- Page 1 011648 EN Operating Instruction Booklet Pneumatic Screwdriver 347F-228 386365 A 347F-328 386365 B 347F-428 386365 D 347F-528 386365 C MINIMAT-F-ULTRA...
-
Page 2: Table Of Contents
If you need additional information, please contact your DEPRAG Representative, one of our international support offices or us direct at DEPRAG. We will be happy to answer any questions. Please visit our web site: www.deprag.com Content 1 SAFETY TIPS ........................3... -
Page 3: Safety Tips
Safety Tips 1.1. General Safety Tips Before operating tool make sure to carefully read and observe this operating instruction. Generally, the operator of the equipment and/or machinery is responsible for the equipment’s perfect condition and operation, while observing all necessary safety regulations. -
Page 4: General Safety Tips For Pneumatic Screwdriver Spindles
1.2. General Safety Tips for Pneumatic Screwdriver Spindles • Disconnect the tool from the air supply, when changing bits or when readjusting clutch. • Do not wear wide clothing or jewelry, for they can be seized by movable parts. Wear a hairnet if operator has long hair. •... -
Page 5: Owner Obligation
1.3. Owner Obligation The owner is obliged to only let persons operate the equipment, who • are familiar with basic work environment safety rules and accident- preventing regulations. Also, those persons must have been instructed in the correct use of the equipment. •... -
Page 6: Warranty And Liability
1.5. Warranty and Liability Unless otherwise specified, our “General Sales and Delivery Conditions” apply. Warranty and liability claims in regards to persons or equipment damages are invalid, if one or several of the following causes apply: • Use of the equipment in a non-designated application. •... -
Page 7: Symbol Description
1.6. Symbol Description Read and observe the Operating Instruction Booklet, prior to and during operation of tool. DANGER Reference to an immediate danger to a person. May lead to serious injuries or even death, if unobserved! Properly recycle environmentally damaging grease, cooling agents or detergents. - Page 8 ESD-protected area Equipment may be damaged or destroyed by an electrostatic discharge. Maintenance and repair on hydraulic and pneumatic equipment may only be performed by specially trained personnel! Disconnect equipment from air supply, prior to repair of pneumatic or hydraulic equipment. Provide regular preventive maintenance on hoses and airlines.
-
Page 9: Observe Environmental Regulations
The function controller required for this screwdriver type, monitors the correct assembly of screw joints as well as the number of screw joints per work piece. Start-up and good function are guaranteed only in conjunction with a DEPRAG function controller consisting of an fc10 and pc 10 controller. -
Page 10: Installation
The hose length should not exceed 2 meters. • All DEPRAG Screwdrivers, may be operated either with or without lubricated air. (see paragraph: Maintenance and Upkeep) When operating with oilfree air, a performance reduction of up to 20% occurs and maintenance requirements increases! •... - Page 11 In regards to air-quality according to ISO8573-1, we recommend: LASS ESIDUE ESIDUE OF ESIDUE OF ATER Content Particle Concentration Pressure Size µm mg/m³ max. mg/m³ Point Concentration max. g/m³ Lubricated Air Dry Air 0,88 Picture: Connection of a DEPRAG MINIMAT-F-ULTRA Screwdriver...
-
Page 12: Operation
Adjust clutch to the required torque value. If necessary, exchange clutch spring. The required torque adjustment can be checked, using a DEPRAG Torque Wrench or Dynamometer (see DEPRAG catalogs D3020 and D 3022). This equipment can also be used to re-adjust the torque of the Screwdriver. -
Page 13: Range And Exchange Of Clutch Spring
4.1. Range and Exchange of Clutch Spring The torque range of the DEPRAG Screwdriver is adjustable. Please see a listing for the torque ranges of the color-coded springs below. Torque Range of the individual clutch spring: -∅ C OLOR ORQUE... - Page 14 half-round bore clutch spring Picture: Exchange of Clutch Spring Make sure to screw adjusting nut onto clutch bearing until one line of the thread is visible.
-
Page 15: Torque Adjustment
4.2. Torque Adjustment To avoid a driver lockout by the Multi-Function Controller, apply the following adjustment method: • input required amount of screws per part on the digital counter (field 3) to the value of 97. • turn key-switch to the reset-position or keep holding the reset-button. While the driver is rotating, its function will be indicated as an error on the Multi-Function Controller. -
Page 16: Handling
The screwdriver will be held as shown on picture “Connection of a DEPRAG MINIMAT-F-ULTRA screw- driver“. As soon as you push the bit slightly on to the screw, a start signal will be provided to the function control unit, some air will be supplied to the screwdriver and it will start running. -
Page 17: Assembly - Disassembly
After repair or maintenance, verify that equipment runs to specification! Principally, use only DEPRAG original spare parts. Otherwise, a reduction in equipment power-output and an increased maintenance-requirement occurs. If NON-DEPRAG parts are installed, DEPRAG is justified to void any existing warranty and liability obligations. Attention:... - Page 18 Special Repair Tools (Optional Equipment) Fixing device (for rotor cylinder) 460474 Arbor (to disassemble bearing cover with groove ball bearing) 462330 Key AF 27 (for clutch bearing) 462111 Assembly arbor (to assemble circlip 800248 onto spindle 351888) 461292 Chucking jaws (for exterior motor housing 388704) 462049 Key (for valve housing) 462113...
