Remove the PSoC 3 Development Kit from
the package.
3
Plug the USB cable into your PC and the
USB communications port (J2).
5
Insert the PSoC 3 Development Kit CD.
Install PSoC Creator and the kit software.
®
PSoC
3 DEVELOPMENT KIT
QUICK START GUIDE
2
Plug the LCD Module into port P8.
4
Vary the R56 potentiometer. The voltage is
displayed with 16 bits of precision on the
LCD module.
6
Launch PSoC Creator.
Open the code examples from the Start page.
