The Legacy AXS master bucket provides a comprehensive suite of master controls, facilities, and
features that address all the needs of modern audio production. These facilities include:

Master Channel Routing Controls

•
• 6 Assignable Stereo Returns
3 Stereo Program Bus Masters and Master Faders (A, B, C)
•
• Stereo Grand Master and Fader (GM)
Main Stereo VU Meters
•
2500C Stereo Bus Compressor
•
Automation Controller
•
2 Automation Group Master Faders
•
24 Multitrack Bus Masters
•
12 Auxiliary/Cue Masters
•
Talkback Controls
•
Solo Controls
•
• Meter and Peak Indicator Controls
Control Room Monitor Controls
•
• Studio Monitor Controls
Oscillator
•
PSU Indicators
•
User Switches
•
Master Channel Routing Controls
The channel signal flow can be altered console-wide using the controls in the INPUT SELECT area of
the Master Section.
The INPUT SELECT controls function as follows:
FLIP: Swaps the input sources between Large and Small Fader paths globally
SM ALT LINE: Switches the Small Fader path input to the Alternate Line In (ALT)
globally
• Replaces the preamp output with the Alt Line In as the Small Fader
ALL CLR (All Clear): Returns all channel input routing to the default positions:
Resets the FLIP
•
• The Small Fader source will be the Preamp output
The Large Fader source will be the Line Input
•
Illuminates only when pressed
•
COMP LRG (Compressor to Large Fader): Routes the 200 slot processor into the Large Fader path
globally
The Compressor routing on individual channels can be reset by engaging the
on the 968 Input Module
Illuminates when engaged
•
COMP BYP (Compressor Bypass): Bypasses the 200 slot processor on all channels
• Illuminates when engaged
L e g a c y A X S
The Preamp Output will be routed to the Large Fader path
The Line Input will be routed to the Small Fader path
Input sources on individual channels can be reset by engaging the
button on the 968 Input Module
Illuminates briefly when engaged to acknowledge activation, but then
goes out
path
source on all channels
The Small Fader input source on individual channels can be reset by
ALT
engaging the button on the 968 Input Module
Illuminates briefly when engaged to acknowledge activation, but then
goes out
and ALT buttons on all channels
45
FLIP
COMP LRG button
