Page 1 Network Video Recorder User Manual Version 1.0.1...
Page 2 Foreword General This manual introduces the functions and operations of the NVR device (hereinafter referred to as "the Device"). Safety Instructions The following categorized signal words with defined meaning might appear in the Manual. Signal Words Meaning Indicates a high potential hazard which, if not avoided, will DANGER result in death or serious injury.
Page 3 About the Manual The manual is for reference only. If there is inconsistency between the manual and the actual product, the ⚫ actual product shall prevail. We are not liable for any loss caused by the operations that do not comply with the manual. ⚫...
Page 4 Important Safeguards and Warnings The following description is the correct application method of the device. Read the manual carefully bef ore use to prevent danger and property loss. Strictly conf orm to the manual during application a nd keep it properly after reading. Operating Requirement •...
Page 5: Table Of Contents
Contents FE A T URE S ........................ 7 ....................... 7 V E R V I E W ........................ 7 E A T U R E S LO C AL B A SI C OPE R AT IO N ................... 8 ........
Page 6 2. 8.9 . S plic e Pla ybac k ....................86 2. 8.1 0. Fi le L i st ...................... 87 2. 8.1 1. Loc k o r Unl o c k Fi le ..................88 2. 8.1 2. Other Aux Fu nc tio ns ..................
Page 7 2. 17. 1. S ec ur it y S tat us ..................18 5 2. 17. 2. S ys tem S e r vic e ................... 18 7 2. 17. 3. Attac k De fen se ..................19 0 2. 17. 4. CA C e rti fic ate ....................
Page 8: Features
Features Overview This series NVR is a high-performance network video recorder. This series product support local preview, multiple-window display, recorded file local storage, remote control and mouse shortcut menu operation, and remote management and control function. This series product supports center storage, front-end storage and client-end storage. The monitor zone in the front-end can be set in anywhere.
Page 9: Local Basic Operation
Local Basic Operation Slight difference may be found on the user interface. The following figures for reference only. Getting Started This chapter introduces device initial settings such as boot up, device initialization, reset password, and quick settings. Boot up For device security, connect the NVR to the power adapter first and then connect the device to the power socket. The rated input voltage matches the device power button.
Page 10 Fi gu r e 2. 1 Step 2 Set system time zone according to the actual environment. Click to shut down the device. It is suitable for the system integrator or the user to shut down directly after set ting the time z one Step 3 Click Next.
Page 11 Step 4 Set login password of admin. Parameter Description User By default, the user is admin. Password In the Password box, enter the passw ord for admin. The new pa ssword can be set from 8 characte rs through 32 characters a nd contains at least two types from number, letter Confirm Passw ord and special characters (excluding"'", """, ";", ":"...
Page 12 The pattern that you want to set must cross at least four grids. If you do not want to configure the unlock pattern, click Skip. Once you have configured the unlock pattern, the system will require the unlock pattern as the default login method. If you skip this setting, enter the password for login.
Page 13: Reset Password
Step 9 Device goes to startup wizard interface. 2.2.2. Reset Password You can reset the password by the following methods when you forgot the password for admin account. If the password reset function is enabled, you can use mobile phone to scan the QR code to reset the password. If the password reset function is disabled, there are two situations: If you configured security questions, you can reset the password by the security questions.
Page 14: Resetting Password On Local Interface
Device supports Reset button on the main board: You can answer the security question on the local menu or click the Reset button on the main board to reset password. • Device does not support Reset button on the main board: You can only answer the security question on the local menu to reset password.
Page 15 Step 2 Click • If you have set the reserved email address, the Prompt interface is displayed. See Figure 2.8. • If you did not set the reserved email address, the email entering interface is displayed. See Figure 2.9. • Enter the email address, and then click Next, the Prompt message interface is displayed.
Page 16 After clicking Next, the system will collect your information for password reset, purpose and the information includes but not limited to email address, MAC address, and device serial number. Read the prompt carefully before clicking Next. Fi gu r e 2. 10 Step 4 Reset the password.
Page 17 Fi gu r e 2. 11 Step 5 Click Next. The Reset Password int erface is displayed. See Figure 2.12. Fi gu r e 2. 12 Step 6 In the N ew Pas sword box, enter the new password and enter it again in the Confi rm Password box.
Page 18: Reset Button
Fi gu r e 2. 13 2.2.5. Reset Button You can always use the reset button on the mainboard to reset the Device to the factory default settings. Reset button is for some series products only. Step 1 Disconnect the Device from power source, and then remove the cover panel. For details about removing the cover panel, see "3.4 HDD Installation."...
Page 19: Quick Settings
Step 4 Reboot the Device. After the Device is rebooted, the settings have been restored to the factory default. You can start resetting the password. 2.2.6. Quick Settings After you successfully initialized the device, it goes to startup wizard. Here you can quickly configure your device. Click Next, device goes to General interface.
Page 20 Fi gu r e 2. 16 Step 2 Set parameters. Parameter Description Device Name In the Device Name box, enter the Device name. Device No. In the Device No. box, enter a number for the Device. Language In the Language list, select a language for the Device sy stem. In the Video Standard list, select PAL or NTSC according to your actual Video Standard situation.
Page 21 Parameter Description Time Sync In the IPC Time Sync Period box, enter the interval for time sy nc. Period (hour) You can set auto logout interval once login user remains inactive Auto logout for a spe cifie d time. Value ranges from 0 to 60 minutes. Enable the navigation bar.
Page 22 Parameter Description In the System Time box, enter time for the syst em. Click the time zone list, you can select a time zone for the system, and the time in adjust automatically. System Time Do not change the syst em time randomly; otherwise the recorded video cannot be se arched.
Page 23 Fi gu r e 2. 18 Step2 Click Add Holiday s button, the Add Holidays interface is displayed. See Figure 2.19. Fi gu r e 2. 19 Step 3 Set holiday name repeat mode and holiday mode. Click Add more to add new holiday information. Step 4 Click Add button, you can add current holiday to the list.
Page 24: Preparation
• Click the dropdown list of the state; you can enable/disable holiday date. • Click to change the holiday information. Click to delete current date. Step 5 Click Next button to save settings. Basic Network Settings You can set device IP address, DNS (Domain Name System) information. You can also configure basic network settings by selecting Main Menu →...
Page 25 Fi gu r e 2. 21 Step3 Set parameters. Parameter Description • Multi-address: Two Ethernet ports work separately through either of which you can request the Device to provide the services such as HTTP and RTSP. You need to configure a default Ethernet port (usually the Ethernet port 1 by default) to reque st the services from the device end such as DHCP, Email and FTP.
Page 26 Parameter Description In the IP Version list, you can select IPv4 or IPv6. Both versions are IP Version supported for a ccess. MAC Address Display s the MAC addr ess of the Device . Enable the DHCP function. The IP address, subnet mask and default gateway are not available f or conf iguration once DHCP is enabled.
Page 27: Instaon
• Go to the http://orange.instaon.com/ to register an account and use the SN to add a device. Refer to the INSTAON operation manual for detailed information. Before use the INSTAON function, make sure the NVR has connected to the WAN.
Page 28: Client Operation
Fi gu r e 2. 22 Step 2 Check the box to enable INSTAON function. After the INSTAON function is enabled and connected to the Internet, the system will collect your information for remote access, and the information includes but not limited to email address, MAC address, and device serial number. Step 3 Click Next button to complete setup.
Page 29 Fi gu r e 2. 23 ➢ Tap on the top right corner. The i n t e r f a c e r e q u i r i n g d e v i ce initialization is displayed. A pop-up message reminding you to make sure the Device is initialized is displayed.
Page 30 • Tap INSTAON. The INSTAON interface is displayed. See Figure 2.25. Fi gu r e 2. 25 Enter a name for the NVR, the username and password, scan the QR code under Device SN. • Tap Start Live Preview. The Device is added and displayed on the live view interface of the cell phone. See Figure 2.26. Fi gu r e 2.
Page 31: Registration
2.3.3. Registration If you do not select Smart add function during the initialization process, go to the remote Device interface to register a remote device. After adding remote device, the device can receive, store, and manage the video streams of the remote device. You can view, browse, play back and manage several remote devices at the same time.
Page 32 Fi gu r e 2. 28 Parameter Description Enable the Uninitialized function, the uninitialized devices out Uninitia lized of the searched dev ice s are displaye d in the searched dev ice list. Select the uninitialized device from the uninitialized device list, Initia lize and the click Initialize to start initializing device.