-
Page 19: Proximity Switch Adjustment
6.1. Proximity Switch Adjustment Disconnect screwdriver from air supply. Unscrew air connection. With the bit in the screwdriver, activate the push-to-start and c o n t i n u e t o h o l d t h e s c r e w d r i v e r d o w n throughout this procedure! Picture Picture... -
Page 20: Correct Assembly Of Shut-Off Function On Clutch
6.2. Correct Assembly of Shut-Off Function on Clutch ATTENTION If the stop-pin is installed incorrectly, the clutch will NOT shut -off. In between the two curves, the taper of the stop pin has to point towards the outside (as illustrated in the pictures below). Curves Taper on Stop Pin... -
Page 21: Spare Parts Drawing
6.3. Spare Parts Drawing... -
Page 24: Dimensional Drawing
6.4. Dimensional Drawing... -
Page 25: Maintenance And Upkeep
6 months (single shift). • Exchange broken or worn plug in tools immediately, for they can cause injury to the Operator. • If tool malfunctions, we recommend to send the machine to DEPRAG. 7.1. Wear Parts UANTITY... -
Page 26: Trouble Shooting
Maintain air pressure of 90 PSI not shut-off or required torque value ratchets Valve Pin is too long Check length of valve pin, either shorten or replace valve pin (picture: Actual Size of Valve Pin) If necessary, please send tool to DEPRAG for service. -
Page 27: Delivery Capacity
Delivery Capacity Please check the delivery capacity in regards to its completeness. UANTITY Operating Instruction Booklet 011648 EN Pneumatic Screwdriver 386365 A/B/C/D Torque Setting Screwdriver 326240 1 set of Clutch Spring see chapter: Range and Ex- change of Clutch Spring... -
Page 28: Accessories - Optional Equipment
10 Accessories – Optional Equipment Spring sleeve cpl. 364672 A Support ring 389775 A Operating Screwdriver with a Finder: Installation of the Finder (optional equipment): • Remove screw-cap (left-hand thread) from spring sleeve • Insert finder and spring into spring sleeve •... -
Page 29: Storage
D-92203 Amberg Phone 09621/371-0 09621/371-120 Technical Data: 347F-228 347F-328 347F-528 347F-428 Order No. 386365 A 386365 B 386365 C 386365 D Screws (up to) Drive hex. female (DIN 3126) F6,3 (¼") Weight (kg) Air pressure (bar/PSI) 6,3 / 90 Required Hose I.D. (mm/in.) LW 6 / ¼"... -
Page 30: Disposal
13 Disposal Unused machines should be stored in a dry, locked area. Disassemble the machine for the required disposal complete. Observe local and environmental regulations for the separation and recycling of materials. Recycle waste oil to avoid environmental contamination! Waste Oil... -
Page 31: Declaration Of Manufacturer
14 Declaration of Manufacturer EC-Declaration of Manufacturer in accordance with the CE-Machine-Guideline 98/37/EC, appendix II B DEPRAG SCHULZ GMBH u. CO. Kurfürstenring 12 – 18 Postfach 1352 D-92204 Amberg D-92203 Amberg declares, that the construction of Pneumatic Screwdrivers 347F-228 347F-328... -
Page 32: Service Locations And Authorized Partners
15 Service Locations and Authorized Partners ARGENTINA CZECHIA/SLOWAKIA GREECE ERIN s.a. DEPRAG CZ a.s. D. Panayotidis – J. Tsatsis s.a. Av. Constituyentes 5751 ul. T.G. Masaryka 113 6 Pireos Street – Moschaton RA-1431 Buenos Aires CZ -50781 Lázně Bělohrad Athen Tel./Fax: +54 (0) 11 / 4573.1313... - Page 33 Tel.: +65 / 6271-3688 LT-3028 KAUNAS Fax: +1 / 972 / 221 – 8163 Fax: +65 / 6271-8866 Tel.: +370 (0) 37 / 352195 Toll Free: (800) 4 DEPRAG Internet: http://www.testel.com.sg Fax: +370 (0) 37 / 351952 Internet: http://www.deprag.com e-mail: sunny@testel.com.sg e-mail: hidroteka@hidroteka.lt...
- Page 36 DEPRAG SCHULZ GMBH u. CO. Postfach 1352, D-92203 Amberg Kurfürstenring 12-18, D-92224 Amberg (09621) 371-0 (09621) 371-120 Internet: http://www.deprag.com e-mail: info@deprag.de...
