- Page 1 SCA14000 (COBALT) INSTALLATION MANUAL Read the manual thoroughly before operation and retain for future reference. REV SCA14000-IM-03...
-
Page 3: Table Of Contents
SCA14000 Cobalt Installation Guide TABLE OF CONTENTS DISCLAIMER ---------------------------------------------------------------------- 2 SAFETY PRE CAUTIONS ----------------------------------------------------- 3-6 FEATURES AND SPECIFICATIONS ---------------------------------------- 7 WHAT’S INCLUDED ---------------------------------------------------------- 8-9 INSTALLATION BOM LIST --------------------------------------------------- 10 INSTALLATION REMARKS ---------------------------------------------- 11-13 ELECTRICAL SUPPLY REMARKS ---------------------------------------- 14 NSTALLATION INSTRUCTIONS --------------------------------------- 15-20... -
Page 4: Disclaimer
For Commercial or Industrial Use Only. DIRECTIONS FOR USE Follow the instructions to ensure proper installation. The display panel will turn on and the “Surgically Clean Air™” LED will light up if the unit is powered on. DISPOSAL INSTRUCTIONS Dispose of filters according to local regulations based on the location of use (e.g., medical waste if used in a medical... -
Page 5: Safety Precautions
SCA14000 Cobalt Installation Guide SAFETY PRECAUTIONS FIRST AID INSTRUCTIONS In case of injury, clean the area using soap and warm water, apply antibiotic ointment and a bandage, and seek immediate medical attention. OPERATING ENVIRONMENT CAUTIONS • DO NOT place in rooms with high heat, damp, or wet places. - Page 6 SCA14000 Cobalt Installation Guide SAFETY PRECAUTIONS WARNING – THIS DEVICE SHOULD NOT BE USED IN A CONSTRUCTION ZONE. Extensive amounts of particulates such as construction dust and debris will clog up the filter and impact the efficiency of the unit. If construction needs to be conducted in an area where Cobalt units are installed, it is recommended that the unit is turned off.
- Page 7 SCA14000 Cobalt Installation Guide SAFETY PRECAUTIONS WARNING – TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT expose to water or rain. – RISK OF FIRE OR ELECTRIC SHOCK, DO NOT use this equipment with any solid-state speed control device.
- Page 8 SCA14000 Cobalt Installation Guide SAFETY PRECAUTIONS CARE AND MAINTENANCE/ SERVICING CAUTIONS WARNING – RISK OF FIRE. Never operate the air purifier in a space that contains flammable gases. Never use the equipment to extract or filter flammable, blazing or burning particles, chemicals, or liquids. Never use the unit to extract or filter hostile vapors or sharp particles.
-
Page 9: Features And Specifications
SCA14000 Cobalt Installation Guide FEATURES AND SPECIFICATIONS The device features: Automatic Proximity Sensor On/Off Automatic Timer Remote Control Model No. SCA14000–2x4 Power Requirement 120V, 60 Hz Rated Power 250 W, 2.1A Fan Motor 310 VDC, 0.98 A, 113 W Dimensions (L) 1245.0 mm x (W) 636.0 mm x (H) 360.0 mm... -
Page 10: What's Included
SCA14000 Cobalt Installation Guide WHAT’S INCLUDED MAIN PRODUCT Below items are included with the SCA14000 air purifier: Cobalt Unit H13 Filters (x2), included in the unit Mount Bracket (x4) ¼” Screws (x8) Remote Control Remote Control AAA Battery (x2) - Page 11 SCA14000 Cobalt Installation Guide WHAT’S INCLUDED The below accessories are available as alternative installation options. These components are not included in the main package, and need to be purchased separately: WALL-MOUNT ACCESSORIES The below accessories are provided for wall-mount installation option:...
-
Page 12: Installation Bom List
SCA14000 Cobalt Installation Guide INSTALLATION BOM LIST (NOT INCLUDED IN PACKAGING) Below items are required for the SCA14000: INSTALLATION TYPE NAME REMARK Concrete Ceiling/ ⅜” Threaded Rod Hanging Bar I-Beam Ceiling 100+ lbs. rated ⅜” Expansion Bolt Concrete Ceiling Expansion Bolt 100+ lbs. -
Page 13: Installation Remarks
SCA14000 Cobalt Installation Guide INSTALLATION REMARKS The SCA14000 is designed to be installed as a fixed built-in unit by a qualified installer. In addition to the following instructions the SCA14000 shall be installed: ANSI/NFPA 70 In the United States, in accordance with the National Electric Code/State, and Municipal codes •... - Page 14 SCA14000 Cobalt Installation Guide INSTALLATION REMARKS • The Cobalt unit can be hoisted from the concrete ceiling or the I-beam. Ensure the unit is being installed level in both directions. • • Follow ceiling tile system manufacturer instructions for integration compatibility.