Page 33 In the Searched Device List area, se lect the device that you want to add. Add the device by manually configuring settings such a s IP Manual Add address, channel se lect ion. Added Device Display s the added de vices. You can edit and delete the device List and view the device inf ormation.
Page 34 • Configure parameters. Parameter Description In the Channel list, se lect the channel that you want use on Channel the Device to connect t he remote device. In the Manufacture list , select the manufactur er of the remote Manufa cturer device.
Page 35: Schedule
• Click OK. The remote device information is displayed on the Added Device list. Step 4 Click Next to complete the remote device registration. • Click to change the remote device information. Click to delete remote device. Once the multiple-sensor device has registered to the device system displays the channel status on the Link info. See Figure 2.30.
Page 36 Fi gu r e 2. 31 Step 2 Select a channel from the dropdown list, you can set different record plans for different channels. Select All if you want to set for all channels. Parameter Description Channel In the Channel list, sele ct a channel to record the video. In the Pre-record list, enter the amount of time that you want to Pre-record start the recording in advance.
Page 37 You can set ANR (auto network resume) funct ion. ⚫ The IPC continues record once the NVR and IPC connection fails. After the network become s normal, the NVR can download record f ile during the offline period fr om the IPC. I t is to guarantee there is no record loss on current connected IPC channel.
Page 38 • When the record type is MD (motion detect), alarm, MD & Alarm, IVS and POS. Fi gu r e 2. 34 Step 4 Set record period. It includes edit mode and draw mode. See Figure 2.35. If you have added a holiday, you can set the record period for the holiday. Fi gu r e 2.
Page 39 ✓ Red stands for alarm record. ✓ Blue stands form intelligent record. ✓ Orange stands for MD & Alarm record. ✓ Purple stands for POS record. ✓ Once the time period overlaps, the record priority: MD & Alarm → Alarm → POS → Intelligent → MD →...
Page 40 Fi gu r e 2. 37 ➢ Set record type for each period. ✓ There are six periods for you to set for each day. ✓ Under Copy, select All to apply the settings to all the days of a week, or select specific day(s) that you want to apply the settings to.
Page 41 Fi gu r e 2. 38 Step 2 Select a channel to set schedule snapshot. Step 3 Set snapshot type as schedule. Step 4 Check the box to set alarm type. See Figure 2.39. Fi gu r e 2. 39 •...
Page 42: Record Control
Step 5 S et snapshot period. Step 6 Click Apply button to save snapshot plan. • Enable auto snapshot function so that the snapshot plan can become activated. 2.3.5. Record Control After set schedule record or schedule snapshot, you need to enable auto record and snapshot function so that system can automatically record or snapshot.
Page 43: Camera
Parameter Description Display s a ll the a nalog channels and the connected digital Channel channels. You can select a single channel or se lect All. Auto: Automatically re cord according to the record type and ⚫ recording time as configured in the recording schedule. Record status Manual : Keep general recording for 24 hours for the selected ⚫...
Page 44: Changing Ip Address
2.4.2. Changing IP address Step 1 Select Main Menu → REGISTRATION → Camera Registration, check the box before the camera name and then click Modify IP or click the before the camera name. Enter Modify IP interface. See Figure 2. 43. •...
Page 45: Ip Export
Auto Changing H.265 For the remote device that first registered to the system, it can automatically adopts encode format as H.265 if you enable H.265 Auto switch function. Click H.265 Auto Switch button at the bottom of the interface, it is from .
Page 46: Ip Import
Step 2 Select Address to save export file. Step 3 Click the OK button. Device pops up a dialogue box to remind you successfully exported. When exporting IP address, the File Backup Encryption check box is checked by default. The file information includes IP address, port, channel number, manufacturer, username, and password.
Page 47: Remote Device Initialization
2.4.5. Remote Device Initialization Remote device initialization can change remote device login password and IP address. When connect a ca mera to the NVR via PoE port, NVR automatically initialize the camera. The camera adopts NVR curre nt password a nd email information by default. When connect a ca mera to the NVR via PoE port after NVR upgrade d to the new version, t he NVR may fail to initializ e the camera.
Page 48 Fi gu r e 2. 48 Configure parameters. Parameter Description User The default is admin. The new password can be set from 8 characters through 32 Password characters a nd contains at least two types from number, letter and special characters (excluding"'", """, ";", ":" and "&"). Enter a strong password according to the passw or d Confirm Passw ord strength bar indication.
Page 49 Fi gu r e 2. 49 Step 6 Set email information. Input an email address for reset password purpose. Cancel the box and then click Next or Skip if you do not want to input email information here. Step 7 Click Next button. The Network interface is displayed.
Page 50: Short-Cut Menu To Register Camera
Step 8 Set camera IP address. Check DHCP, there is no need to input IP address, subnet mask, and default gateway. Device automatically allocates the IP address to the camera. Check Static, and then input IP address, subnet mask, default gateway and incremental value. If it is to change several devices IP addresses at the same time, input incremental value.
Page 51: Image
Fi gu r e 2. 52 Step 2 Click "+", device pops up interface to add network camera. 2.4.7. Image You can set network camera parameters according to different environments. It is to get the best video effect. Step 1 Select Main Menu → CAMERA → IMAGE. The IMAGE interface is displayed.
Page 52 Step 2 Configure parameters. Different series network camera displays different parameters. The actual product shall prevail. Parameter Description In the Channel list, select the channel that you want to Channel conf igure . There are three config files f or you. System h a s configured the Config File corresponding parameters for each file, you can select accor ding to your actual situation.
Page 53 It is f or the camera of auto iris only. ⚫ After enable auto iris function, the iris can ⚫ automatically zoom in/ zoom out according to the brightness of the environment and the Auto iris image br ightness changes too. If disable the auto iris function, the iris doe s ⚫...
Page 54: Encode
Configure the color and black & w hite mode of the image. T his setting is not affected by the configuration files. The default setting is Auto. ➢ Color: The camera outputs color image only. ➢ Auto: Depends on the camera, such a s overall brightness and whether there is an IR light, either color image or Day &...
Page 55 Parameter Description In the Channel list, select the channel that you want to Channel conf igure the settings for. Enable the smart codec function. T his f unction can reduce the video bit stream for non- important recorded vide o to maximize the storage space.
Page 56 I Frame Interval The interval between two reference frames. In the Bit Rate list, select a value or enter a customized value to change the image quality. The bigger the value is, the better Bit Rate (Kb/S) the image w ill become. Step 2 Configure parameters.
Page 57 Snapshot You can set snapshot mode, ima ge size, quality and interval. Step1 Select Main Menu → CAMERA → ENCODE → Snapshot. The SNAPSHOT interface is displayed. See Figure 2.56. Fi gu r e 2. 56 Step2 Configure parameters. Parameter Description In the Manual Snap list, select how many snapshots you want to Manua l Snap...
Page 58: Channel Name
Step 3 Click Apply. 2.4.9. Channel Name You can set customized channel name. Step1 Select Main Menu → CAMERA → CAM NAME. The CAM NAME interface is displayed. See Figure 2.57. Fi gu r e 2. 57 Step 2 Modify a channel name. You can only change the camera connected via the private protocol.
Page 59: Remote Upgrade
2.4.10. Remote Upgrade You can upgrade the connected network camera firmware. It includes online upgrade and file upgrade. Step 1 Select Main Menu → CAMERA → REGISTRATION → Upgrade. The Upgrade interface is displayed. See Figure 2.58. Fi gu r e 2. 58 Step 2 Update the firmware of the connected remote device.
Page 60: Remote Device Info
2.4.11. Remote Device Info Device Status You can view the connection and alarm status of the corresponding channel. Select Main M enu → CAMERA → REGISTRATION → Status, the Status interface is displayed. See Figure 2.59. Fi gu r e 2. 59 Icon Description Icon...
Page 61: Live View
Fi gu r e 2. 60 Live View After you logged in, the system goes to multiple-channel live view mode by default. You can view the monitor video of each channel. The displayed window amount may vary. The actual product shall prevail. 2.5.1.
Page 62: Navigation Bar
2.5.2. Navigation bar You can quickly perform operation through the icon on the navigation bar. Different series products may display different navigation bar icons. Refer to the actual product for detailed information. Select Main Menu → SYSTEM → GENERAL → General to enable navigation bar function and then click Apply; otherwise you cannot see the following interface.
