System Specifications
EM Field Generator
Specification
Height
Width
Length
Weight
EM Field Generator Fixation Plate
Specification
Height
Width
Length
Weight
66
Figure 13
Value
200 mm
200 mm
71 mm
2.8 kg
Figure 14
Value
121 mm
300 mm
428 mm
2 kg
Technical User Guide Rev. 1.1 Curve Dual Navigation Station Ver. 1.2
