Page 65 UPSaver installation and start-up All the other dips must be set as follows:  ON, all the dips of the two peripheral devices, being them the I/O module and one power module or two power modules;  ON, the dip 2 of DSW1; ...
  • Page 66 UPSaver installation and start-up Picture 57 – 800kVA UPSaver The configuration of the dip-switches must be as follows: MODULE DIP-SW DSW1 OMH44149 REV. C...

  • Page 67: Connecting The Signal Cables

    UPSaver installation and start-up 3.4.9 Connecting the signal cables The routing of the signal cables between the I/O module and the power modules can be carried out after the complete installation of the system. Simply for the matter of a easier execution of the routing it is recommended to lay the signal cables down before putting the power modules in place.
  • Page 68 UPSaver installation and start-up The signal terminal boards or connectors in the I/O module are located at the bottom of the right hand side distribution column, as indicated in the picture below. Picture 58 – I/O module signal position OMH44149 REV. C...

  • Page 69: Electrical Connection

    UPSaver installation and start-up ELECTRICAL CONNECTION The electrical connection is part of the work which is normally provided by the company that carries out the product installation. For this reason, the UPS manufacturer shall not be held responsible for any damages due to wrong connections. Use qualified personnel only All the operations related to the electric connection must be carried out by qualified and trained personnel.

  • Page 70: Connecting The Power Cables

    UPSaver installation and start-up Mains connection The connection to the mains must be carried out with protection fuses between the mains and the UPS. The use of differential protection devices in the line supplying the UPS is unadvisable. The leakage current to ground due to the RFI filters is rather high and it can cause spurious tripping of the protection device.
  • Page 71 UPSaver installation and start-up Details of the electrical connections Potenza (kVA) 1000 1200 1400 1600 Input fuses [A] Rectifier 1250 1600 1000 1250 1250 1600 Bypass 1000 1600 1000 1250 1600 1600 2000 Phase conductor cross sect. [mm Rectifier 2x150 2x300 3x240 4x240...

  • Page 72: Back-Feed Protection Device

    UPSaver installation and start-up BACK-FEED PROTECTION DEVICE The back-feed protection device is installed inside the I/O module on UPSaver systems with distributed static bypass switch. The device is a contactor for each power module, which automatically disconnects the bypass line in case of failure of the static switch, in order to avoid voltage feed-back on the input terminals during a mains failure.

  • Page 73: Terminal Boards

    UPSaver installation and start-up TERMINAL BOARDS The UPSaver UPS is provided with terminal boards, located inside the I/O module, for the connection of power cables and of the auxiliary connections. The cables entry can be provided either from the bottom or the top, on the basis of the plant requirements;...
  • Page 74 UPSaver installation and start-up Picture 61 – 600-800kVA UPSaver, I/O module neutral connection bar (bottom cables entry) Picture 62 – 600-800kVA UPSaver, I/O module earth connection bar (bottom cables entry) OMH44149 REV. C...
  • Page 75 UPSaver installation and start-up Picture 63 – 600-800kVA UPSaver, I/O module terminal boards (bottom cables entry) Picture 64 – 600-800kVA UPSaver, detail of the I/O module power terminals (bottom cables entry) OMH44149 REV. C...
  • Page 76 UPSaver installation and start-up Picture 65 – 600-800kVA UPSaver, I/O module neutral connection bar (top cables entry) Picture 66 – 600-800kVA UPSaver, I/O module earth connection bar (top cables entry) OMH44149 REV. C...
  • Page 77 UPSaver installation and start-up Picture 67 – 1200kVA UPSaver, I/O module terminal boards (bottom cables entry) Picture 68 – 1200kVA UPSaver, detail of the I/O module power terminals (bottom cables entry) OMH44149 REV. C...
  • Page 78 UPSaver installation and start-up Picture 69 – 1200kVA UPSaver, centralized battery power terminals (bottom cables entry) Picture 70 – 1200kVA UPSaver, I/O module neutral connection bar (bottom cables entry) OMH44149 REV. C...
  • Page 79 UPSaver installation and start-up Picture 71 – 1200kVA-1400kVA UPSaver, centralized battery power terminals (top cables entry) Picture 72 – 1600kVA UPSaver, detail of the I/O module power terminals OMH44149 REV. C...
  • Page 80 UPSaver installation and start-up Picture 73 – 1600kVA UPSaver, detail of the I/O module power terminals The 1600kVA I/O module, in its typical configuration, is arranged for input and putput power bus-bars, while for the bypass line and the batteries are used copper bars and terminals repsectively.

