UM1570
6.1
The STM32F3DISCOVERY Discovery board mechanical
drawing
6.33mm
6.33mm
Figure 5. STM32F3DISCOVERY mechanical drawing
66.00mm
53.34mm
2.54mm
53.34mm
UM1570 Rev 6
Hardware layout and configuration
2.54mm
6.33mm
6.33mm
13/36
