parts list

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C3
3 1 CG1
4 4 CT1, CT2, CT3, CT4
5 1 D2
6 8 D4-D7, D17-D20
7 8 D8-D11, D13-D16
8 4 Q3-Q6
9 4 Q9-Q12
10 1 R12
11 1 R13
12 1 R14
13 8 R18-R21, R43-R46
14 8 R23, R25, R27, R29, R34, R36, R38, R40
15 8 R24, R26, R28, R30, R35, R37, R39, R41
16 4 RT1-RT4
17 2 U2, U3
1 1 Q1
2 1 R10
3 1 R15
4 1 R31
5 2 RC1, RC6
6 2 RC2, RC8
7 2 RC3, RC10
8 2 RC4, RC5
9 1 RC7
10 1 RC9
11 1 RC11
12 1 T1
13 1 U1
Optional Circuit Components
1 0 C2
3 0 C5
4 0 D1
5 0 D12
6 0 E5,E6
7 0 Q2
8 0 Q7,Q8
9 0 R9, R22, R33, R42
6 0 R16, R17, R32
2 0 RV1-RV4
DEMO MANUAL DC1788B
PART DESCRIPTION
DC1788B General BOM
Cap., X7R, 0.1µF , 100V, 10%, 0805
Cap., X7R, 47nF , 100V, 10%, 0805
Cap., X7R, 1nF , 2KV, 10%, 1808
Cap., X7R, 0.01µF , 10%, 200V, 0805
Diode, SMBJ58A, SMB-DIODE
Diode, MMSZ5242BS, SOD-323
Diode, MMBD4148, SOT23
Trans., MMBT3904, SOT23
Trans., MMBT3906, SOT23
Res., Chip, 8.2Ω, 5%, 0603
Res., Chip, 3.3k , 5%, 0603
Res., Chip, 100k, 5%, 0603
Res., Chip, 100k, 5%, 0402
Res., Chip, 4.3k , 5%, 0402
Res., Chip, 3.6k , 5%, 0402
Res., Chip, 75Ω, 5%, 0603
Quad MOSFETs, FDMQ8203
DC1788B-A BOM
Trans., FDMC86102, POWER33
Res., Chip, 0Ω, 5%, 0603
Res., Chip, 100k, 5%, 0603
Res., Chip, 10k, 1%, 0805
Res., Chip, 140Ω, 1%, 0805
Res., Chip, 76.8Ω, 1%, 0805
Res., Chip, 49.9Ω, 1%, 0805
Res., Chip, 34.8Ω, 1%, 0805
Res., Chip, 46.4Ω, 1%, 0805
Res., Chip, 64.9Ω, 1%, 0805
Res., Chip, 118Ω, 1%, 0805
XFMR, Würth 749022016
IC, LT4275AIDD, DFN10DD
Cap., OPT, 0402
Cap., OPT, 0603
Diode, OPT, SMA
Diode, OPT, SOD-123
TP , OPT
Trans., FDN8601, SOT23
Trans., OPT, SOT23
Res., 0603, OPT
Res., 0805, Opt
Varistor, Opt
MANUFACTURER/PART NUMBER
TDK, C2012X7R2A104K
AVX, 08051C473KAT2A
TDK, C4520X7R3D102K
AVX, 08052C103KAZ2A
DIODES INC., SMBJ58A-13-F
DIODES INC., MMSZ5242BS
FAIRCHILD, MMBD4148
FAIRCHILD, MMBT3904
FAIRCHILD, MMBT3906
VISHAY, CRCW06038R20JNEA
VISHAY, CRCW06033K3JNEA
VISHAY, CRCW0603100KJNEA
VISHAY, CRCW0402100KJNEA
VISHAY, CRCW04024K30JNEA
VISHAY, CRCW04023K60JNEA
VISHAY, CRCW060375R0JNEA
FAIRCHILD, FDMQ8203
FAIRCHILD, FDMC86102
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW0603100KJNEA
VISHAY, CRCW080510K0FKEA
VISHAY, CRCW0805140RFKEA
VISHAY, CRCW080576R8FKEA
VISHAY, CRCW080549R9FKEA
VISHAY, CRCW080534R8FKEA
VISHAY, CRCW080546R4FKEA
VISHAY, CRCW080564R9FKEA
VISHAY, CRCW0805118RFKEA
WÜRTH, 749022016
LINEAR TECHNOLOGY, LT4275AIDD
OPT
OPT
OPT
OPT
OPT
FAIRCHILD, FDN8601
OPT
OPT
OPT
SANKOSHA, SD4-90, OPT
