- Page 1 012331EN Operating Instruction Booklet Stationary Screwdriver Spindle 347-218-31 397066 A 347-318-31 397066 B 347-518-31 397066 C 347-618-31 397066 D MINIMAT...
-
Page 2: Table Of Contents
We kindly ask that you read these operating instructions carefully so that you will be able to use this tool safely and for many years to come. If you need additional information, please contact your DEPRAG Representative, one of our international support offices or us direct at DEPRAG. -
Page 3: Safety Tips
Safety Tips 1.1. General Safety Tips Before operating tool make sure to carefully read and observe this operating instruction. Generally, the operator of the equipment and/or machinery is responsible for the equipment’s perfect condition and operation, while observing all necessary safety regulations. -
Page 4: General Safety Tips For Pneumatic Stationary Screwdriver Spindles
1.2. General Safety Tips for Pneumatic Stationary Screwdriver Spin- dles · Disconnect the tool from the air supply, when changing bits or when re-adjusting clutch. · Do not wear wide clothing or jewelry, for they can be seized by movable parts. Wear a hairnet if operator has long hair. ·... -
Page 5: Operator Obligation
1.4. Operator Obligation Personnel, who is engaged in the operation of the equipment, must always be committed to · observe the basic safety and accident preventing regulations, · read and observe the safety and warning notifications of this operating instruction booklet. 1.5. -
Page 6: Symbol Description
1.6. Symbol Description Read and observe the Operating Instruction Booklet, prior to and during operation of tool. DANGER Reference to an immediate danger to a person. May lead to serious injuries or even death, if unobserved! Properly recycle environmentally damaging grease, cooling agents or detergents. - Page 7 Maintenance and repair on hydraulic and pneumatic equipment may only be performed by specially trained personnel! Disconnect equipment from air supply, prior to repair of pneumatic or hydraulic equipment. Provide regular preventive maintenance on hoses and airlines. Exchange hose lines, even if there is no visible damage! (Observe corresponding requirements of the manufacturer!) After repair and maintenance, check the following items: ·...
-
Page 8: Observe Environmental Regulations
1.7. Observe Environmental Regulations When working on or with the equipment, it is imperative to observe all requirements in regards to waste-disposal and proper recycling. Especially during installation, repair or maintenance, water damaging agents such as · lubricating grease and oil ·... -
Page 9: Installation
The hose length should not exceed 2 meters. · All DEPRAG Screwdrivers may be operated either with or without lubricated air (see paragraph: Maintenance and Upkeep). Best results are achieved, when machine is lubricated with 1 – 2 drops of oil per 1m... - Page 10 OUR RECOMMENDATION: The preferred lubricating method for the screwdriver spindles mounted in fixtures, brackets, machines, etc., each in connection with a controller, is method b) with Point-of-Use Oiler. · Check pressure at directly on the machine. The Regulator needs to be adjusted to an airflow between 5.0 (71 PSI) and 6.3 bar (90 PSI).
-
Page 11: Operation
Operating the clutch using a clutch spring which exceeds its allowable torque, leads to a reduction of the torque accuracy. The necessary torque adjustment can be tested, using a DEPRAG Torque Wrench or Dynamometer (see DEPRAG catalogs D3020 and D 3022). This equipment can also be used to re-adjust the torque of the Screwdriver Spindle. -
Page 12: Range And Exchange Of Clutch Spring
4.1. Range and Exchange of Clutch Spring The torque range of the DEPRAG Screwdriver is adjustable. Please see a listing for the torque ranges of the color-coded springs below. Torque Range of the individual clutch spring: " ." " ."... -
Page 13: Torque Adjustment
adjustment nut clutch spring claw of the in- termediate ring half-round bore Picture: Exchange of clutch spring Make sure to screw adjustment (adjusting) nut onto clutch bearing until one line of the thread is visible. 4.2. Torque Adjustment For an external torque adjustment use the following steps: Disconnect screwdriver from air supply. -
Page 14: Change Of Bits
4.3. Change of Bits CAUTION Prior to changing bits, clutch bearing has to be in place and screwdriver needs to be disconnected from air supply, to avoid the unintentional start of the screwdriver which may result in injuries. IMPORTANT Make sure to use perfect bits with DIN 3126 – E6,3 (1/4“) exter- nal hexagon end only. -
Page 15: Connection-Possibilities Of The Function Control
4.4. Connection-Possibilities of the Function Control Use as air pressure outlet during screw-assembly: · to control driver start and stop, as well as shut-off control of clutch; · as cycle counter of the complete process; each in connection with a PE-Switch or similar This function control is under pressure of appx. -
Page 16: Disassembly - Assembly
After repair or maintenance, verify that equipment runs to specification! Principally, use only DEPRAG original spare parts. Otherwise, a reduction in equipment power-output and an increased maintenance-requirement occurs. If NON-DEPRAG parts are installed, DEPRAG is justified to void any existing warranty and liability obligations. Attention:... - Page 17 10. Unscrew valve housing 401130 (AF 10, right-hand thread) from motor housing 398856. 11. Take off intermediate ring 401120 and push the motor together with the gearing completely out of the motor housing in direction of the air inlet. a. Clamp rotor cylinder into fixing device. b.
