VERTIV EDGE UPS
500-3000VA, I, 230V IN, 230V OUT
Quick Installation Guide
MODEL DESIGN CONFIGURATIONS
7 8
5
EDGE 1U 500-1500VA
7 8
EDGE 2U 2200-3000VA
IMPORTANT: Before installing,
connecting to supply or operating
your Vertiv EDGE UPS, please
review the Safety and Regulatory
Statements sheet. For detailed
installation, operating,
maintenance and troubleshooting
information refer to the EDGE User
Guide available at www. V ertiv.com.
Thank you for your recent purchase of a Vertiv UPS! We appreciate your
business and are confident that your new product will provide many years of
uninterruptible power to your connected equipment. With this purchase, you
may also want to consider Vertiv's complete line-up of Racks, PDU's, Thermal
Solutions, KVM Switches, and Serial Consoles. Vertiv also offers a broad array of
Services and Extended Warranties. If you require any support, please don't
hesitate to reach out to Vertiv or one of our Resellers or Local Rep Firms. We
stand ready to support you.
We sincerely hope that you'll continue to select Vertiv for all of your future
infrastructure needs!
The Vertiv Team
6
2
7
8
EDGE-750/1000IMT
6 2 3
3
5 2 6 4
# Description
1 Grounding screw
2 USB communication port
3 Programmable receptacles
4 Non-programmable receptacles
5 IntelliSlot port
6 Emergency Power Off (EPO) connector
7 Input circuit breaker
8 AC input
5
5
2
6
7
4
8
3
1
EDGE-1500IMT
7 8
4
7 8
1
4
3
5 4
6 2
EDGE 2U 1500VA
5 2 6 4 3
EDGE 3U 3000VA