Page 63: Channel Info
Open the record search interface. For detail, see "4.6.2 Search Interface." Open the Broadcast int erface. For detail, see " 4.17.3 Broadcast." Open the EVENT interface to view the device alarm status. For details, see "4.8.2 Alarm Status." Open the CHANNEL INFO interface to display the information of each channel.
Page 64: B Ma Nage R
Fi gu r e 2. 62 2.5.4. USB Manager After connecting the USB device, you can copy log, config file to USB device or update NVR system. Click , system goes to HDD Manager interface. You can view and manage HDD information. See Figure 2.63. Here you can view USB information, backup file, and update system.
Page 65: Preview Control Interface
Preview Control Interface 2.5.5. Move your mouse to the top center of the video of current channel; you can see system pops up the preview control interface. See Figure 2.64. If your mouse stays in this area for more than 6 seconds and has no operation, the control bar automatically hides.
Page 66 Instant replay is to playback the previous 5 minutes to 60 minutes record of current channel. Move the slider to choose the time you want to start playing. Play, pause and close playback. The information such as channel name and recording status icon are shielded during instant playback and will not display until exited.
Page 67 The digital zoom interface is shown as in Figure 2.67. When the image is in the enlarged status, you can drag the image toward any direction to view the other enlarged areas. Right click mouse to cancel zoom and go back to the original interface.
Page 68 S: Sub stream. Its definition is low but occupies small network bandwidth. It is suitable for general surveillance, remote connection etc. Click to switch the bit stream type of the mainstream and sub stream. M: Mainstream. S: Sub stream. Some series products support two sub streams (S1, S2). Right-Click Menu: By right-clicking the menu, you can quickly access the corresponding functional interface and perform relevant operations, including entering the main menu, searching records and selecting screen split mode.
Page 69 Open the PTZ interface. For details, see "4.4 PTZ." View Configure the live vie w screen as a single -channel layout 1/4/8/9/16/25/36 or multi -cha nnel lay out. Sequence (View Set customized screen split mode and channe ls. For details, Layout ) see "4.3.4 Sequence."...
Page 70 Fi gu r e 2. 69 Step 2 On the edit view interface, drag the channel to the desired window, or drag on the preview window to switch the position. Check the channel number at the right bottom corner to view the current channel sequence. See Figure 2.70. Fi gu r e 2.
Page 71: Z S Et Ting S
Fi gu r e 2. 71 PTZ is a mechanical platform that carries a camera and a protective cover and performs overall control remotely. A PTZ can move in both horizontal and vertical direction to provide all-around view to the camera. Before you control the PTZ, make sure the PTZ decoder and the NVR network connection is OK.
Page 72 Fi gu r e 2. 72 Step3 Configure parameters. Parameter Description In the Channel list, se le ct the channel that you want to connect the Channel PTZ camera to. • Loca l: Conne ct through RS-485 port. • Remote: Connect through network by adding IP address of PTZ PTZ Type camera to the Device.
Page 73: Z Cont Ro L
2.6.2. PTZ Control PTZ control panel performs the operations such as directing camera in eight directions, adjusting zoom, focus and iris settings, and quick positioning. Basic PTZ Control Panel Right-click on the live view screen and then select PTZ. The PTZ control panel is displayed. See Figure 2.73. Fi gu r e 2.
Page 74 Fast positioning button. Positioning: Click to enter the fast positioning screen, and ⚫ then click anyw here on the live view screen, the PTZ will turn to this point and move it to the middle of the scr een. Zooming: On the f ast posit ioning screen, drag to draw a square on the view.
Page 75: Configuring Ptz Functions
Tour Flip Pattern Reset Click the AUX Config icon to ope n functions settings Auto scan interface. Click the Enter Menu icon to open AUX Switch the MENU OPERATION interface. 2.6.3. Configuring PTZ Functions Configuring Presets Step 1 On the Expanded PTZ Control Panel, click The Preset interface is displayed.
Page 76 Fi gu r e 2. 76 Step3 In the Patrol No. box, enter the value for the tour route. Step4 In the Preset box, enter the preset value. Step5Click Add Preset . A preset will be added for this tour. You can repeat adding more presets.
Page 77: Calling Ptz Functions
of adjusting zoom, focus, iris, and directions. Step5 On the PTZ interface, click End to complete the settings. Configuring Auto Scan Step1 On the Expanded PTZ Control Panel, click The PTZ interface is displayed. Step2 Click the Border tab. The Border interface is displayed. See Figure 2.78. Fi gu r e 2.
Page 78 Calling Tours Step1 On the Expanded PTZ Control Panel, in the No. box, enter the value of the tour that you want to call. Step2 Click to call the tour. Step3 Click again to stop calling the tour. Calling Patterns Step1 On the Expanded PTZ Control Panel, in the No.
Page 79: Record File
Record File Device adopts 24-hour continuous record by default. It supports customized record period and record type. Playback and Search 2.8.1. Instant Playback You can view the record file of previous 5 to 60 minutes. 2.8.2. Search Interface You can search and playback the record fine on the NVR. Select Main Menu > PLAYBACK, or on the preview interface right click mouse and then select Search, you can go to the following interface.
Page 80 Function Description Display the se arched re corded vide o or picture . It supports playing in single- channel, 4-channel, 9-channel, and 16- channel simultaneously. Display Window When playing back in a single channel mode, hold down the left mouse button to select the area that you want to enlar ge. The are a is e nlar ged after the left mouse button is released.
Page 81 Select the Sync check box to simultane ously play recorded Sync videos of different channels in the same pe riod in multi- channel view. Select the check box to define the recording type to search Record type for. Select the content to play back: Record, PIC, Splice Search type Playback .
Page 82: Playback Control
2.8.3. Playback Control The playback control interface is shown as below. See Figure 2.82. Fi gu r e 2. 82 Refer to the following sheet for more information. Icon Function Play/Pause In slow play mode, click it to switch between play/pause. Stop When playing ba ck, click t o stop current playback process.
Page 83: Search Type
Click the snapshot button in the full - screen mode , the sy stem can snapshot 1 picture. System supports custom snap picture saved path. Connect the peripheral device f irst , click snap button on the full - screen mode, you can sele ct or create path.
Page 84: Record Backup
This function allows you to clip some footages to a new file and then save it to the USB device. See Figure 2.85. Follow the steps listed below. Step1 Select a record first and then click to playback. Step2 Select a time at the time bar and then click to start clip.
Page 85: Smart Search Playback
Step3 Click Backup to begin the process. 2.8.6. Smart Search Playback This function is for some series product only. During playback process, it can analyze the motion detect zone in the scene and give the analysis result. This function is for channel that already enabled motion detect function (Main Menu → ALARM → VIDEO DETECT → Motion Detect).
Page 86: Mark Playback
2.8.7. Mark Playback When you are playback record, you can mark the record when there is important information. After playback, you can use time, or the mark key words to search corresponding record and then play. It is very easy for you to get the important video information.
Page 87: Playback Image
Fi gu r e 2. 88 Modify • Double-click one-mark information item, you can see system pops up a dialogue box for you to change mark information. You can only change mark name here. • Delete Here you can check the mark information item you want to delete and then click Delete button; you can remove one- mark item.
Page 88: File List
Step1 Select Main Menu > PLAYBACK, the PLAYBACK interface is displayed. Step2 In the Searc h Type list, select Splice Play back; In the Split Mode list, select 4, 9, or 16. Se e Figure 2.89. Fi gu r e 2. 89 Step3 In the Calendar area, select a date.
Page 89: Lock Or Unlock File
Fi gu r e 2. 91 • Check a file name, double-click the file or click to play. • Input accurate time at the top column, you can search records of current day. • System max displays 128 record files in one list. •...
Page 90: Other Aux Functions
Fi gu r e 2. 92 2.8.12. Other Aux Functions Digital Zoom In 1 -window play back mode, left click mouse to select any zone on the screen, you can z oom in current zone. Right click mouse to exit. Switch Channel During playback mode, select from the dropdown list to switch playback channel.
Page 91: Ai Search
2.9.1. AI Search You can search the record file on the NVR and filter the record file meets the corresponding rule. It is suitable for you to play the specified file. This series NVR products support playback the AI by camera file only. AI by camera means the connected camera does all the AI analytics, and then gives the results to the NVR.