  • Page 81: Connection Bars Position

    UPSaver installation and start-up 4.3.1 Connection bars position The tables that follow indicates the distance of the connection bars from a defined reference point:  For bottom cables entry the distance is given from the ground (cabinet base)  For top cables entry the distance is given from the roof (cables entry plate) The distance is referred to the first available hole.
  • Page 82 UPSaver installation and start-up Top cables entry Distance from roof [mm] Connection Barra I/O 800kVA I/O 1200kVA I/O 1600kVA Rectifier Bypass UPS output Battery Rect. / Byp. / Out. Neutral 1010 Earth OMH44149 REV. C...

  • Page 83: Interface Cards

    UPSaver installation and start-up INTERFACE CARDS The UPS is provided with interface cards for the external communication of the operating status and parameters. Access to the card is possible opening the I/O module front door.  RS232/USB: used for connection to the proprietary programming and control software.

  • Page 84: Diesel Mode Activation

    UPSaver installation and start-up On the EXT-INP card the following signals can be connected:  Diesel Mode enabling contact (from Diesel Generator);  external bypass switch;  Remote shut-down contact (EPO);  Auxiliary contact of the centralized battery isolator. On the EXT-INP-3 card the following signals can be connected: ...

  • Page 85: Relay Card Connection

    UPSaver installation and start-up SRC-2 RELAY CARD CONNECTION The UPSaver is provided with a relay card for the remote repetition of operating statuses and alarms, named SRC-2. The connection of the user cables is made directly on the card terminals; the card is located in the area reserved to the I/O module interface cards. Status in Status in Relay...

  • Page 86: Startup And Shutdown

    UPSaver installation and start-up STARTUP AND SHUTDOWN Read the technical documentation Before installing and using the device, make sure you have read and understood all the instructions contained in the present manual and in the technical supporting documentation. Further information In the event that the information provided in this manual is not sufficiently exhaustive, please contact the manufacturer of the device, whose details are available in the “Contacts”...

  • Page 87: Start-Up Procedure

    UPSaver installation and start-up START-UP PROCEDURE First system start-up During the first start-up of the UPSaver system the I/O module and the power modules are configured and the system redundancy is defined. The first start-up is performed either by the manufacturer's technical personnel or authorized service centres.

  • Page 88: Picture 75 - Touch Screen Start-Up Image

    UPSaver installation and start-up Close the general switch RCB inside the I/O module. After some seconds the touch screen will start, which will shown the start-up screen with the UPSaver logo. Picture 75 – Touch screen start-up image Picture 76 – I/O module start-up After the software loading phase the control logic will acquire the system status and the operation of the RCB switch, and will give the first operating instruction as shown in the picture below.

  • Page 89: Picture 77 - Choice Of The Start-Up Mode

    UPSaver installation and start-up Picture 77 – Choice of the start-up mode Press on the NORMA STARTUP button. The NEW CONFIG. section is generally used during the first start-up and is reserved to trained personnel. Picture 78 – Module 1 start-up Close the switch RCB1 in order to start the module 1 control logic.

  • Page 90: Picture 79 - Module 1 Start-Up

    UPSaver installation and start-up Picture 79 – Module 1 start-up Picture 80 – Module 1 start-up The module 1 rectifier and inverter are started in sequence; once these phases are completed the battery voltage is checked and the green lamp located next to the battery switch BCB1 will turn on.

  • Page 91: Picture 81 - Module 1 Start-Up

    UPSaver installation and start-up Picture 81 – Module 1 start-up Operation on BCB switch The switches BCBx, located in the distribution column, can only be closed if the relevant green lamp is on. Serious damages both to the battery and the equipment may occur if the breaker is closed before the front panel requires it.

  • Page 92: Picture 83 - Module 1 Start-Up

    UPSaver installation and start-up Close OCB1 to connect the module 1 output to the I/O module common output bus. Picture 83 – Module 1 start-up Press the button SBCB1 to supply the module 1 bypass line and wait for the closure of the back-feed contactor located inside the I/O module.

  • Page 93: Picture 85 - Module "N" Start-Up

    UPSaver installation and start-up Picture 85 – Module "n" start-up Picture 86 – Module "n" start-up Once the module 1 is started (or the following module in case the module 1 had been skipped), the sequence will go on repeating the same operations, until the last module is started.

  • Page 94: Picture 87 - Battery Start-Up

    UPSaver installation and start-up Picture 87 – Battery start-up All the modules are now started and connected, either to their own battery (DB, distributed battery configuration) or in parallel to the common DC bus in the I/O module (CB, centralized battery configuration). Close the battery switch BCB (external) in order to connect the centralized battery (CB) to the UPSaver system.

  • Page 95: Picture 89 - Start-Up Completed

    UPSaver installation and start-up Picture 89 – Start-up completed Picture 90 – Flow diagram At the end of the start-up sequence the touch screen shown the system flow diagram with the main parameters shown next to each supply source. OMH44149 REV. C...

