Dundalk LeisureCraft
Kota Sauna
Assembly Instructions
Please read and understand the complete instructions prior to assembly and use of your sauna. Customer agrees not to hold
Dundalk LeisureCraft Inc. and any of its authorized dealers liable for improper installation, maintenance and repair of this product
Requirements:
* 2 People (recommended)
* Step or Extension Ladder
* Cordless Drill (we supply the bit)
* Tape Measure
* 4" Drill Bit
View the assembly process on
Ph: 519-923-9813 | Fax: 866-458-7583 | Web: www.dundalkleisurecraft.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dundalk LeisureCraft Kota Sauna
Summary of Contents for Dundalk LeisureCraft Kota Sauna
- Page 1 Please read and understand the complete instructions prior to assembly and use of your sauna. Customer agrees not to hold Dundalk LeisureCraft Inc. and any of its authorized dealers liable for improper installation, maintenance and repair of this product Requirements:...
- Page 2 Dundalk LeisureCraft Kota Cedar Sauna Assembly Instructions Start by Laying out and organizing your Kota Make sure you have a solid, level Foundation. sauna pieces. (Wood Deck, Patio Stones, Concrete Pad etc.) Lay your 2 sauna floor pieces together. Make sure floor pieces are flush and screw With 2 people, stand up the 2 pieces.
- Page 3 Dundalk LeisureCraft Kota Cedar Sauna Assembly Instructions Place a wall section flush to corner of Door Panel Grab the glass door assembly and have your section. helper hold in where “door” is marked on floor. Use 2 ½” screws to secure the 2 panels Screw panels together from each panel as together as shown.
- Page 4 Dundalk LeisureCraft Kota Cedar Sauna Assembly Instructions Repeat process for all sides. When wall is complete, make sure wall is flush to floor and secure to floor using 2 ½” screws Lay out and organize the wall trim pieces. The trim pieces are “numbered” and should match the numbers on top of wall panels.
- Page 5 Dundalk LeisureCraft Kota Cedar Sauna Assembly Instructions Secure with screws as shown above. Place 2” screws into the pre-drilled holes in the corner cap pieces and slide into place. Continue process for all corners. Screw the trim pieces to the corner caps using 2 ½”...
- Page 6 Dundalk LeisureCraft Kota Cedar Sauna Assembly Instructions With your helper holding panel in place, screw Place the first roof panel up to the entrance roof panels together using 2 ½: screws. piece. Screw the trim piece to the roof from Continue process for remaining roof panels.
- Page 7 Dundalk LeisureCraft Kota Cedar Sauna Assembly Instructions Center outer door handle and secure into place Repeat for remaining ridge caps. with 2” screws. Repeat process for inside towel holder/door Carry the benches and support brackets inside handle. sauna. Lay out the 3 bench seats where they will be Place the support brackets where the seats will be positioned.
- Page 8 Dundalk LeisureCraft Kota Cedar Sauna Assembly Instructions Secure the brackets to the bench seats from Place seats on top of brackets. underneath with 1 ½ ” screws. Using the pre-drilled holes, screw brackets into Once all seats and brackets are screwed into wall with 2 ½”...
- Page 9 Dundalk LeisureCraft Kota Cedar Sauna Assembly Instructions To install the electric heater, Place heater on top Mark the placement of the heater brackets. of the included box of sauna rocks to get the correct height for installation. Place heater on wall brackets.
- Page 10 Dundalk LeisureCraft Kota Cedar Sauna Assembly Instructions Assemble remaining front support to the 2 ends Stand the 2 sides of the heater guard on edge in the same manner as previous step. with pre-drilled holes on the bottom. Screw front guard support to either side using (2) –...
- Page 11 Dundalk LeisureCraft Kota Cedar Sauna Assembly Instructions Secure the vent cover pieces with 1 ½” screws as Using supplied screws, secure vent on the shown. inside of sauna. Ensure the vent cover slides freely before To install towel hanger, simply place where screwing in tightly desired and secure with 1 ½”...
- Page 12 Congratulations on the assembly of your new Kota Cedar Sauna! For assistance in the assembly of your Kota cedar sauna please visit our support page at: https://www.dundalkleisurecraft.com/support/ Or to view the assembly process got to: https://www.youtube.com/watch?v=_HgBZmLw_u0 Ph: 519-923-9813 | Fax: 866-458-7583 | Web: www.dundalkleisurecraft.com...
-
Page 13: Warranty
7. Do NOT use commercial wood sealers from local lumberyards or hardware stores. These are not designed to withstand the sauna temperatures or humidity! 8. Contact your local dealer or Dundalk LeisureCraft directly if you have questions or concerns regarding your product.