Page 92 Fi gu r e 2. 94 To lock the files to make it unable to be overwritten, select the files, and then click Lock. To add a mark to the file, select the files and then click Add Mark. Go to Face Properties and Person Details to view detailed information. Face Recognition System can search and compare the human face on the video with the face image on the database, and playback the corresponding record file.
Page 93: Ivs
Step2 Select the channel and set the parameters such as start time, end time, gender, age, glasses, beard, mask, and similarity according to your requirement. Step3 Click Smart Search. The search result is displayed. See Figure 2.96. The human face in the image is pixelated. The actual image is clear. Fi gu r e 2.
Page 94: Human Body Detection
Fi gu r e 2. 97 Step2 Select a channel, start time, end time, event type, and then click Smart search, the search result is displayed. Step 3 Click the picture that you want to play back. You can also do the following operations to the recorded files. To back up the recorded files to the external storage device, select files, click Backup, select the save path and file type, and then click Start.
Page 95 Step2 Select a channel, start time, end time, and set corresponding parameters. Step3 Click Smart search. The search result is displayed. See Figure 2.99. For privacy reason, the human face in the image is pixelated. Fi gu r e 2. 99 Step4 Select one or multiple results, and then you can to back up the recorded files to the external storage device, select files, click Backup, select the save path and file type, and then click Start.
Page 96: Non-Motor Vehicle Detection
The VEHICLE DETECTION interface is displayed. See Figure 2.100. Fi gu r e 2. 10 0 Step 2 Select a channel and set parameters. • System supports plate fuzzy search. • System searches all plate numbers by default if you have not set a plate number. Step3 Click Smart search.
Page 97 Fi gu r e 2. 10 1 Step2 Sele ct the cha nnel and the time, and then se lect one or multiple features from Type, Vehicle Color, People Number, or Helmet . Step3 Click Smart Searc h. The search result is displayed. See Figure 2.102. Fi gu r e 2.
Page 98: People Counting
Step4 Select one or multiple results, and then you can: • To back up the recorded files to the external storage device, select files, click Backup, select the save path and file type, and then click Start. • To lock the files to make it unable to be overwritten, select the files, and then click Lock. •...
Page 99: Heat Map
Parameter Description Channel Select the channel you want to search people amount. Rule Select the rule from the dropdown list. Select report type from the dropdown list: daily report, Report Type monthly report, yearly report. Start time/end time Set search start time and end time. Type Select from the dropdown list.
Page 100: Parameters
2.9.7. Parameters Smart Plan The smart plan is for the smart network camera. It includes IVS, human face detection, human face recognition, human body detection, people counting, heat map. If you do not set a rule here, you cannot use these AI intelligent functions when you are connecting to a smart network camera.
Page 101 • Click to delete the preset. • Click Add to add a preset. • Once the remote device does not support preset function, the interface is shown as in Figure 2.106. Fi gu r e 2. 10 6 Select a channel. Click the smart plan icon.
Page 102 Fi gu r e 2. 10 7 Step2 In the Channel list, select a channel that you want to configure face detection function, and then enable it. Step3 Configure the parameters. Parameter Description This series NVR product s support AI by Camera only. AI by Camera means Type the connected camera does all the AI analytics, and then give s the results to the NVR.
Page 103 Select the che ck box. When an alarm occur s, the NVR device sends a n email to the set ma ilbox to notify the user. Send Email You need to set the email first. For details, see "4.12.6 Email." Select the check box and se lect the needed rec ording channel ( suppor t multiple choice s).
Page 104 The comparison result will be displayed on the AI mode live view screen and smart search interface and link the alarms. This series NVR products support AI by camera only. You can use the connected camera to realize AI function. Make sure the connected camera supports human face detection function.
Page 105 Step5 Set the Target Face Database. Step 6 (Optional) Click to modify the similarity. The lower the number is, the easier the alarm linkage will trigger. Step7 Click to set the alarm linkage. Step8 Configure the parameters. Parameter Description Configure the period and in the set time range, the corresponding Period configuration item will be linked to start the alar m.
Page 106 Step9 Click OK, system goes back to human face recognition interface. Step10 Click Apply to complete the settings. 2.9.8. IVS (General Behavior Analytics) The IVS function processes and analyzes the images to extract the key information to match with the specified rules. When the detected behaviors match with the rules, the system activates alarms.
Page 107 Fi gu r e 2. 10 9 Step2 Select a channel from the dropdown list. Click Add and then set corresponding rule. See Figure 2.110. Click to delete the selected rule. Fi gu r e 2. 11 0 Step3 Set corresponding parameters. Step4 Click Apply.
Page 108 2.9.8.1.1. Tripwire When the detection target crosses the warning line along the set direction, the system performs an alarm linkage action. Step1 Select Main Menu → AI → PARAMETERS → IVS. In the Type drop-down list, select Tripwire. See Figure 2.111. Fi gu r e 2.
Page 109 a. Configure the parameters. Parameter Description Name Customize the rule name. Direction Set the tripwire direction, including A→B, B→A and A↔B. Click to filter the target. Check the blue wireframe and adjust the size of the area w ith the mouse. Filter target Each rule can set 2 target filters (maximum size and minimum size), that is, when the passing target is smaller than the minimum target or...
Page 110 Step4 Configure the parameters. Parameter Description Configure the period and in the set time range, the corresponding Period configuration item will be linked to start the alar m. The alarm device ( such as lights, sirens, etc.) is conne cted to the alarm Alarm Out output port.
Page 111: Ivs ( Gene Ra L Beha Vio R An Aly Tic
Step1 In the Type drop-down list, select Abandoned Object. The interface is shown as Figure 2.114. Step2 Draw the detection rule. Fi gu r e 2. 11 4 a. Click to draw the rule on the surveillance video. b. Set parameters. Parameter Description Preset...
Page 112 Step3 Click Step4 Click Apply to complete the setup. 2.9.8.1.3. Fast moving You can detect the fast-moving object in the specified zone. Step1 In the Type drop-down list, select Fast Moving. The interface is shown as below. See Figure 2.115.
Page 113 Fi gu r e 2. 11 5 Step2 Draw the detection rule. Figure 2.116 Click to draw the rule on the surveillance video. Set parameters. Parameter Description Preset Select a pre set you want to use IVS Name Input customized rule name Sensitivity You can set alarm sensitivity.
Page 114 The interface is shown as below. See Figure 2.116. Fi gu r e 2. 11 6 Step2 Draw the detection rule. iii. Click to draw the rule on the surveillance video. iv. Set parameters. Parameter Description Preset Select a pre set you want to use IV S. Name Input customized rule name Duration...
Page 115 linkage action. Step1 In the Type drop- down list, select P arking . The interface is shown as below. See Figure 2.117. Fi gu r e 2. 11 7 Step2 Draw the detection rule. vii. Click to draw the rule on the surveillance video. viii.
Page 116 Step1 In the Type drop-down list, select Missing Object. The interface is shown as below. See Figure 2.118 Fi gu r e 2. 11 8 Step2 Draw the detection rule. Figure 2.118 xi. Click to draw the rule on the surveillance video. xii.
Page 117 2.9.8.1.7. Loitering Detection System can generate an alarm once the object is staying in the specified zone longer than the threshold. See Figure 2.119. Fi gu r e 2. 11 9 Step1 In the Type drop- down list, select Loiteri ng Detection. The interface is shown as below.
Page 118 ANPR After set the heat map parameters, go to Main Menu → INFO → EVENT → HEAT MAP to view heat map report. System uses the video recognition technology to extract the plate number on the surveillance video and then compare it with the specified plate information.
Page 119 The alarm device (such as light s, sirens, etc.) is conne cted to the alarm Alarm Out output port. When an alarm occurs, the NVR device transmits the alarm information to the alar m device. When the alarm ends, the alarm extende d for a period. The time range is Latch from 0 seconds to 300 seconds.
Page 120: Event M A N A G E
Event Manager 2.10.1. Alarm Info You can search, view a n d back up the alarm inf ormation. Step1 Select Main Menu → ALARM → ALARM INFO. The ALARM INFO interface is displayed. See Figure 2.121. Fi gu r e 2. 12 1 Step4 In the Type list, select the event type;...