  • Page 96: Shut-Down Procedure

    UPSaver installation and start-up SHUT-DOWN PROCEDURE It is advisable to shut-down the UPSaver system by using the emergency power off push- button (EPO) and then proceed to open the general switches OCB, SBCB, BCB and RCB. Operating the EPO push-button allows the control logic to stop the system in a controlled manner, so that whatever operation will follow, it will be done in complete safety.

  • Page 97: Restart From Manual Bypass

    UPSaver installation and start-up RESTART FROM MANUAL BYPASS Before restarting the UPS from manual by-pass, make sure the Bypass_Sw selector is in BYPASS position and the MBCB isolator is closed. Close the general switch RCB inside the I/O module. After some seconds the touch screen will start, which will shown the start-up screen with the UPSaver logo.

  • Page 98: Picture 93 - Module 1 Start-Up

    UPSaver installation and start-up Close the switch RCB1 in order to start the module 1 control logic. The module start-up can be skipped by pressing the SKIP button; the display will immediately switch to the following module. The skipped module can be started at a later stage using the Module insertion procedure.

  • Page 99: Picture 95 - Module 1 Start-Up

    UPSaver installation and start-up In case of centralized static bypass switch configuration (CSB, single static switch located inside the I/O module) such phase is not present, since the bypass line is not connected to the power modules. Picture 95 – Module 1 start-up Once the bypass line is started the battery voltage is checked and the green lamp located next to the battery switch BCB1 will turn on.

  • Page 100: Picture 96 - Module 1 Start-Up

    UPSaver installation and start-up Picture 96 – Module 1 start-up Close OCB1 to connect the module 1 output to the I/O module common output bus. Picture 97 – Module 1 start-up OMH44149 REV. C...

  • Page 101: Picture 98 - Module "N" Start-Up

    UPSaver installation and start-up Picture 98 – Module "n" start-up Picture 99 – Module "n" start-up Once the module 1 is started (or the following module in case the module 1 had been skipped), the sequence will go on repeating the same operations, until the last module is started.

  • Page 102: Picture 100 - Start-Up From Mbcb

    UPSaver installation and start-up Picture 100 – Start-up from MBCB All the modules are now started and connected, either to their own battery (DB, distributed battery configuration) or in parallel to the common DC bus in the I/O module (CB, centralized battery configuration). Close the battery switch BCB (external) in order to connect the centralized battery (CB) to the UPSaver system.

  • Page 103: Picture 102 - Start-Up From Mbcb

    UPSaver installation and start-up Picture 102 – Start-up from MBCB Picture 103 – Inverters start-up Opening MCB will enable the start-up of all the power modules' inverters, which will start and synchronize with the bypass line. OMH44149 REV. C...

  • Page 104: Picture 104 - Inverters Start-Up

    UPSaver installation and start-up Picture 104 – Inverters start-up Move the Bypass-SW selector to the NORMAL position per to transfer the load to the inverter. Picture 105 – Start-up from MBCB completed At the end of the start-up sequence the touch screen shown the system flow diagram with the main parameters shown next to each supply source.

  • Page 105: Starting-Up A Power Module

    UPSaver installation and start-up STARTING-UP A POWER MODULE Starting-up a power module from the "completely off" condition is possible by simply following the indications given by the touch screen, according to the following procedure. From the Home page (flow diagram), press on the power module which is supposed to be started.

  • Page 106: Picture 108 - Module Start-Up Confirmation

    UPSaver installation and start-up Press on the START button and confirm the operation in the following page. Picture 108 – Module start-up confirmation The rectifier and inverter are started in sequence. Picture 109 – Module start-up OMH44149 REV. C...

