U-Line DYMO Quick Start Manual

π
H-3677
DYMO POSTAL SCALE
®
INSTALLATION
The scale is powered through a USB port on your
computer. (See Figure 1) When not connected to your
computer, the scale can be powered by 3 AAA batteries.
Figure 1
Power
Zero/
Tare
LCD
display
1. Unpack the scale.
2. Set the scale on a firm, flat surface.
3. Plug the USB cable into the USB port on the back of
the scale. (See Figure 2)
Figure 2
4. Plug the USB cable into an available USB port on
your computer.
The scale is automatically recognized by your computer
when the power is turned on.
NOTE: When connecting the scale through a
USB hub, always use a powered hub.
PAGE 1 OF 3
1-800-295-5510
uline.com
USB port
Kg/Lb
Hold
LED
SETUP
INSERTING THE BATTERIES
NOTE: When not connected to your computer,
the scale can be powered by 3 AAA alkaline
batteries. The scale automatically turns off
after three minutes of inactivity.
Figure 3
CAUTION! Make sure to insert the batteries
correctly. Inserting the batteries backwards
can damage the scale.
5. Replace battery compartment cover.
NOTE: Remove the batteries if the scale will not
be used for a long period of time.
PREPARING TO USE THE SCALE
With proper care and handling, your scale will give you
years of service. Keep the following in mind when using
your scale:
• Your scale works best when operated and stored at
normal room temperature. Avoid lengthy exposure
to extreme heat or cold.
• Only operate the scale on a stable, vibration-free
surface.
TO INSERT BATTERIES:
1. Disconnect the USB
cable from the
computer or USB hub.
2. Turn the scale over.
3. Remove the battery
compartment cover.
4. Insert three AAA
batteries as shown.
(See Figure 3)
0415 IH-3677
