2.

SETTING ON THE 73VR31BLD

2.1

SYSTEM SETTING

The System setting menu appears as below.
Figure 2.1. System setting.
2.1.1

OPERATING MODE

Choose among the following options.
DEMO
Normal
2.1.2

TEMPERATURE UNIT

Choose among the following options.
Centigrade
Fahrenheit
2.1.3

START MODE

Choose among the following options.
Cold Start
Hot Start
2.1.4

DATA STORING FORM

Choose among the following options.
Float
Short int
2.1.5

DATA OVERWRITE

Data can be overwritten when the data file is full.
ON
OFF
Demonstration mode You can run the 73VR3100 program without actual signal
input for learning, evaluation and demonstration when you
choose DEMO.
Running mode Choose this option when you connect actual input signals to
the 73VR3100.
Centigrade (Celsius)
Fahrenheit
At a restart, the 73VR3100 stands by showing the initial
view.
At a restart, the 73VR3100 automatically starts recording.
Floating point 1 data size: 4 bytes
Short integer Integer data multiplied by 10 (2-byte-long data)
The oldest data is replaced with a new data when the file
capacity is full.
The 73VR3100 stops recording when the file capacity is full.
73VR31BLD USERS MANUAL EM-7397-C Rev.4 7