  • Page 107: Picture 110 - Module Start-Up

    UPSaver installation and start-up Picture 110 – Module start-up Picture 111 – Module start-up Once these phases are completed the battery voltage is checked and the green lamp located next to the battery switch BCBx will turn on. Close the switch BCBx as requested.
  • Page 108 UPSaver installation and start-up Operation on BCB switch The switches BCBx, located in the distribution column, can only be closed if the relevant green lamp is on. Serious damages both to the battery and the equipment may occur if the breaker is closed before the front panel requires it. Picture 112 –...
  • Page 109 UPSaver installation and start-up Press the button SBCBx to supply the module 1 bypass line and wait for the closure of the back-feed contactor located inside the I/O module. In case of centralized static bypass switch configuration (CSB, single static switch located inside the I/O module) such phase is not present, since the bypass line is not connected to the power modules.
  • Page 110 UPS user manual UPS USER MANUAL Index     APPLICABILITY .................. 7     SAFETY RULES AND WARNINGS ............ 8     GENERAL UPS DESCRIPTION ............9 3.1  POWER MODULE (BPU) ................... 10  3.1.1  Rectifier / Battery-charger ................10  3.1.2  Inverter .......................
  • Page 111 UPS user manual 4.1  ICONS ......................... 23  4.1.1  Icons colours ..................... 24      TOUCH SCREEN – MANAGING THE UPS........25 5.1  DISPLAYING THE MEASURES ................. 25  5.2  BASIC DIAGNOSTICS ....................27  5.2.1  Displaying the operating status ............... 27  5.2.2  Icons colours .....................
  • Page 112 UPS user manual 5.4.3.4  Parallel type ....................48  5.4.3.5  Message statistics ..................48  5.4.4  Firmware release ....................48  5.4.5  Service information ..................49  5.4.6  Communication information ................49  5.4.7  LINE INTERACTIVE mode information ............49      TOUCH SCREEN – MANAGING THE POWER MODULES ..... 50 6.1 ...
  • Page 113 UPS user manual Index of the pictures     Picture 1 – 1200 kVA UPSaver typical block diagram ................9     Picture 2 – Power module (BPU) block diagram ..................10     Picture 3 – 1200 kVA UPSaver, "CB+CSB" configuration ..............11  ...
  • Page 114 UPS user manual     Picture 37 – LAN parameters setting ......................39     Picture 38 – NTP parameters setting ......................39     Picture 39 – TCP/IP ports setting ......................40     Picture 40 – Modification of numerical parameters ................... 40  ...
  • Page 115 UPS user manual OMH44150 REV. B...
  • Page 116 UPS user manual APPLICABILITY The instructions contained in the operating manual are applicable to the UPS systems of the UPSaver series, in all their possible power configurations. Storing documentation This manual and any other supporting technical documentation relating to the product must be stored and made accessible to personnel in the immediate vicinity of the UPS.
  • Page 117 UPS user manual SAFETY RULES AND WARNINGS Injury hazard due to electric shock! Always respect all the safety instructions and, in particular:  any work on the unit must be carried out by qualified personnel;  internal components can only be accessed after disconnecting the device from supply sources;...
  • Page 118 UPS user manual GENERAL UPS DESCRIPTION UPSaver is a completely adaptable multi-functional, high-efficiency structured system for the protection of the energy supply. The system flexibility is achieved by using hot-swappable power modules in order to easily expand the system power up to 1600 kVA. The UPSaver power modules uses IGBT technology with a high changeover frequency in order to allow a low distortion of the current re-injected into the supply line, as well as high quality and stability of output voltage.
  • Page 119 UPS user manual POWER MODULE (BPU) The power module, part of the UPSaver UPS, is composed of the following main sections:  rectifier / battery-charger;  inverter;  battery static switch;  inverter and bypass static switches. Picture 2 – Power module (BPU) block diagram The power module is not provided with isolator switches, which are all installed in the distribution columns of the I/O module.
  • Page 120 UPS user manual 3.1.3 Battery static switch The battery static switch consists of two diode-SCR couples connected in anti-parallel, one for each polarity, and allows to control the connection and disconnection of the battery to the DC bus, in order to reduce the losses and optimize the battery expected lifetime. 3.1.4 Bypass static switch The Static Bypass allows to transfer the load between Inverter and Emergency Mains, and vice-versa, in a very short time, and uses SCR’s as power commutation elements.
  • Page 121 UPS user manual Picture 4 – UPSaver "CB+CSB", power module configuration Neither the bypass nor the battery static switches are installed in the power module (BPU). 3.2.2 "CB+DSB" configuration Picture 5 – 1200 kVA UPSaver, "CB+DSB" configuration In the "CB+DSB" configuration the battery bank is single for the whole UPSaver system, and is connected to the I/O module common DC bus.
