1
Connect the 9-V battery to the board.
3
Insert the kit CD and run the CD's
autorun utility.
®
PS
C
3 F
O
IRST
QUICK START GUIDE
Out of Box Demo: PSoC Rocks!
OUCH ™
T
STARTER KIT
2
Wave the kit and view the message,
as shown.
4
Open the guide and install software.
Advertisement
Related Manuals for Cypress PSOC 3 FIRSTTOUCH STARTER KIT
Summary of Contents for Cypress PSOC 3 FIRSTTOUCH STARTER KIT
- Page 1 ® OUCH ™ STARTER KIT IRST QUICK START GUIDE Out of Box Demo: PSoC Rocks! Connect the 9-V battery to the board. Wave the kit and view the message, as shown. Insert the kit CD and run the CD’s Open the guide and install software. autorun utility.
- Page 2 CY8C3866AXI-040. This kit is equipped with production PSoC 3 silicon. For the latest information about this kit, visit http://www.cypress.com/go/CY8CKIT-003 © 2009-2012 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks referenced herein are the properties of their respective owners. Doc.#: 001-53755 Rev.*D...
