Summary of Contents for Badger Meter ER-9
- Page 1 Digital Resettable Totalizer and Installation & Model ER-9 Digital Rate of Flow Indicator Operation Manual with Pulse Output ER9-IOM-01 BadgerMeter,Inc. 12-01 ®...
-
Page 2: Scope Of This Manual
General Information The ER-9 is an external or battery powered indicator that displays rate Powered by two replaceable 3V Lithium batteries, this unique design of flow and total flow. It also has a scalable pulse output. It has... -
Page 3: Installation
MSE1 Black (1) Red (2) tions" refers to the wires on the transmitter. The numbers in parenthe- sis refer to the terminal numbers on the ER-9. Connect the wire coming MSE5 Black (1) Red (2) from the transmitter to the corresponding terminal number on the ER-... -
Page 4: Operation
Operation By pressing the DOWN key during normal operation, the ER-9 will alternatively display the Flow Total or the Flow Rate. The Letter R on the left indicates that the Flow Rate is being displayed. Total Display: Indicates the present... -
Page 5: Totalizer Programming
ER9 Programming Calculations TOTALIZER PROGRAMMING that has a pulse output of 126.7 pulses per gallon. You wish to read rate of flow in gallons per minute. Totalizer values can be expressed in any engineering unit of measure such as gallons, quarts, liters, etc. For each unit a unique scale factor 60 seconds /126.7 pulses per gallon X 1 must be programmed. -
Page 6: Troubleshooting
1. Check programming. 2. Defective transmitter. 2. Repair or replace transmitter. No Pulse Output 1. Defective output Transistor 1. Replace ER-9 2. Improper wiring 2. Check connections For further assistance, call our Technical Support Staff at 414-355-0400, Extension 637. Field Calibration... - Page 7 4. Replace pickup and pad in adapter, feeding wires up through the TURBO METER drop pipe. 1. Remove the front cover on the ER-8 or ER-9 unit and disconnect 5. Reposition entire assembly on meter. all wiring. 6. Rewire sensor to ER-8/9 unit.
- Page 8 Please see our website at www.badgermeter.com BadgerMeter,Inc. for specific contacts. P.O. Box 245036, Milwaukee, WI 53224-9536 (800) 876-3837 / Fax: (888) 371-5982 www.badgermeter.com Copyright © Badger Meter, Inc. 2001. All rights reserved, all data subject to change without notice. ®...