  • Page 122 UPS user manual 3.2.3 "DB+CSB" configuration Picture 7 – 1200 kVA UPSaver, "DB+CSB" configuration In the "DB+CSB" configuration the battery is distributed, that is each power module is provided with its own battery and battery static switch, which are independent from the others. The isolators BCBx, located in the distribution colums at the sides of the I/O module, directly connects the DC bus of each module to its battery.
  • Page 123 UPS user manual In the "DB+DSB" configuration the battery is distributed, that is each power module is provided with its own battery and battery static switch, which are independent from the others. The isolators BCBx, located in the distribution colums at the sides of the I/O module, directly connects the DC bus of each module to its battery.
  • Page 124 UPS user manual The AC loads are directly supplied from the inverter output, that is the parallel of the inverters of the single power modules (BPU). When the Green Conversion algorithm is active the rectifier operates at reduced DC voltage and supplied the inverter alone, since the battery is disconnected from the DC bus.
  • Page 125 UPS user manual Picture 13 – Battery discharging In case the supply is restored before the battery is completely discharged, the system will be switched back to normal operation automatically. In the opposite case, the inverter shuts down and the load is switched to the bypass line (bypass operation). If the bypass line is not available or is out of tolerance, the loads supply is interrupted as soon as the battery reaches the discharge limit threshold (black-out).
  • Page 126 UPS user manual redundancy algorithm, which has been explained previously, therefore is is activated only if the output load is such to allow to have at least one power module off to be used as "reserve". 3.3.2 VHE mode – Very High Efficiency (Line Interactive) In the VHE mode the load is supplied by the mains via the static bypass switch;...
  • Page 127 UPS user manual 3.3.4 UHE mode – Ultra High Efficiency Picture 16 – UHE mode The UHE mode is the one that guarantees the higher efficiency, since during the normal operation all the system power converters (rectifier and inverter) are off and the loads are directly supplied by the mains via the static switch.
  • Page 128 UPS user manual 3.3.5 Manual bypass The manual bypass operation is necessary whenever the UPS functionality is tested, or during maintenance or repair work. Picture 18 – Manual bypass In such condition all the switches are generally open, both the general switches and those related to each power module, and the only closed isolator is MBCB.
  • Page 129 UPS user manual CONTROL AND OPERATION DEVICES The control and operating devices of the UPS are listed below.  Rectifiers input line isolator (RCBS)  Bypass input line isolator (SBCBS)  UPS output isolator (OCBS)  Manual bypass isolator (MBCBS) ...
  • Page 130 UPS user manual Isolating the power modules The power modules isolating devices are located inside the I/O module, therefore the modules are isolated from the input/output sources when the isolators are open. before carrying out any maintenance operation on the power modules let the capacitors discharge for at least 5 minutes.
  • Page 131 UPS user manual 3.4.5 Touch screen control panel The UPS control panel is used for:  Verifying the device operating parameters  Accessing the events log  Displaying the device information  Modifying the operating parameters The section through which the parameters can be modified is password-protected in order to avoid the access by non-authorized personnel.
  • Page 132 UPS user manual CONTROL PANEL The UPS control panel is a 10.1" touch screen which dialogues with the I/O module control logic via ModBus protocol. The main page (Home) shows the system flow diagram, from which all the UPSaver UPS operating variables, as well as those of each single power module (BPU) that compose the system, can be displayed.
  • Page 133 UPS user manual The panel also contains touch-sensitive areas in correspondence to the diagrams of the power modules. The pages related to the module can be opened by pressing the module itself. 4.1.1 Icons colours The icons can take on different colours on the basis of the UPS operating condition; in general the basic colours are: ...
  • Page 134 UPS user manual TOUCH SCREEN – MANAGING THE UPS The UPS operating parameters can be managed by entering the various sections of the control panel from the Home page directly. DISPLAYING THE MEASURES Press on the Measures icon to enter the main page. Picture 20 –...
  • Page 135 UPS user manual The list of all the available measures is given below. Sub-page Displayed data Accuracy Rectifier input voltage Rectifier input current INPUT Frequency 0,1 Hz Input power 1 kVA Voltage Current Load percentage OUTPUT Active power 1 kW Apparente power 1 kVA Frequency...
  • Page 136 UPS user manual BASIC DIAGNOSTICS Pressing the Alarms icon will open the page where either the UPS operating status or the history log can be selected. Picture 22 – ALARMS section 5.2.1 Displaying the operating status Press UPS status to show the UPS operating status, which includes possible active alarms. Picture 23 –...
