Solo Modes and Controls

Solo Modes

The Legacy AXS provides five solo modes:
After-Fader Listen (AFL)
Pre-Fader Listen (PFL)
Pre-Fader Listen 2(PFL 2)
Solo-In-Place (SIP)
Mix-Over-Solo
After-Fader Listen (AFL) is the default Solo mode (no buttons engaged).
Solo modes are selected using the SOLO controls in the Master Section. The selected solo mode is
activated when a channel or Stereo Return SOLO button is engaged.
After-Fader Listen (AFL):
The stereo Solo Bus is fed post pan-pot (stereo)
Non-destructive
Control room monitor source is replaced with the Solo Bus
Solo level control
Pre-Fader Listen (PFL):
The stereo Solo Bus is fed post-insert pre-fader (mono)
Non-destructive
Control room monitor source is replaced with the Solo Bus
Solo level control
Pre-Fader Listen 2 (PFL 2):
The stereo Solo Bus is fed post-preamp/COMP and pre-EQ (mono)
PFL 2 allows monitoring of the Direct Output PRE signal
Non-destructive
Control room monitor source is replaced with the Solo Bus
Solo level control
Solo-In-Place (SIP):
Destructive (all other channels/returns will mute when a SOLO button is engaged)
Monitored via the assigned Program Buses
Post-fader and pan-pot (stereo)
Solo-In-Place for the Large Fader and Small Fader may be assigned individually
Solo-In-Place for Large Fader and Small Fader may operate independently or be linked
Mix-Over-Solo:
Mixes the Solo Bus with the active control room monitor source in the control room monitors
•
• Level control adjusts the balance between the Solo Bus and the control room monitor source
AFL and PFL Solo modes only (does not work with Solo-In-Place)
A channel or return SOLO button must be engaged to activate Mix-Over-Solo
Auxiliary Master Solos
The output of the 265 Auxiliary Masters can be soloed by engaging the AFL button on the master.
After-Fader Listen is the only solo mode available to the Aux Masters.
