TROUBLE SHOOTING GUIDE

Possible problem
Machine will not work when
switched on
Motor appears to stall when juicing
Excess pulp building up in the stainless steel
filter basket
Pulp too wet and reduced extracted juice
Juice leaks between the rim of the Juicer and
the juicer cover
Bowl surround juice sprays out from spout
Juicer makes loud noise when turned on
No juice coming out while juicing
Easy solution
The safety locking arm may not be correctly engaged in the ver-
tical operating position with the locking arm located into the two
grooves on either side of the juicer cover (see ›Assembling the
appliance‹).
Wet pulp can build up under the juicer cover if the juicing action is
too vigorous. Try slower juicing action by pushing the food pusher
down more slowly. Follow ›Disassembling the appliance‹ and ›Care
and cleaning‹ instructions and clean the filter bowl surround, the
stainless steel filter basket and the juicer cover.
Stop the juicing process and follow Disassembling instructions.
Remove the juicer cover, scrape off pulp, reassemble and begin
juicing again. Try alternating (soft and hard) vegetables and fruit
varieties.
Try a slower juicing action. Remove stainless steel filter basket
and thoroughly clean mesh walls with a cleaning brush. Rinse the
stainless steel filter basket under hot water. If the fine mesh holes
are blocked, soak the basket in a solution of hot water with 10%
lemon juice to unblock the holes or wash in the dishwasher. This
will remove excess fibre build up (from fruit or vegetables) which
could be inhibiting the juice flow.
Try a slower juicing action by pushing the food pusher down more
slowly. Fruit and vegetables with a high water content (tomatoes
and watermelon) should be juiced on low speed.
Try a slower juicing action by pushing the food pusher down more
slowly.
Filer basket is not properly snapped into position. Turn the On/
OFF button to OFF. Turn the power OFF. Disassemble the »Design
Multi Juicer« (refer to disassembling). Re-assemble (refer to
assembling).
Check that the spout is not blocked with pulp. Refer to ›Care and
cleaning‹.
55