Page 121: Ala Rm Inpu
Fi gu r e 2. 12 2 2.10.3. Alarm Input Step1 Select Main Menu → ALARM → ALARM INPUT, The ALARM INPUT interface is displayed. See Figure 2.123. Step2 There are four alarm types. • Local alarm: After connecting the alarm device to the NVR alarm input port, system can trigger the corresponding alarm operations when there is alarm signal from the alarm input port to the NVR.
Page 122 Fi gu r e 2. 12 3 Step3 Set Alarm In channel number and then sele ct the Enable check box to enable the f unction. Step4 Configure parameters. Parameter Description Alarm in Select a channel to set alarm. Enable Check the box to enable the function.
Page 123: Ala Rm C O Nt Ro
Select the check box and click Setting to se lect the channel and P TZ action. Whe n an alarm occur s, the NVR device associates the channel to Activation perform the corresponding PTZ action. For example, activate the PTZ in channel one to turn to the preset point X.
Page 124: Video De Tec T Io
Step2 Select the alarm mode of the alarm output channel. • Click OK button of the Alarm Release, y ou can clear all alarm output statuses. • View the alarm output status on the Status column. Step3 Click Apply. 2.10.5. Video Detection The video detection adopts the computer image and graphics process technology.
Page 125 Parameter Description Channel In the Channel list, sele ct a channel to set the motion detection. Region Click Setting to def ine the motion detection r egion. Enable or disable the motion detection function. Check the box Enable MD to enable the function. Period Define a per iod during which the motion dete ction is active.
Page 126 • Click Copy, in the Copy dialog box, select the additional channel(s) that you want to copy the motion detection settings to, and then click Apply. • Click Test to test the settings. 2.10.5.1.1. Setting the Motion Detection Region Step1 Next to Region, click S etting . The region setting screen is displayed.
Page 127 2.10.5.1.2. Setting Period The system only activates the alarm in the defined period. Step1 Next to Period, click Setting. The Setting interface is displayed. See Figure 2.127. Fi gu r e 2. 12 7 Step2 Define the motion detection period. By default, it is active all the time. •...
Page 128 Fi gu r e 2. 12 8 a. Enter the time frame for the period, and then select the check box to enable the settings. There are six periods for you to set for each day. Under Copy, select All to apply the settings to all the days of a week, or select specific day(s) that you want to apply the settings to.
Page 129 Tampering When the camera lens is covered, or the video is displayed in a single color because of sunlight status, the monitoring cannot be continued normally. To avoid such situations, you can configure the tampering alarm settings. Step1 Select Main Menu → ALARM → VIDIEO DETECTION → Tampering. The Tampering interface is displayed.
Page 130 Video Loss When the video loss occurs, the system activates the alarm. Step1 Select Main Menu → ALARM → VIDIEO DETECTION → Video Loss. The Video Loss interface is displayed. See Figure 2.130. Fi gu r e 2. 13 0 Step 2 To configure the settings for the video loss detection parameters, see "4.8.5.1 Motion Detect."...
Page 131 Scene Change When the detected scene has changed, system can generate an alarm. Step1 Select Main Menu → ALARM → VIDEO DETECTION → SCENE CHANGE, The Scene Change interface is displayed. See Figure 2.131. Fi gu r e 2. 13 1 Step 2 To configure the settings for the scene change parameters, see "4.8.5.1 Motion Detect."...
Page 132: Audio De Tec
Fi gu r e 2. 13 2 Step2 To configure the settings for the PIR alarm parameters, see "4.8.5.1 Motion Detect." Step3 Click Apply to complete the settings. • Click Default to restore the default setting. • Click Copy, in the Copy dialog box, select the additional channel(s) that you want to copy the motion detection settings to, and then click Apply.
Page 133 Fi gu r e 2. 13 3 Step2 Configure parameters. Parameter Description Channel In the Channel list, sele ct a channel to set. Check the box here, system can generate an alar m once the audio input Input abnormal is abnorma l. Intensity Check the box here, system can generate an alarm once the audio change...
Page 134: The Rm Al Ala R
Select the check box. When an alarm occurs, the NVR device sends a n Send Email email to the set mailbox to notify the user. Select the check box a n d select the needed recording channe l (support multiple choices) . When an alarm occur s, the NVR device activates Record Channe l the channel for recording.
Page 135 • The connected channel shall support temperature test function. • This function is for some series products only. It supports enable/disable function only. Go to the front-end device to set corresponding parameters. Step1 Select Main Menu → ALARM → THERMAL ALARM. The THERMAL ALARM interface is displayed. See Figure 2.134.
Page 136 Select the check box. When an alarm occurs, the NVR device uploa ds Alarm Upload an alarm signa l to the network (including the alarm center). Select the check box. When an alarm occur s, the NVR device sends an Send Email email to the set mailbox to notify the user.
Page 137: Abno Rm A Li
2.10.8. Abnormality Step1 Select Main Menu → ALARM → ABNORMALITY. The Abnormality interface is displayed. Se e Figure 2.135. Fi gu r e 2. 13 5 Fi gu r e 2. 13 6...
Page 138 Fi gu r e 2. 13 7 Fi gu r e 2. 13 8 Step2 Configure parameters.
Page 139 Parameter Description Click the corre sponding tab to set different abnormality events. ⚫ HDD: Sets proce ss method whe n there is a HDD event such as HDD error, no HDD, no space. See Figure Figure 2.135. ⚫ Network: Sets process method when there is a network event Event Type such as disconnection, IP conflict, MAC conflict.
Page 140: S Earc
Select the Snapshot check box to take a snapshot of the se lected Snapshot channel. Select the check box, the NVR device records the alarm information in the log when an alarm occurs. Check the box and then select the corresponding audio f ile from the Voice Prompts dropdown list.
Page 141: S Etting
Step2 In the POS SEARCH box, enter the information such as transaction number on your receipt, amount, or product name. Step4 In the Start Time box and End Time box, enter the time period that you want to search the POS transaction information.
Page 142 Parameter Description In the POS Name list, se lect the POS machine that you want to conf igure settings for. Click to modify the POS name. ⚫ POS Name ⚫ ⚫ The POS na me shall be unique. ⚫ The POS name supports 63 English characters . Enable Enable the POS function.
Page 143 Enable the POS Inf o function, the POS information display s POS Inf o in the live view/WEB . There is no line delimite r by default. After set the line delimiter (HEX), the overlay infor mation after the delimiter is displayed in the new line. For example, Line Delimiter the line delimiter is F and the overlay inf ormation is 123156789, NVR displays overlay information on the local...
Page 144: Log
Fi gu r e 2. 14 2 Step3 Source IP and Port. Refers to POS IP address and port. Step4 Click OK to complete setup. Operation and Maintenance 2.12.1. You can view a nd search the log inf ormation, or backup log to the USB device. Step1 Select Main Menu →...
Page 145: System
Account , Clear, Playbac k, and Connection) or select All to view all logs. Step6 In the Start Time box and End Time box, enter the time period to se arch, and then click. Search. The search results are displayed. See Figure 2.144. Fi gu r e 2.
Page 146 HDD Info You can view the HDD quantity, HDD type, total space, free space, status, and S.M.A.R.T information. Select Main Menu → OPERATION → INFOMATION → HDD, the HDD interface is displayed. See Figure 2.145. Fi gu r e 2. 14 5 Parameter Description Indicates the number of the currently conne cted HDD.
Page 147 Fi gu r e 2. 14 6 Device Status You can view fan running status such as speed, CPU temperature, and memory. Select M ain Menu → OPERATION → INFOMATION → Status, the Status interface is displaye d. See Figure 2.147. Fi gu r e 2.
Page 148 space, manufacturer, Serial No., and health status. Step1 Select Main Menu → OPERATION → INFOMATION → HDD Health Detection. The HDD Health Detection interface is display ed. See Figure 2.148. Fi gu r e 2. 14 8 Step2 Double-click the HDD in the list, system displays the detection report. Step3 Select an item in the list, system displays the corresponding report.
Page 149: N Etwo R
2.12.3. Network Online User You can view the online user information or block any user for a period of time. To block an online user, click and then enter the time that you want to block this user. The maximum value you can set is 65535. The system detects every 5 seconds to check whether there is any user added or deleted and update the user list timely.
Page 150 Fi gu r e 2. 15 0 Step2 Click the LAN name that you want to view, for example, LAN1. The system displays the information of data sending speed and receiving speed. • System displays LAN1 load by default. • Only one LAN load can be displayed at one time.