- Page 15 SCA14000 Cobalt Installation Guide INSTALLATION REMARKS CHOOSING THE LOCATION • Choose a location with the following conditions: Indoor Space Operating Temperature: 50 -104 °F (10 – 40 °C), Relative Humidity: <75% • Built-in fixed units must be unobstructed from the front.
-
Page 16: Electrical Supply Remarks
SCA14000 Cobalt Installation Guide ELECTRICAL SUPPLY REMARKS • The customer has the responsibility to ensure that the unit installation is in compliance with all national and local electrical and building codes and ordinances. The electrical supply which the unit is designed for is 120VAC, 60 Hz. -
Page 17: Nstallation Instructions
SCA14000 Cobalt Installation Guide INSTALLATION INSTRUCTIONS CONCRETE CEILING 1. Determine the installation location; the reinforced concrete ceiling must be selected for installation. 2. Draw rectangles at the installation position with dimensions as follows： - SCA14000–2x4: 1037mm*490mm - SCA14000–2x2: 490mm*490mm The four vertices of the rectangle are the anchor points for installing the expansion screw. - Page 18 SCA14000 Cobalt Installation Guide 3. Use an electric hammer to drill holes in four anchor points, ensuring a minimum depth of two inches into the slab and install expansion screws.
- Page 19 SCA14000 Cobalt Installation Guide 4. Drive the expansion screw, screw in the threaded rod, and then screw in the four Nuts, where nut 3 is next to nut 4. The position of each screw should be at the same height from the ceiling.
- Page 20 SCA14000 Cobalt Installation Guide 6. Using a level in both directions, adjust nut 3 and nut 4 to ensure the machine is leveled horizontally. Finally tighten nuts 3 and 4 to fix the machine place, connect the power to complete the installation.
-
Page 21: I-Beam Ceiling/ Recess Mounted
SCA14000 Cobalt Installation Guide CEILING INSTALLATION I-BEAM CEILING/ RECESS MOUNTED 1. Determine the installation location; the I-Beam structure must be directly under the suspended ceiling opening or desired area. 2. Make note of the position of eye bolts: - SCA14000–2x4: 1037mm*490mm - SCA14000–2x2: 490mm*490mm... - Page 22 SCA14000 Cobalt Installation Guide 3. Secure the eye bolts (4x) to the back of the ceiling unit. Eye Bolt 4. Secure the wire rope to the I-Beam based on eye bolt location as shown. For concrete ceiling, use expansion bolt and L-bracket to secure the wire rope to the concrete ceiling.
-
Page 23: Electrical Wiring Instructions
SCA14000 Cobalt Installation Guide ELECTRICAL WIRING INSTRUCTIONS INSTRUCTIONS TO HARD WIRE 120V, 60 HZ: For Recess Mount installations, the power cord needs to be hard wired and have a conduit. Please follow the instructions below to hard wire the power cord: Remove the 6 bolts from the conduit front panel. -
Page 24: Wall-Mount Installation
SCA14000 Cobalt Installation Guide WALL-MOUNT INSTALLATION 1. Assemble the wall mount as shown, use the fitted screws (4x on each bracket) to fix the frame. Select installation location, place the frame on the wall, and use a level to adjust the location, mark the screw holes (16 counts). - Page 25 SCA14000 Cobalt Installation Guide 3. Drill holes at the point marked and install the anchors. 4. Install the frame on the wall using screws, ensure the frame is installed level.
- Page 26 SCA14000 Cobalt Installation Guide 5. Install hooks on the back of the machine and secure them with screws. 6. Mount the machine onto the wall bracket hooks. 7. Plug the power cable into power supply socket.
-
Page 27: Mobile Stand Installation
SCA14000 Cobalt Installation Guide MOBILE STAND INSTALLATION 1. Assemble the stand mobile cart as shown. 2. Place the machine on the small bar and rest it against the frame. - Page 28 SCA14000 Cobalt Installation Guide 3. Fix the machine onto the cart with screws from the back. 4. Plug the power cable into power supply socket.
-
Page 29: Care And Maintenance
SCA14000 Cobalt Installation Guide CARE AND MAINTENANCE If the device is operating in an atmosphere with heavy dust, particulate, or pet dander, you may need to periodically vacuum the pre-filters for optimal performance. CAUTION: • DO NOT clean the filters and any other parts with liquid, especially alcohol, gasoline, paint thinner, etc. -
Page 30: Troubleshooting
SCA14000 Cobalt Installation Guide TROUBLESHOOTING Most service problems that appear to be major can often be resolved easily. You can be your own troubleshooter by reviewing the following guide. All other major servicing should be done by the manufacturer. SOLUTION... - Page 31 SCA14000 Cobalt Installation Guide One or both HEPA filters are Replace HEPA filter(s) fully loaded Replace HEPA filters and reset “Surgically Clean Air™” LED Filter change cycle timer expired the timer flashing Replace batteries Battery nearly exhausted Remote Control is...
