4) Now you can boot up the proxy server. When you see the network status is Y, it means
your registration is OK. You can view the proxy server when the device is online.
Important
The server IP address can also be domain. But you need to register a domain name before
you run proxy device server.
Alarm Centre
2.14.1.11
This interface is reserved for you to develop. See Figure 2-93.
INSTAON
2.14.1.12
You can use your cell phone to scan the QR code and add it to the cell phone client. Via the
SN from scanning the QR code, you can access the device in the WAN. Please refer to the
InstaOn operation manual included in the resources CD.
From Main Menu
INSTAON interface is shown as in Figure 2-94.
Figure 2-93
Setting Network InstaOn, you can go to the following interface, the
85