  • Page 137 UPS user manual 5.2.2 Icons colours The icons Alarms and Home take on different colours on the basis of both the UPS operating condition and the displayed page. Icon Colour Meaning Light blue No active alarms Dark blue No active alarms Grey A page of the Alarms section is currently displayed Active alarm;...
  • Page 138 UPS user manual The first event shown is the latest one in order of time; a new event makes all the other events automatically shift one position, clearing the oldest event. Each line shows the number of the event (position within the list), the alarm code and date and time;...
  • Page 139 UPS user manual The text file that will be saved contains the same information available on the History pages, completed with the decription of each event. 5.2.4 Alarms and operating status ALLARMI MAINS FAULT ASYMMETRIC LOAD INPUT WRONG SEQUENCE SERVICE REQUIRED BOOSTER STOPPED DIESEL MODE BOOSTER FAULT...
  • Page 140 UPS user manual STATUS BOOSTER OK RECTIFIER STANDBY BATTERY OK INVERTER STANDBY INVERTER OK BATTERY STANDBY INVERTER  LOAD BATTERY DISCHARGING INVERTER BYPASS SYNCHRONIZED BATTERY IN CHARGE (I) BYPASS OK BATTERY IN CHARGE (I) BYPASS  LOAD GREEN CONVERSION INVERTER MASTER GROUPS SYNC. LINE INTERACTIVE INVERTER MODULES SYNCHRONIZED Display and recording mode of alarms...
  • Page 141 UPS user manual SETTINGS AND ADVANCED OPERATIONS Pressing the Settings icon will show the setting section access page, protected by password. Picture 27 – Access password to the Settings section Picture 28 – SETTINGS section, page 1 The arrow in the upper main bar indicates that the section contains further pages. OMH44150 REV.
  • Page 142 UPS user manual Picture 29 – SETTINGS section, page 2 Password-protected access The SETTINGS menu is protected by a password set by the factory in order to prevent access to unauthorized personnel.  We recommend minimum disclosure of the access password. ...
  • Page 143 UPS user manual  System restart after a shutdown due to EPO activation Several specific blocking conditions of the power modules can only be cleared by directly entering the Settings section of the modules (see relevant paragraph). For a description of the UPS status in each of the failure conditions listed above, please refer to the “Faults and alarms”...
  • Page 144 UPS user manual Picture 31 – Clock automatic setting The NTP server access parameters can be configured via the Network configuration pages in the Settings section. In case the server does not respond or the LAN connection is lacking, the message NTP ERROR will be displayed. 5.3.3 Setting the display language The following picture shows the languages that can be set.
  • Page 145 The Teleservice port is reserved to the interface with a dedicated converter for the integration within the BORRI teleservice system; the other two ports are available for the user. 5.3.6 New centralized battery The page NEW CENTR BATT is used in case battery circuit breaker BCB is not closed, when requested, in the start-up phase.
  • Page 146 UPS user manual 5.3.7 Setting the centralized battery In case the UPS has been tested without knowing the characteristic data of the storage battery, the CENTR BATT SETTING section allows to set such data. Each single settable parameter can be accessed via the following page. Picture 34 –...
  • Page 147 UPS user manual 5.3.8 Centralized battery test The CENTR BATT TEST section allows to carry out a short discharge test of the battery. In case the battery is not efficient, the alarm “A10 – Battery fault” is generated at the end of the test.
  • Page 148 UPS user manual Picture 37 – LAN parameters setting 5.3.9.2 Setting the NTP parameters The NTP service parameters which can be set are the following:  Primary NTP server address  Primary NTP server address  NTP Enabling / Disabling Picture 38 –...
  • Page 149 UPS user manual 5.3.9.3 Setting the ModBus TCP/IP and RS485 parameters This screen allows the setting of the TCP/IP port on which the display answers via ModBus TCP/IP protocol. The address of the ModBus RS485 port can also be set. Picture 39 –...
  • Page 150 UPS user manual Picture 41 – Modification of NTP address parameters 5.3.10 Bypass Switch status The section BYPASS SWITCH STATUS replies the operation of the Bypass_SW selector, which allows the system commutation from inverter to the bypass mains and vice-versa. Picture 42 –...
  • Page 151 UPS user manual Picture 43 – Confirmation of load transfer Load transfer operation The load transfer operation is reserved to skilled personnel. It is recommended to operate under the supervision of manufacturer's personnel or following its specific indications. The manufacturer cannot be considered liable for any damages due to incompetence or inexperience of the customer's authorized personnel.
  • Page 152 UPS user manual 5.3.12 Modifying the modules redundancy logic The section PARALLEL MODULES allows the modification of the redundancy logic of the power modules. Such operation is reserved to personnel who have had a specific training on the product. Modifying the power modules redundancy logic The modification of the modules redundancy logic is reserved to skilled personnel.
  • Page 153 UPS user manual conditions are fulfilled (see LINE INTERACTIVE section of the INFO menu) the activation of such operating mode depends on how the parameter is set. In the AUTOMATIC mode the system manages independently the activation and de- activation of the LINE INTERACTIVE mode. In case of alarms, or parameters out of tolerance, the system restores the on-line double conversion mode and the LINE INTERACTIVE mode is resumed when the activation conditions are fulfilled again.
