Note: The actual play speed has relationship with the software version.
•
•
•
9 Time bar
•
•
In playback mode, click it to play the next or the previous section.
You can click continuously when you are watching the files from the
same channel. In normal play mode, when you pause current play,
│
you can click │ and
│ to begin frame by frame playback.
In frame by frame playback mode, click ►/
playback.
Slow play
In playback mode, click it to realize various slow play modes such as
slow play 1, slow play 2, and etc.
Fast forward
In playback mode, click to realize various fast play modes such as
fast play 1, fast play 2 and etc.
Smart search
The volume of the playback
Click the snapshot button in the full-screen mode, the system can
snapshot 1 picture.
System supports custom snap picture saved path. Please connect
the peripheral device first, click snap button on the full-screen
mode, you
snapshot picture can be
saved to the specified path.
Mark button.
Please note this function is for some series product only. Please
make sure there is a mark button in the playback control pane.
You can refer to chapter 2.10.1.3 for detailed information.
It is to display the record type and its period in current search criteria.
In 4-window playback mode, there are corresponding four-time bars. In
another playback mode, there is only one time bar.
Use the mouse to click one point of the color zone in the time bar,
system begins playback.
The time bar is beginning with 0 o'clock when you are setting the
configuration. The time bar zooms in the period of the current playback
time when you are playing the file.
The green color stands for the regular record file. The red color stands
for the
external alarm record file. The yellow stands for the motion detect record
file.
can select or create path. Click Start button, the
to restore normal
40
