4 Terminal Configuration and Functions

4.1

CC3135MOD Pin Diagram

Figure 4-1 shows the pin diagram for the CC3135MOD module.
GND
FLASH_SPI_CLK
FLASH_SPI_nCS_IN
FLASH_SPI_MISO
DIO23
HOST_INTR
DIO13
DIO14
HOST_SPI_nCS
HOST_SPI_DOUT
HOST_SPI_DIN
HOST_SPI_CLK
nHIB
DIO10
GND
GND
NOTE: Figure 4-1 shows the approximate location of pins on the module.
