- Page 1 Model EPM Installation & Operation Manual Electronic Preset Meter - Advanced Series IMPORTANT !!!! This manual contains important warnings and information. READ AND KEEP FOR REFERENCE. Bulletin No. IOM-079-01 BadgerMeter,Inc. Part No. 53400-079 February 2001 ®...
-
Page 2: Table Of Contents
12.Do NOT dispense valves towards any person or any TABLE OF CONTENTS part of the body. 13.Do NOT place hands or fingers over the end of or into Definitions ..............2 the dispense valve. Installation ..............3 14.Comply with all local, state, and federal fire, electrical, Operating the Meter ............ -
Page 3: Installation
Note: The threaded end of the meter will always have Installation female threads, so the metal end of the hose must Pre-Installation Procedure have male threads. Apply thread sealant to the male 1. Relieve the system pressure: end. The inlet and outlet connections are both 1/2" a. -
Page 4: Programming The Meter
Programming the Preset Batch Function a. Press the button to toggle between the two 1. To enter the batch-programming mode, press and hold options, count up or count down. Press the button until the digit and colon appear next to button to select either count up or count down AUTO (approx. -
Page 5: Operational Functions
Batch (Auto) Mode Flow Rate 1. Program the meter to auto mode using option 1-6 in This option allows the user to see the instantaneous rate the batch-programming mode. (See Programming the at which oil is flowing through the meter. Batch Function) While oil is flowing through the meter, press and hold the 2. -
Page 6: Service
Changing Factory Settings Mechanical Override In case of an emergency or to interrupt a batch, the meter is equipped with a mechanical override. This option Factory Settings automatically closes the valve in the meter, stopping the Each meter is preprogrammed and calibrated at the flow immediately. - Page 7 Recalibrating the Meter The Scale factor is used to adjust the accuracy of the meter. The scale factor will be set at the factory for oil. The primary use for the recalibration function is if the user wants to batch fluids with a viscosity other than 10W oil. If the fluid has a lower viscosity, more fluid can slip past the gears without being detected.
-
Page 8: Dimensional Drawing
11.00" 3.50" 6.00" SPECIFICATIONS English Metric Maximum Flow * 8 gpm 30 lpm Minimum Flow * 0.25 gpm 1 lpm Operating Pressure (Maximum) 1000 psi 67 bar Operating Pressure (Minimum) 5 psi .35 bar Operating Temperature (Maximum) 120° F 50° C Operating Temperature (Minimum) 20°... -
Page 9: Parts Drawing
ITEM # PART DESCRIPTION PART NUMBER Top Case with Screws 64103-002 Keypad 63802-001 PCB Assembly, Non-Approved with Screws 64103-001 Bare Meter, NPT 63897-001 Bare Meter, BSPP 63897-002... - Page 10 ITEM # PART DESCRIPTION PART NUMBER Battery Door with Screws 64103-004 Bottom Case with Screws 64103-003 Detent Ball 63841-001 Solenoid 63879-001 O-Ring, Battery Door 55300-043 O-Ring, Battery Compartment Screw 55300-006...
- Page 11 ITEM # PART DESCRIPTION PART NUMBER Valve Assembly 63997-001 Screw, Sems Type 63253-001 Housing Cover 63810-001 O-Ring 55300-035 Gear Service Kit with O-Ring 62896-001 Trigger Assembly 64103-005...
- Page 12 Due to continuous research, product improvements and BadgerMeter,Inc. enhancements, Badger Meter reserves the right to change product or system specifications without notice, except to the P.O. Box 245036 Milwaukee, WI 53224-9536 extent that an outstanding bid obligation exists. Telephone: (414) 355-0400 Copyright©...