- Page 18 Assembly: Use the DEPRAG Grease 807293 (100-g tube) to grease the ball bearing, needle bearing and gearing parts prior to reassembly. a. Clean rotor. b. Press the ball bearings into the two bearing covers. c. Press the shaft-side bearing cover with the ball bearing on the rotor.
-
Page 19: Special Repair Tools (Optional Equipment)
5.1. Special Repair Tools (Optional Equipment) Fixing device (for rotor cylinder) 460762 Arbor (to disassemble bearing cover with grooved rotary joint) 462329 Press device 461224 (to press intermediate pinion 328139 into gear support) Plier (for clutch bearing 398861) 461296/1 Assembly arbor 461292 (to assemble circlip 800248 onto spindle 351888) chucking jaws (for motor housing) -
Page 20: Correct Assembly Of Shut-Off Function On Clutch
5.2. Correct Assembly of Shut-Off Function on Clutch ATTENTION If the stop-pin is installed incorrectly, the clutch will NOT shut -off. In between the two curves, the taper of the stop pin has to point towards the outside (as illustrated in the pictures below). Curves Taper on Stop Pin... -
Page 21: Spare Parts Drawings
5.3. Spare Parts Drawings... -
Page 28: Spare Parts Drawings For Accessories
5.4. Spare Parts Drawings for Accessories... -
Page 29: Installation Tips For Screwdriver Spindle
5.5. Installation Tips for Screwdriver Spindle... -
Page 30: Maintenance And Upkeep
6 months (single shift). · Exchange broken or worn inserting tools immediately, for they can cause injury to the Operator. · If tool malfunctions, we recommend to send the machine to DEPRAG. 6.1. Wear Parts UANTITY... -
Page 31: Trouble Shooting
Maintain air pressure of 90 PSI shut-off or for required torque ratchets value Valve Pin is too long Check length of valve pin, either shorten or replace valve pin (picture: Actual Size of Valve Pin) If necessary, please send tool to DEPRAG for service. -
Page 32: Delivery Capacity
Delivery Capacity Please check the delivery capacity in regards to its completeness. UANTITY Operating Instruction Booklet 012331EN Screwdriver spindle 397066 A / B / C / D Hand screwdriver 326240 Hook ( to loosen clutch bearing) 3275961 1 set of... - Page 33 Finder and bit are not included in the delivery capacity of the spring sleeve. You will find suitable inserting tools · in our brochure D 3320 E or · on the internet as follows: ® Screwdriving www.deprag.com Technology® Selection program: Inserting tools...
-
Page 34: Storage
Mount the exhaust connection 386924 G (in the screwdriver axis) resp. 386924 H (right-angled to the screwdriver axis) as follows: Disconnect screwdriver from air supply. Clamp screwdriver spindle always with chucking jaws into a vice, utilizing the flats of the motor housing (otherwise motor- and gearing parts may be damaged). -
Page 35: Technical Data
09621/371-0 09621/371-120 Technical Data: 347-218- 347-318- 347-518- 347-618- Part No. 397066 A 397066 B 397066 C 397066 D Body diameter (mm) Drive hex. female (DIN 3126) F6.3 (1/4") Weight (kg/lbs) 0.6 / 1.3 Air pressure (bar/PSI) 6.3 / 90 Hose for function control 4 / 2.5... -
Page 36: Disposal
12 Disposal Unused machines should be stored in a dry, locked area. Disassemble the machine for the required disposal complete. Observe local and environmental regulations for the separation and recycling of materials. Recycle waste oil to avoid environmental contamination! Waste Oil... -
Page 37: Declaration Of Manufacturer
13 Declaration of Manufacturer EC-Declaration of Manufacturer in accordance with the CE-Machine-Guideline 98/37/EC, appendix II B DEPRAG SCHULZ GMBH u. CO. Kurfürstenring 12 – 18 Postfach 1352 D-92204 Amberg D-92203 Amberg declares, that the construction of the stationary screwdriver spindle... -
Page 38: Service Locations And Authorized Partners
14 Service Locations and Authorized Partners ALGERIA CZECHIA/SLOWAKIA GREAT BRITAIN EP-Technology Trading S.U.A.R.L. DEPRAG CZ a.s. DEPRAG Ltd. 29 Rue Ahmed Tlili - ZI Borj Cedria ul. T.G. Masaryka 113 Unit B4, Pegasus Court TN-2055 Bir el Bey Tunis - Tunisia CZ -50781 Lázně... - Page 39 Tel.: +1 / 972 / 221 – 8731 Toma Zupana 16 LUXEMBOURG Fax: +1 / 972 / 221 – 8163 SLO-4202 NAKLO Toll Free: (800) 4 DEPRAG Tel.: +386 (0) 4 / 277 17 00 Internet: http://www.deprag.com Parelhoenstraat 24 Fax: +386 (0) 4 / 277 17 17 e-mail: deprag@depragusa.com...
- Page 40 DEPRAG SCHULZ GMBH u. CO. Postfach 1352, D-92203 Amberg Kurfürstenring 12-18, D-92224 Amberg (09621) 371-0 (09621) 371-120 Internet: http://www.deprag.com e-mail: info@deprag.de...
