Cypress PSoC Quick Start Manual

1
Remove the PSoC Development Board from the kit package.
3
After self test, read the success message on the LCD screen.
5
For PSoC 1 Development
• View the kit user's guide.
• Install the PSoC 1 software.
®
PSoC DEVELOPMENT KIT
QUICK START GUIDE
PSoC Development Board Self Test
2
Connect the AC power adapter.
4
Select an Architecture
• PSoC 1: Insert the "PSoC 1 Software" CD and jump to
step 5.
• PSoC 3/PSoC 5LP: Insert the "PSoC 3/PSoC 5LP
Software" CD and jump to step 6.
6
For PSoC 3/PSoC 5LP Development
• View the kit user's guide.
• Install the PSoC 3/PSoC 5LP software.
