UG-1673
Qty Reference Designator
1 U9
1 Y1
1 Y2
1 Y3
Table 8. Not Populated
Qty Reference Designator
15 12V_FPGA, GND1, GND3,
GND5, GPCLK, INT_N,
LDO_CAP, LED_0, LINK_ST,
MDC, MDIO, P9, P10, P11,
SUPPLY
5 C5, C6, C18, C55, C92
4 C33, C45, C91, C99
1 J1
8 R49, R65, R67, R95, R97, R101,
R111, R120
4 R138 to R141
1 R19
12 R8, R9, R22, R23, R27 to R32,
R37, R38
1 R85
1 SHIELD
Description
IC, ultralow power Arm® Cortex-M3
micro-controller with integrated power
management and 256 kB of embedded
flash memory
Crystal, 25 MHz, 10 ppm, 10 pF load
capacitor
Crystal, 32.768 kHz, 20 ppm, 6 pF load
capacitor
Crystal, 26 MHz, 30 ppm, 0 pF load
capacitor
Description
Test point, do not insert
Capacitor, 0.1 μF, 16 V, 10 %, C0402, X7R
Capacitor, 0.01 µF, 25 V, 10%, 0402, X7R
PCB connector, straight SubMiniature
Version A (SMA)
Resistor, 0 Ω, 50 V, 1%, 0402
Resistor, 0 Ω, R0805
Resistor, 1 MΩ, 1%, 0402
Resistor, 10 kΩ, 1%, 0603
Resistor 10 Ω, 1%, R0402
PCB connector, 4 mm socket
Rev. 0 | Page 28 of 29
EVAL-ADIN1200FMCZ
Supplier Device Number
ADUCM3029BCPZ Analog Devices
FA- Seiko Epson
128_25.000000MHZ_
10.0_+10-10
ABS07-120- Abracon Corp.
32.768KHZ-T
ECS-260-10-36Q-ES- ECS, INC.
TR
Supplier Device Number
1405-2 Keystone Electronics
530L104KT16T American Technical
Ceramics
TDK C1005X7R1E103K050EB
TE Connectivity LTD 5-1814832-1
Multicomp (SPC) MC00625W040210R
Multicomp (SPC) MC 0.1W 0805 0R
Panasonic ERJ-2RKF1004X
Multicomp (SPC) MC0063W0603110K
Multicomp (SPC) MC00625W0402110R
Rapid 20054