Page 151: Maintenance And Management
Network Test You can test the networ k connection status bet ween the Device and other devices. Step1 Select Main Menu → INFO → NETWORK → TEST . The TEST interface is displayed. See Figure 2.151. Fi gu r e 2. 15 1 Step2 In the Destination IP box, enter the IP address.
Page 152 Fi gu r e 2. 15 2 Step4 Configure the settings for the system maintenance parameters. Parameter Description Auto Reboot In the Auto Reboot list, select the reboot time. In the Case Fan Mode list, you can select Always run or Auto. If you select Auto, the case fan will stop or star t according Case Fan Mode external...
Page 153 is displayed. See Figure 2.153. Fi gu r e 2. 15 3 Step2 Insert a USB storage device into one of the USB ports on the Device. Step3 Click Refresh to refresh the interface. The connected USB storage device is displayed. See Figure 2.154. Fi gu r e 2.
Page 154 Default This function is for admin account only. You can select the settings that you wa nt to restore to the factory def ault. Step1 Select Main Menu → OPERATION → SYSTEM MAITAIN → DEFAULT. The DEFAULT interface is displayed. See Figure 2.155. Fi gu r e 2.
Page 155 Fi gu r e 2. 15 6 Step3 Click System Upgrade. The System Upgrade interface is displayed. See Figure 2.157. Fi gu r e 2. 15 7...
Page 156 Step4 Click the file that you want to upgrade. The selected f ile is displayed in the Update File box. Step5 Click Start. 2.12.4.5.2. Online Upgrade When the Device is connected to Internet, you can use online upgrade function to upgrade the system. Before using this function, you need to check whether there is any new version by auto check or manual check.
Page 157: F I L E B A C K U
2.12.4.5.3. Uboot Upgrading • Under the root directory in the USB storage device, there must be "u-boot.bin.img" file and "update.img" file saved, and the USB storage device must be in FAT32 format. • Make sure the USB storage device is inserted; otherwise the upgrading cannot be performed. When starting the Device, the system automatically checks whether there is a USB storage device connected and if there is any upgrade file, and if yes and the check result of the upgrade file is correct, the system will upgrade automatically.
Page 158: N E T W O R
Step3 Select backup device and then set channel, file start time and end time. Step4 Click Search button, system begins search. All matched files are listed below. System automatically calculates the capacity needed and remained. Step5 System only backup files with a √ before channel name. You can use Fn or cancel button to delete √ after file serial number.
Page 159 Parameter Description Multi -address: Two Ethernet ports work separately through e ither ⚫ of which you can request the Device to provide the services such as HTTP and RTSP. You need to conf igure a default Ethernet port (usua lly the Ethe rnet port 1 by default) to request the services from the device end such as DHCP, Email and FTP.
Page 160: Po R
Alternate DNS In the Alternate DNS box, enter the IP address of alternate DNS. In the MTU box, enter a value f or network card. T he value ranges from 1280 byte through 1500 byte. The default is 1500. The sugge sted MTU values are as below. 1500: The biggest value of Ethernet information package.
Page 161: Pppo
Parameter Description The allow able maximum clients accessing the Device at the same time, such as WE B, Platform, and Mobile Phone. Max Connection Select a value between 1 and 128. The default v alue setting is 128. The default value setting is 25001. You can enter the value TCP Port accor ding to y our actual situation.
Page 162: Ddn
Fi gu r e 2. 16 2 Step2 Enable the PPPoE function. Step3 In the Username box and Password box, enter the username and password accordingly provided by the Internet Service Provider. Step4 Click Apply to complete the settings. The system pops up a message to indicate the successfully saved. The IP address appears on the PPPoE interface. You can use this IP address to access the Device.
Page 163 Step1 Sele ct Main Menu → NETWORK → DDNS. The DDNS interface is displayed. See Figure 2.163. Fi gu r e 2. 16 3 Step2 Configure the settings f or the DDNS par ameters. Parameter Description Enable the D DNS function. Enable After enabling DDN S function, the third-party might collect your Device inf ormation.
Page 164: Upn
2.14.5. UPnP If the web interface of the Device is displaye d, the conf iguration is successful. If not, the conf igur ation is failed. You can map the relationship between the LAN and the WAN to access the Device on the LAN through the IP address on the WAN.
Page 165 Step2 Configure the settings for the UPnP parameters. Parameter Description Enable the UPnP function. Indicates the status of UPnP function. Status Offline: Failed. ⚫ Online: Succeeded. ⚫ Enter IP address of r out er on the LAN. LAN IP After mapping succee ded, the system obtains IP address automatically without performing any conf igur ations.
Page 166: Email
2.14.6. Email You can configure the email settings to enable the system to send the email as a notification when there is an alarm event occurs. Step1 Sele ct Main Menu → NETWORK → EMAIL. The EMAIL interface is displayed. See Figure 2.166. Fi gu r e 2.
Page 167 Title Enter the email subj ect. Supports E nglish and Arabic numerals. It s u p p o r t s maximum 64 char acters. Attachment Enable the attachment function. Whe n there is an alarm event, the system can attach snapshots as an attachment to the email.
Page 168 Configuration Steps Step1 Select Main Menu → NETWORK → SNMP. The SNMP interface is displayed. See Figur e 2.167. Fi gu r e 2. 16 7 Step2 Configure the settings for the SNMP parameters. Parameter Description Enable Enable the SNMP function. Select the check box of SNMP version(s) that you are using.
Page 169: Mult Ic A
Authentication Password Enter the password for authentication type and encryption type. The password should be no le ss than eight characters. Encryption Password In the Encryption Type list, select an encryption type. The Encryption Type default setting is CBC - DES. Step3 Compile the two MIB files by MIB Builder.
Page 170: Ala Rm C Ent
Parameter Description Enable Enable the multicast function. Enter the IP address that you want t o use as the IP Address multicast IP. address ranges from 224.0.0.0 throug h 239.255.255.255. Enter the port for the multicast. T he port ranges from Port 1025 through 65000.
Page 171: Regi St
Parameter Description Enable Enable the alarm center function. Protocol Type In Prot ocol Type list, select protocol type. T he default is ALARM CENTER. Host IP The IP address and communication port of the PC installed with alarm clie nt. Port Self-Report Time In the Self-Report Time list, select time cy cle and specific...
Page 172: In S T A
Port Enter the port of the server. Sub Service ID This ID is a llocated by the server and used f or the Device. Step 3 Click Apply to complete the settings. 2.14.11. INSTAON INSTAON is a kind of convenient private network penetration technology. You do not need to apply for dynamic domain name, doing port mapping or deploying transit server.
Page 173: Mobile App Operation
You can start adding the device – Cell Phone Client: Use your mobile phone to scan the QR code to add the device into the Cell Phone Client, and then you can start accessing the Device. Platform: Obtain the Device SN by scanning the QR code. Go to the INSTAON management platform and add the Device SN into the platform.
Page 174 e. Click the QR code icon behind the SN to enter the QR code scan interface. Scan the device label or scan the SN QR code got by selecting Main Menu → Network → INSTAON. When the scan is successful, the device SN will be displayed in the SN item. g.
Page 175: S T O R A G
Fi gu r e 2. 17 4 Step2 Select the Ethernet card you want to certify. Step3 Select Enable and configure parameters. Parameter Description PEAP: Protected EAP protocol. ⚫ Authentication TLS: Transport Layer Security. Provide privacy and data inte grity ⚫...
Page 176: Basic
2.15.1. Basic You can set basic storage parameters. Step1 Select Main Menu → STORAGE → BASIC. The Basic interface is displayed. See Figur e 2.175. Fi gu r e 2. 17 5 Step2 Set parameters. Parameter Description Configure the settings for the situation all the read/write discs are full, and there is no freer disc.
Page 177: Schedule
Step3 Click Apply or Sav e to complete setup. 2.15.2. Schedule You can set schedule record and schedule snapshot. NVR can record or snapshot as you specified. 2.15.3. You can view and sett HDD properties and format HDD. You can view current HDD type, status, capacity and etc. The operation includes format HDD, and change HDD property (read and write/read-only/redundancy).
Page 178 This function is for some series product only. The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD. There are two detect types: • Quick detect is to detect via the universal system files. System can quickly complete the HDD scan. If you want to use this function, make sure the HDD is in use now.
Page 179: Rai
After the detect operation, you can go to the detect report to view corresponding information. Replace the malfunction HDD in case there is data loss. Step1 Sele ct Main Menu → STORAGE → HDD DETECT → Detect Report. The Detect Report interface is displayed.
