SEA SURF 350 Installation Manual

Electromechanical swing gate operator
Hide thumbs Also See for SURF 350:

Advertisement

Quick Links

Download this manual
International registered trademark n. 2.777.971
SURF 350 - SURF 450
SURF K
ELECTROMECHANICAL SWING GATE OPERATOR
67410720
REV 06 - 02/2020

Advertisement

loading
Need help?

Need help?

Do you have a question about the SURF 350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SEA SURF 350

Summary of Contents for SEA SURF 350

  • Page 1 International registered trademark n. 2.777.971 SURF 350 - SURF 450 SURF K ELECTROMECHANICAL SWING GATE OPERATOR 67410720 REV 06 - 02/2020...
  • Page 2 International registered trademark n. 2.777.971 IMPORTANT SAFETY INFORMATION GENERAL SAFETY PRECAUTIONS The following precautions are an integral and essential part of the product and must be supplied to the user Read them carefully as they contain important indications for the safe installation, use and maintenance. 1.
  • Page 3 International registered trademark n. 2.777.971 GENERAL SAFETY INFORMATION An appliance shall be provided with an instruction manual. The instruction manual shall give instructions for the installation, operation, and user maintenance of the appliance. The installation instructions shall specify the need for a grounding-type receptacle for connection to the supply and shall stress the importance of proper grounding.
  • Page 4 The installer shall follow the provided instructions thoroughly. SEA products must only be used to automate doors, gates and wings. Any initiative taken without SEA USA Inc. explicit authorization will preserve the manufacturer from whatsoever responsibility.
  • Page 5 International registered trademark n. 2.777.971 5. The End of Type E. Type E (audible alarm) devices can no longer be used for entrapment protection. This change was made because the Type E device is really a warning device, not an entrapment-protection device. Also, all gate operator classes are now required to have an audio alarm that sounds when two successive obstructions are encountered via a contact-type system.
  • Page 6 Fig. 4 PRECAUTIONS SEA motors have been created for the automation of gates used by vehicles only. Be aware to avoid the crossing of the gate path because it is very dangerous for pedestrians (fig. 4). Install the warning signs, on each side of the gate and in avisible zone which informs the pedestrians about the danger they run when passing or resting in the environment of the gate (fig.
  • Page 7 International registered trademark n. 2.777.971 TECHNICAL SPECIFICATIONS SURF 350 - SURF 450 is an irreversible electromechanical swing gate operator strong and safe, easy to install, for leaf length up to 14,76 feet SURF operator is equipped with release system through key, which allows the manual release of the leaf in case of emergency or black out 1.
  • Page 8 International registered trademark n. 2.777.971 TECHNICAL DATA SURF 350 (120V) SURF 350 (24V) SURF 450 (24V) SURF K (24V) TECHNICAL DATA Power supply 24Vcc 120V (± 5%)50/60Hz Max. power 280 W 60 W Max. absorbed current 2,5 A Motor speed...
  • Page 9 International registered trademark n. 2.777.971 SURF 350 - SURF 450 MAIN PARTS Fig. 7...
  • Page 10 International registered trademark n. 2.777.971 SURF K MAIN PARTS Fig. 8...
  • Page 11 International registered trademark n. 2.777.971 STANDARD INSTALLATION Fig. 9 EXIT ENTRY * For SURF K operator use 2x2,5 cables type to connect motors to the control unit 1) Operator 7) Left Photocell (Sx) 2) Mechanical stop 8) Start - stop push button with key 3) Electronic control unit 9) Antenna 4) Flashing lamp...
  • Page 12 Where possible, it is advisable to install mechanical stops on the ground for a good functioning of the operator Fig. 11 Mechanical stop in closing Mechanical stop in opening SURF 350 - 450 INSIDE INSTALLATION SURF 350 - 450 OUTSIDE INSTALLATION outside outside inside inside Fig.
  • Page 13 22,44 11,81 11,02 100° 5,90 5,11 22,83 11,81 11,02 100° 5,51 5,51 23,22 11,81 11,02 100° 5,11 5,90 23,62 11,02 100° 4,72 6,30 24,01 11,02 100° inside Fig. 17 * For SURF K operator quotes, please contact SEA-USA technical support...
  • Page 14 International registered trademark n. 2.777.971 INSTALLATION ON MASONRY PILLARS BY MAKING A NICHE 2,36 7,87 If you have to make a niche 42,05 observe the dimensions shown 6,10 Minimum 3,14 Minimum CAUTION: During installation, make sure that the cables do not interfere with the niche DIMENSIONS IN INCHES 2,36...
  • Page 15 2) Weld the front fixation bracket on the gate operating on the the points indicated by the arrows (Fig. 23) Place the operator on the front fixing bracket (SURF 350 - 450 as per Fig. 26 - 27) or insert the bracket into the housing pin on the operator (SURF K as per Fig.
  • Page 16 Fig. 24 and Fig. 25 3) Place the operator on the front fixing bracket (for SURF 350 - 450 as per Fig. 26 - 27) or insert the bracket into the housing pin on the operator (for SURF K as per Fig. 30 - 31) and tighten the «A» screw to max 8.5 Nm...
  • Page 17 International registered trademark n. 2.777.971 INSTALLATION OF MECHANICAL STOP MECHANICAL STOP IN CLOSING Max = 2,55 in Fig. 32 MECHANICAL STOP IN OPENING Max = 2,95 in Fig. 33 SURF K CONNECTIONS SURF K 24V Operator Terminal board Fig. 34 Fig.
  • Page 18 International registered trademark n. 2.777.971 SURF 350 - SURF 450 CONNEXIONS CAUTION: Limit-switches must be connected to the control unit (not to the operator directly) SURF 350 WITH MECHANICAL STOP, LIMIT-SWITCH AND ENCODER operator terminal Fig.36 SURF 350 WITH MECHANICAL STOP AND LIMIT-SWITCH...
  • Page 19 3) After having relocked the operator, close the lock protection cover to prevent damages due to atmospheric agents Note: for a greater safety of the release, SEA recommends to install the SURF release lock KIT (Code: 12715280) Handle Fig. 39 Fig.
  • Page 20 NOTE: THE MANUFACTURER SHALL NOT SHOULDER ANY RESPONSIBILITIES IN CASE OF DAMAGE CAUSED BY INAPPROPRIATE, WRONG OR CARELESS USE. SEA reserves the right to make all the necessary changes and modifications of the products or manuals without giving prior notice...
  • Page 21 PAYMENT: Method of payments and terms are notified by SEA and displayed on the commercial invoice. DELIVERY: The delivery time on the invoice is not binding and represents an estimated delivery. Shipments costs will be charged to the buyer and SEA is not responsible for delays and/or damages occurred to the products during shipment.
  • Page 22 International registered trademark n. 2.777.971 NOTES...
  • Page 24 International registered trademark n. 2.777.971 SEA USA Inc. 10850 N.W. 21st unit 160 DORAL MIAMI Florida (FL) 33172 USA Phone:++1-305.594.1151 Fax: ++1-305.594.7325 Toll Free: 800.689.4716 web site: www.sea-usa.com e-mail: sales@sea-usa.com...
