SYSTEM OVERVIEW
EM Base Station Components
③
②
①
No.
①
②
③
④
⑤
⑥
⑦
Technical User Guide Rev. 1.1 Curve Dual Navigation Station Ver. 1.2
⑦
Component
Power connection
EM instrument LEDs
Power LED
EM instrument ports
Tool extension port
Navigation system port
EM Field Generator port