  • Page 154 UPS user manual SYSTEM INFORMATION The INFO section provides general information about the UPS; press the related icon to open the main page. Picture 44 – INFO section All the data shown in the varius sections are set during the factory test via a specific interface software and cannot be modified by anyone, except for personnel authorized by the manufacturer.
  • Page 155 UPS user manual Sub-page Displayed data Serial number assigned by the manufacturer and by SERIAL NUMBER a possible OEM distributor DEVICE TYPE Device type (ON LINE, ECO,ecc.) It may be SINGLE, or PARALLEL in case the MODE OPERATION system is in parallel with other UPSaver UPS's RUNNING HOURS Equipment operating hours CLOCK...
  • Page 156 UPS user manual 5.4.3 Parallel information The page containing the information about the parallel is only enabled if the UPS is in parallel with other UPSaver systems. Picture 47 – Parallel information 5.4.3.1 Parallel index The first number identifies the position of that specific UPS within the parallel system. The second number represents the total number of UPSaver units.
  • Page 157 UPS user manual Picture 48 – Parallel bus communication status 5.4.3.4 Parallel type The string may have two values, “POWER” or “REDUNDANT+x”.  POWER means that the parallel system is so set as to require the presence of all the UPS units to feed the load.
  • Page 158 UPS user manual 5.4.5 Service information The SERVICE menu provides important information regarding the technical service on the UPS. The information is displayed via a text string which chows the contact main details. However, please also see the addresses and contact numbers indicated in the present manual 5.4.6 Communication information The COMMUNICATION section provides information about the settings of the three...
  • Page 159 UPS user manual TOUCH SCREEN – MANAGING THE POWER MODULES The power modules operating parameters can be managed by entering the various sections of the control panel by pressing the picture of the module from the Home page flow diagram. Picture 51 –...
  • Page 160 UPS user manual The measures page of a specific section of the module is entered pressing one of the arrows. The available measures are the same as those related to the UPSaver system that can be displayed from the Home page. The module battery measures are only available if the system is configured with distributed battery (DB).
  • Page 161 UPS user manual The audible indicator, if enabled, is activated to show the occurred failure. The audible alarm is silenced by pressing the Alarms icon. Automatic erasure of alarms Should an alarm occur and then the conditions that originated it no longer exist, the alarm will be automatically cancelled and the system restarted.
  • Page 162 UPS user manual STATI BOOSTER OK INVERTER OK INVERTER  LOAD BATTERY DISCHARGING INVERTER BYPASS SYNCHRONIZED BATTERY IN CHARGE (I) BYPASS OK BATTERY IN CHARGE (U) BYPASS  LOAD INVERTER MASTER SYNCHRONIZED Display and recording mode of alarms  The statuses are always displayed in ascending order when the ALARMS – STATUS menu is entered.
  • Page 163 UPS user manual SETTINGS AND ADVANCED OPERATIONS Pressing the Settings icon will show the setting section access page, protected by password. The password access page is the same as the one described in the paragraph related to the Settings section of the whole UPS. Picture 54 –...
  • Page 164 UPS user manual  Booster shutdown due to the operation of the load symmetry sensor (alarm A33)  Inverter shutdown due to voltage control loop error (alarm A39)  Booster shutdown due to voltage control loop error (alarm A41)  Booster shutdown due to current control loop error (alarm A43) ...
  • Page 165 UPS user manual 6.3.4 New battery The page NEW BATTERY is used in case battery circuit breaker BCB is not closed, when requested, in the start-up phase. In this case the system will start considering the battery completely discharged and activating the alarm “A10 – BATTERY FAULT”. To set the battery autonomy to 100% it is necessary to access the section and confirm the operation in the confirmation page.
  • Page 166 UPS user manual POWER MODULE INFORMATION The INFO section provides general information about the power module; press the related icon to open the main page. Picture 56 – INFO section, power module All the data shown in the varius sections are set during the factory test via a specific interface software and cannot be modified by anyone, except for personnel authorized by the manufacturer.
  • Page 167 UPS user manual FAULTS AND ALARMS As indicated in the previous chapters, the system is provided with basic diagnostics which allow immediate visualization of the operating conditions. L'icona Allarmi diventa rossa e viene attivato il segnalatore acustico (se abilitato). Nella pagina Stato UPS vengono visualizzati il codice alfanumerico dell’allarme e una breve descrizione dello stesso.
