Parameter
Remote Directory
File Length(M)
Image Upload Interval
(Sec.)
Channel
Week Day
Period 1, Period 2
Record type
•
Click Test.
The system pops up a message to indicate success or failure. If failed, please check the
network connection or configurations.
•
Click Apply to complete the settings.
2.14.3.5 Record
2.14.3.5.1 Record
Control Note:
You need to have proper rights to implement the following operations. Please make sure the
Description
Create folder on FTP server.
If you do not enter the name of remote directory, system
automatically creates the folders according to the IP and time.
If you enter the name of remote directory, the system creates the
folder with the entered name under the FTP root directory first,
and
then automatically creates the folders according to the IP and
time.
Enter the length of the uploaded recorded video.
If the entered length is less than the recorded video length, only a
section of the recorded video can be uploaded.
If the entered length is more than the recorded video length, the
whole recorded video can be uploaded.
If the entered length is 0, the whole recorded video will be
uploaded.
If this interval is longer than snapshot interval, the system takes
the recent snapshot to upload. For example, the interval is 5
seconds, and snapshot interval is 2 seconds per snapshot, the
system uploads the recent snapshot every 5 seconds.
If this interval is shorter than snapshot interval, the system
uploads the snapshot per the snapshot interval. For example, the
interval is 5 seconds, and snapshot interval is 10 seconds per
snapshot, the system uploads the snapshot every 10 seconds.
To configure the snapshot interval, select Main Menu
Encode Snapshot.
Select the channel that you want to apply the FTP settings.
Select the week day and set the time period that you want to
upload
the recorded files. You can set two periods for each week day.
Select the record type (Alarm, Intel, MD, and General) that you
want to upload. The selected record type will be uploaded during
the
configured time period.
