Chapter 4 – Chapter 4 Antennas

Antenna System Cellular Devices

The antenna system is defined as the UFL connection point from the device through the cable and antenna. Device
performance depends on implementation and antenna system design. Integrating the antenna system is a critical
part of the design process; therefore, it is essential to consider it early so the performance is not compromised.

Requirements for Cellular Antennas with regard to FCC/IC Compliance

The antenna must be the same type, with similar performance and in- and out-of-band radiation patterns as the
listed antenna. The antenna used must stay below the FCC/IC maximum gain.
For our bundles, MultiTech may change antennas over time. The listed antenna(s) is used as a reference or was
shipping when this document was last updated.

LTE Antenna Information

The cellular radio portion of the device is approved with the following antenna or for alternate antennas meeting
the given specifications.
Manufacturer:
Description:
Model Number:
MultiTech Part Number:
MultiTech ordering information:
Model
ANLTE3-2HRA
ANLTE3-10HRA
ANLTE3-50HRA

Antenna Specifications

Category
Frequency Range
Power Rating
VSWR
Gain
Radiating Element
Polarization
®
SocketModem Cell MTSMC-LVW3 Device Guide
EAD Ltd.
LTE Antenna with SMA-Male Connector
WTR7270
45009760L
Quantity
2
10
50
Description
690-960 MHz
1710-2700 MHz
10 W
< 2.0:1
1 dBi
1/2 wave element
Linear
CHAPTER 4 ANTENNAS