  • Page 168 UPS user manual OPERATING STATUS DEFINITION Status BOOSTER OK Description The rectifier section is working properly. Operating The rectifier supplies the inverter and keeps the battery charged. condition Status BATTERY OK Description The battery is connected to the UPS. Operating The battery is kept charged by the rectifier and is ready to feed the condition inverter.
  • Page 169 UPS user manual Status INVERTER MASTER GROUPS SYNCHRONIZED Description The UPSaver system is synchronized with the UPSaver MASTER system with which it is in parallel. Operating This status is only present on the SLAVE UPSaver units, and shows condition that the inverter is sync with the signal sent by the MASTER UPSaver. Status INVERTER MODULES SYNCHRONIZED Description...
  • Page 170 UPS user manual Status BATTERY IN CHARGE (U) Description The battery is charging. Operating The battery static switch is closed and the battery is in the second and condition final phase of the I/U charging mode (DIN 41773), with constant voltage and decreasing current.
  • Page 171 UPS user manual TROUBLESHOOTING Alarm MAINS FAULT Description The voltage or frequency of the input line are out of tolerance.  Mains instability or failure. Possible causes  Wrong phase rotation. Solutions 1. Check the connections to the mains. 2. Check the stability of mains voltage. 3.
  • Page 172 UPS user manual Alarm DC VOLTAGE FAULT Description The measured DC voltage is out of tolerance.  The battery has reached the discharge voltage due to a power Possible causes failure.  Measuring circuit failure. Solutions 1. Check the actual value of the measured DC voltage. 2.
  • Page 173 UPS user manual Alarm BATTERY AUTONOMY END Description The battery has reached the pre-alarm discharge level.  The battery is discharging due to a mains failure. Possible causes  Rectifier failure. Solutions 1. Check which alarms are present and carry out the indicated procedures.
  • Page 174 UPS user manual Alarm INVERTER OUT OF TOLERANCE Description The inverter voltage or frequency are out of tolerance.  Inverter shutdown due to an alarm. Possible causes  Inverter failure. Solutions 1. Check which alarms are present and carry out the indicated procedures.
  • Page 175 UPS user manual Alarm RETRANSFER BLOCKED Description The load is blocked on the bypass line.  Very frequent changeovers due to load in-rush currents. Possible causes  Static switch problems. Solutions 1. Reset the system. 2. Check the in-rush currents of the loads. 3.
  • Page 176 UPS user manual Alarm THERMA IMAGE Description The thermal image protection has been activated after an extended inverter overload. The inverter is shut down for 30 minutes and then restarted.  Output overload. Possible causes  Measuring circuit failure. Solutions 1.
  • Page 177 UPS user manual Alarm INVERTER OFF Description The inverter is blocked due an operation failure.  Various. Possible causes Solutions 1. Reset the system. 2. If the alarm persists, contact our Technical Support Service. Alarm COMMUNICATION ERROR Description Internal error. ...
  • Page 178 UPS user manual Alarm COMMON ALARM Description Common alarm.  At least one alarm is present. Possible causes Solutions 1. Check which alarms are present and carry out the indicated procedures. Alarm MBCB BUS CLOSED Description The modules acquire the closing signal from the manual bypass isolator.
  • Page 179 UPS user manual Alarm SERVICE REQUIRED Description A UPS check is necessary.  Possible UPS fault. Possible causes Solutions 1. If the alarm persists, contact our Technical Support Service. Alarm DIESEL MODE Description The UPS is supplied by the diesel generator. ...
  • Page 180 UPS user manual INVERTER  LOAD Alarm Description The load is fed by the inverter. This alarm is active for UPS systems in ECO / VHE / UHE mode, where the preferential supply is from the bypass line.  Temporary changeover due to bypass line failure. Possible causes Solutions...
  • Page 181 UPS user manual   Alarm BCB IOBM OPEN Only on IOBM Description The battery general isolator (centralized battery) is open.  Battery isolator open. Possible causes Solutions 1. Check the status of the battery isolator. 2. Check the functionality of the auxiliary contact of the isolator. 3.
  • Page 182 UPS user manual Alarm HIGH TEMPERATURE SSW Description High temperature of the heat sink on the static switch.  Fault of the heat sink cooling fans. Possible causes  The room temperature or cooling air temperature is too high. Solutions 1.
  • Page 183 UPS user manual Alarm 1 PARALLEL CABLE DISCONNECTED Description The systems has detected the disconnection in one point of the parallel bus cable.  Parallel cable disconnected or damaged. Possible causes Solutions 1. Verify the connection of the bus cables. 2.
  • Page 184 UPS user manual   Alarm 2 PARALLEL CABLES DISCONNECTED Only on IOBM Description The systems has detected the disconnection in two points of the parallel bus cable.  DIsconnection of the parallel cable in two separate points. Possible causes Solutions 1.
  • Page 185 UPS user manual Alarm UHE BLOCKED Description The UHE mode is blocked.  Anomaly of the system control. Possible causes Solutions 1. Contact our Technical Support Service.   Only on IOBM Alarm POWER SUPPLY REDUNDANCY LOST Description One of the power supply cards is defective. ...

This manual is also suitable for:

Upsaver 600 kvaUpsaver 800 kvaUpsaver 1000 kvaUpsaver 1200 kvaUpsaver 1400 kvaUpsaver 1600 kva

Table of Contents