Page 180 Fi gu r e 2. 17 9 Step2 Click The Edit dialogue box is displayed. See Figure 2.180. You can configure the Resolution, Frame Rate, Bit Rate and Record Time for the selected channel. Fi gu r e 2. 18 0 Step3 Click Apply to save the settings.
Page 181: Calculating Hdd Capacity For Storage
Calculating Recordi ng Time Step1 On the REC ESTIMATE interface, click the Known Space tab. The Known Space interface is displayed. See Figure 2 .181. Fi gu r e 2. 18 1 Step2 Click Select . The Select HDD(s) interface is displaye d. Step 3 Select the check box of the HDD that you want to calculate.
Page 182 Step 2 In the Time box, enter the time period that you want to record. In the Capacity box, the required HDD capacity is displayed. You can store and view the recorded videos and snapshots on the FTP server. Preparations Purchase or download FTP (File Transfer Protocol) server and install it on your PC.
Page 183 FTP: The default is 21. ⚫ Port SFTP: The default is 22. ⚫ Anonymity Enter the user name and passw ord to login the FTP server. Enable anonymity function, and then Username login anonymously wit hout entering the use rname and password.
Page 184: S Y S T E
System 2.16.1. General You can set device general information. It includes device information, system date. 2.16.2. RS232 After setting RS-232 parameters, the NVR can use the COM port to connect to other device to debug and operate. Step1 Select MAIN MENU → SYSTEM → RS232. The RS232 interface is displayed. See Figure 2.185.
Page 185 Parameter Description Select serial port contr ol pr otocol. Console: Upgrade the program and debug with the console ⚫ and mini terminal software. ⚫ Keyboard: Control this Device with special key board. ⚫ Adapt er: Connect with directly transparent ⚫ transmission of data.
Page 186: S E C U R I T
Details to see the detailed risk description. • User Status: When one of device users or ONViF users uses weak password, the icon will be in orange to warn risk. You can click Details to optimize or ignore the risk warning.
Page 187 Fi gu r e 2. 18 7 • Configuration Security: When there’s a risk in the device configuration, the icon will be in orange to warn risk. You can click Details to see the detailed risk description. See Figure 2.188 and Figure 2.189.
Page 188: S Ys Tem S E R Vic
• Scanning Security Modules This area shows the running status of security modules. For details about the security modules, move mouse pointer on the icon to see the on-screen instructions. • Scanning Security Status You can click Rescan to scan security status. 2.17.2.
Page 189 Parameter Description After enabling this function, the alarm trigge red by the Mobile Push NVR can be pushe d to a mobile phone. This function is Notifications enabled by default. If this function is enabled, the remote devices can be added through the CGI protocol.
Page 190: Ca Certificate
Fi gu r e 2. 19 1 Step 2 Select the Ethernet card you want to certify. Step 3 Select Enable and configure parameters. Parameter Description • PEAP: protected EAP protocol. • TLS: Transport Layer Security. Provide pr ivacy and Authentication data integr ity...
Page 191 Fi gu r e 2. 19 2 Step 2 Enable HTTPS function. Step 3 (Optional) Enable Compatible with TLSv1.1 and earlier versions to allow protocol compatibility. Step 4 Click Certificate Management to create or import a HTTPS certificate from USB drive. For details about importing or creating a CA certificate, see "4.14.4 CA Certificate".
Page 192 Fi gu r e 2. 19 3 Step 2 Select Enable to enable firewall. Step 3 Configure the parameters. Parameter Description Mode can be conf igured when Type is Networ k Access. • If Trusted Sites is enabled, you can visit device port successfully with IP/MAC host s in Trusted Sites.
Page 193 Step 4 Click Apply to complete the settings. Account Lockout Step 1 Select Main Menu → SECURITY → Attack Defense → Account Lockout The Account Lockout interface is displayed. See Figure 2.194. Fi gu r e 2. 19 4 Step 2 Set Parameters. Parameter Description Set the maximum number of allowable wr ong passw ord...
Page 194 Step 3 Click Apply to complete the settings. Anti-DOS Attack You can enable SYN Flood Attack Defense and ICMP Flood Attack Defense to defend the device against Dos attack. See Figure 2.195. Fi gu r e 2. 19 5 Sync Time-Allowlist The synchronization is only allowed with hosts in the trusted list.
Page 195 Fi gu r e 2. 19 6 Step 2 Select Enable to enable Sync Time-Allowlist function. Step 3 Configure the parameters. Parameter Description You ca n add trusted hosts for time synchroniz ation. Type Select IP address or IP segment f or hosts to be added. Input the IP address of a trusted host.
Page 196 2.17.4. CA Certificate Device Certificate ➢ Create Certificate Step 1 Select Main Menu → SECURITY → CA Certificate → Device Certificate. The Device Certificate interface is displayed. See Figure 2.197. Fi gu r e 2. 19 7 Step 2 Configure Parameters. Parameter Description County...
Page 197: Audio / Vid Eo E Nc R Ypti
Trusted CA Certificate Step 1 Select Main Menu → SECURITY → CA Certificate → Trusted CA Certificate. Step 2 Click Install Trusted Certificate. The Create Certificate is displayed. See Figure 2.198. Fi gu r e 2. 19 8 Step 3 Click Browse to select the certificate that you want to install. Step 4 Click Import.
Page 198 Fi gu r e 2. 19 9 Step 2 Configure Parameters. Area Parameter Description Enable s stream frame encryption by using pr ivate protocol. Enable There might be safety risk if this service is disabled. Private Encryption Type Use the default setting. Protocol Secret key update per iod.
Page 199: Security Warning
Step 3 Click Apply to complete the settings. 2.17.6. Security Warning Security Exception Step 1 Select Main Menu → SECURITY → Security Warning → Security Exception. The Security Exception interface is displayed. See Figure 2.200. Fi gu r e 2. 20 0 Step 2 Select Enable and configure parameters.
Page 200 Check the box and the n select the corre sponding audio f ile Alarm Tone from the dr opdown list. Sy stem plays the audio file when the alarm occurs. Select the che ck box, the NVR device records the alarm information in the log when an alarm occurs.
Page 201 Fi gu r e 2. 20 1 Step 2 Select Enable and configure parameters. Parameter Description The alarm device ( such as lights, sirens, etc.) is connected to Alarm-out Port the alarm output port. When an alarm occur s, the NVR device transmits the alar m inf ormation to the alarm device.
Page 202: A C C O U N
Account You can manage users, user group and ONVIF user, set admin security questions. • For the username, the string max length is 31-byte, and for the user group, the string max length is 15-byte. The username can only contain English letters, numbers and “_”, “@”, “.”. •...
Page 203 Step2 Click Add User button in Figure 2.202. The Add User interface is displayed. See Figure 2.203. Fi gu r e 2. 20 3 Step3 Input the username, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user.
Page 204 Step4 Click OK button. Click to modify the corresponding user information, click to delete the user. Modify Password Step1 Select Main Menu → ACCOUNT → User, click of the corre sponding user. T he Modify User interface is displayed. See Figure 2.204. Fi gu r e 2.
Page 205: Group
Fi gu r e 2. 20 5 Step4 Click Bac k. 2.18.2. Group Step1 Select Main Menu → ACCOUNT → Group . The Group interface is displayed. See Figure 2.206. Fi gu r e 2. 20 6...
Page 206: Res Et P As S Wo
Step2 Click Add Group button in Figure 2.206. The Add Group interface is displayed. See Figur e 2.207. Step3 Enter group name and then input some memo information if necessary. Check the box to select authorities. Fi gu r e 2. 20 7 Step4 Click OK.
Page 207: On Vif U Se
Fi gu r e 2. 20 8 Step2 Check the box to enable Reset password function. This function is enabled by default. Step3 Input proper security questions and answers. Step4 Click OK, after you successfully set security questions, you can answer the security questions to reset admin password.
Page 208 Fi gu r e 2. 20 9 Step2 Click Add User button. The Add User interface is displayed. See Figur e 2.210. Fi gu r e 2. 21 0 Step3 Set username, password and then select group from the dropdown list. Step4 Click OK to complete setup.
Page 209: O U T P U T A N D D I S P L A
Output and Display 2.19.1. Display You can configure the display effect such as displaying time title and channel title, adjusting image transparency, and selecting the resolution. Step1 Select Main Menu → DISPLAY → Display. The Display interface is displayed. See Figure 2.211.
