Clas Ohlson NS-600B-EW Manual

600 W Infrared Heater
Art.no 18-1364 Model NS-600B-EW
36-6558 NS-600B-EW
Please read the entire instruction manual before using the product and
then save it for future reference. We reserve the right for any errors in
text or images and any necessary changes made to technical data.
In the event of technical problems or other queries, please contact our
Customer Services.
Safety
Warning:
• This product may only be used outdoors in dry weather and never
left unattended.
• Take the product indoors in the event of rain and after use.
• The product can become very hot during use and cause burns.
Special care must be taken if the product is used in the same room
as young children, aged or infirm persons.
• Never cover the product, doing so could cause overheating and fire.
• The product has no thermostat function to control the room
temperature. Never use the product in spaces which are too small
or premises containing persons incapable of leaving the premises
themselves unless the product can be supervised continuously.
• The product may be used by children of 8 years and above and
by persons with reduced physical, sensory or mental capability or
lack of experience and knowledge provided they have been given
supervision or instruction concerning use of the product in a safe
way and understand the hazards involved.
• Never let children play with the product.
• Cleaning and user maintenance shall not be made by children
without supervision.
• The appliance must be kept out of reach of children under 3 years
of age unless they are under constant supervision.
• Children between the ages of 3 and 8 years must only switch
the appliance on/off provided that it has been placed or installed
in its intended normal operating position and they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
• Children between the ages of 3 and 8 years must not plug in,
regulate and clean the appliance or perform user maintenance.
• The product must only be connected to a standard domestic
230 V, 50 Hz electrical supply.
• The product must only be used as described in this instruction manual.
• The product should never be connected using an on/off timer or
other equipment which can automatically switch the appliance on.
• Never mount the product immediately in front of or below a mains
outlet.
GREAT BRITAIN • customer service tel: 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
• If the mains lead is damaged it must only be replaced by a qualified
electrician.
• Never use the product if your hands are moist or wet.
• Never try to open the housing, repair or modify the product in any way.
• Repairs must only be carried out by qualified electricians and only
using genuine spare parts.
• Never use the product where it risks being exposed to moisture or
splashed by water or any other types of liquids.
• Never position the product where it is exposed to rain or snow.
• Never place the product in a shower or bathroom or in such as way
that it can fall down into water or other liquid.
• Never leave the product unattended when it is connected to
the power supply. Always unplug the product from the power point
when it is not in use.
• Never insert foreign objects through the safety grille or housing.
Doing so could result in an electric shock.
• Never use the product in areas where explosive or flammable gases
or liquids are stored.
• Do not leave the product in direct sunlight for long periods.
• The product must only be placed on a firm, flat surface.
•
Place the product at least 1 m away from combustible materials.
• Do not subject the product to impacts or shocks and do not
expose it to extremely hot, cold or dusty environments.
Product description
1. Mode selector
1
2. 600 W with
oscillation
3. 1 600 W
2
4. 0 OFF
3
4
Operating instructions
Warning:
• The infrared heater can become very hot during use and
cause burns. Special care must be taken if the heater is used in
the same room as young children, aged or infirm persons.
• Never cover the heater, doing so could cause overheating and fire.
• The heater has no thermostat function to control the room
temperature. Never use the heater in spaces which are too small
or premises containing persons incapable of leaving the premises
themselves unless the heater can be supervised continuously.
1. Place the heater on a level surface and plug it into a power point.
2. Set the mode selector to one of the operating modes:
- 600 W with oscillation
- 1 600 W
- 0 OFF
Note:
The heater is fitted with a tip-over switch which switches the heater off
if it falls over. The heater will then switch on again automatically once it
has been stood back up.
Care and maintenance
• Always unplug the lead from the power point and let the product
cool down before cleaning or moving it.
• Clean the product using a lightly moistened cloth. Use only mild
cleaning agents, never solvents or corrosive chemicals.
• Unplug the mains lead from the wall socket and store the product
in a dry, dust-free environment out of the reach of children
whenever it is not to be used for an extended period.
Responsible disposal
This symbol indicates that this product should not be
disposed of with general household waste. This applies
throughout the entire EU. In order to prevent any
harm to the environment or health hazards caused by
incorrect waste disposal, the product must be handed
in for recycling so that the material can be disposed of
in a responsible manner. When recycling your product,
take it to your local collection facility or contact
the place of purchase. They will ensure that the product
is disposed of in an environmentally sound manner.
Specifications
Rated voltage 220–240 V AC, 50/60 Hz
600 W
Power
55 cm
Height
This product is only suitable for well insulated spaces
or occasional use.