Page 210: Tou
Original Scale Click Setting and se lect the channel to restore the corresponding channe l image t o the original scale. Main Screen Select VGA+HDMI1 or HDMI2. Different devices display different contents. See the actual situation. Screen Enable Select the check box to enable this screen. The image can only be displayed when the screen is enabled.
Page 211: Cu Sto M Ized D Is Pla
On the top right of the live view screen, use the left mouse button or press Shift to switch, between (image switching is allowed) and (image switching is not allowed) to turn on/off the tour function. On the navigation bar, click enable the tour and click to disable it.
Page 212 Fi gu r e 2. 21 3 Step2 Click and then click to select basic mode. System adopts the basic window mode as the new window name. For example, if you select the 8-display mode, the default name is Split8. In regular mode, drag the mouse in the preview frame; you can merge several small windows to one window so that you can get you desired split mode.
Page 213 Fi gu r e 2. 21 4 Step3 Click Apply to exit. After the setup, you can go to the preview window, right click mouse and then select Custom Split. See Figure 2.215. Fi gu r e 2. 21 5...
Page 214: A U D I
Audio The audio function is to manage audio files and set schedule play function. It is to realize audio broadcast activation function. This function is for some series product only. 2.20.1. File Manage You can add audio files, listen to audio files, rename and delete audio files, and configure the audio volume. Step1 Select Main Menu →...
Page 215: Schedule
Fi gu r e 2. 21 7 Step3 Select the audio file and then click Import. System supports MP3 and PCM audio format. Step4 Click OK to start importing audio files from the USB storage device. If the importing is successful, the audio files will display in the File Manager interface. 2.20.2.
Page 216 Fi gu r e 2. 21 8 Step2 Configure the settings for the schedule parameters. Parameter Description Period In the Period box, ente r the time. Select the check box to enable the settings. You can conf igure up to six periods. File Na me In the File Name list, select the audio f ile that you want to play f or this configured period.
Page 217: B Ro Adc A
• The finish time for audio playing depends on audio file size and the configured interval. • Playing priority: Alarm event → Audio talk → Trial listening → Schedule audio file. Step3 Click Apply to complete the settings. 2.20.3. Broadcast System can br oadcast t o the camera, or broadcast to a channel group.
Page 218 The Add Group interface is displayed. See Figure 2.220. Fi gu r e 2. 22 0 Step3 Input group name and select one or more channels. Step4 Click Save button to complete broadcast group setup. • On the broadcast interface, click to change group setup, click to delete group.
Page 219: Usb Device Auto Pop-Up
Fi gu r e 2. 22 1 USB Device Auto Pop-up After you inserted the USB device, system can auto detect it and pop up the following dialogue box. It allows you to conveniently backup file, log, configuration or update system. See Figure 2.222. Fi gu r e 2.
Page 220: S H U T D O W
Shutdown • When you see corresponding dialogue box "System is shutting down…" Do not click power on-off button directly. • Do not unplug the power cable or click power on-off button to shutdown device directly when device is running (especially when it is recording.) •...
Page 221: Auto Re Sume After Po We R Fai Lu
Fi gu r e 2. 22 4 Fi gu r e 2. 22 5 • Remote Control Press the power button on the remote for at least 3 seconds. Press the power button at the rear panel of the device. 2.22.2.
Page 222: Web Ope Ra T Io
Web Operation • The interfaces in the Manual are used for introducing the operations and only for reference. The actual interface might be different dependent on the model you purchased. If there is inconsistency between the Manual and the actual product, the actual product shall govern. •...
Page 223: R E S E T P A S S W O R
Step2 Enter the username and password. • The default administrator account is admin. The password is the one that was configured during initial settings. To security your account, it is recommended to keep the password properly and change it regularly. •...
Page 224 Step 3 Click OK. The reset type interface is displayed. See Figure 3.3. Fi gu r e 3. 3 Step4 Follow the onscreen instructions to scan the QR code and get the security code. • You can get the security code twice by scanning the same QR code. If you need to get the security code once again, refresh the interface.
Page 225 Fi gu r e 3. 4 Step7 In the Password box, e nter the new password and enter it again in the Confirm Password box. The new password can be set from 8 characters through 32 characters and contains at least two types from number, letter and special characters (excluding"'", """, ";", ":"...
Page 226: Menu
Web Main Menu After you have logged in the Web, the main menu is displayed. See Figure 3.5. Fi gu r e 3. 5 Icon Description Includes configuration menu through which you can configure ⚫ camera settings, network settings, storage settings, system settings, account settings, and v iew inf ormation.
Page 227 Includes eight function tiles: LIVE, PLAYBACK, AI, ALARM, POS, OPERATION, BACKUP, DISPLAY, and AUDIO. Click each tile to open the conf igur ation interface of the tile. LIVE: You can perform the operations such as vie wing real -time video, ⚫...
Page 228: Gl Os S Ar
Glossary • DHCP: DHCP (Dynamic Host Configuration Protocol) is a network protocol. It is one of the TCP/IP protocol cluster. It is principally used to assign temporary IP addresses to computers on a network. • DDNS: DDNS (Dynamic Domain Name Server) is a service that maps Internet domain names to IP addresses. This service is useful to anyone who wants to operate a server (web server, mail server, ftp server and etc.) connected to the internet with a dynamic IP or to someone who wants to connect to an office computer or server from a remote location with software.
Page 229: A Ppe N D Ix 1 C Yb E R Se C Ur It Y Re C Om M E N D A Ti On
Appendix 1 Cybersecurity Recommendations Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks.
Page 230 9. Change Default HTTP and Other Service Ports a. We suggest you change default HTTP and other service ports into any set of numbers between 1024~65535, reducing the risk of outsiders being able to guess which ports you are using. 10.
Page 231 18. Construct a Saf e Netw ork E nvironment In order to better ensure the safety of equipment and reduce potential cyber risks, we recommend: a. Disable the port mapping function of the router to avoid direct access to the intranet devices from external network.
Page 232: A Ppe N D Ix 3 Compatible Ne Tw Or K C Am E Ra L I
Appendix 3 Compatible Network Camera List Please note all the models in the following list for reference only. For those products not included in the list, please contact your local retailer or technical supporting engineer for detailed information. Audio / Manufacture Model Version...
Page 233 H264 √ ONVIF CP-NS12W-CR cp20110808NS H264 √ ONVIF VS201 cp20111129NS H264 √ ONVIF CP-NB20-R cp20110808BNS H264 √ ONVIF CP PLUS CP-NT20VL3 -R cp20110808BNS H264 √ ONVIF CP-NS36W-AR cp20110808NS H264 √ ONVIF CP-ND20VL2 -R cp20110808BNS H264 √ ONVIF CP-RNP-1820 cp20120821NSA H264 √...
Page 234 － WV-SW352H H264、MPEG4 √ ONVIF/Private WV-SW152E 1.03 H264、MPEG4 √ ONVIF/Private － WV-SW558H H264、MPEG4 √ ONVIF/Private － WV-SW559H H264、MPEG4 √ ONVIF/Private WV-SP105H 1.03 H264、MPEG4 √ ONVIF/Private WV-SW155E 1.03 H264、MPEG4 √ ONVIF/Private WV-SF336H 1.44 √ ONVIF/Private H264、MPEG4 WV-SF332H 1.41 √ ONVIF/Private H264、MPEG4 WV-SF132E 1.03 √...
Page 235 SNC-CH260 1.74.01 H264 √ ONVIF/Private SNC-CH280 1.73.01 H264 √ ONVIF/Private SNC-RH-124 1.73.00 H264 √ ONVIF/Private SNC-RS46P 1.73.00 H264 √ ONVIF/Private SNC-ER550 1.74.01 H264 √ ONVIF/Private SNC-ER580 1.74.01 H264 √ ONVIF/Private SNC-ER580 1.78.00 H264 √ ONVIF SNC-VM631 1.4.0 H264 √ ONVIF WV-SP306 1.61.00 √...
Page 236 Thank You for Choosing CPPlus! Website: - www.cpplusworld.com Email id: - sales@cpplusworld.com; support@cpplusworld.com...

CP Plus ORANGE User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for CP Plus ORANGE

Summary of Contents for CP Plus ORANGE

Table of Contents
