5.11 WLAN Transmitter Characteristics

Table 5-4. WLAN Transmitter Characteristics: 2.4 GHz Band
T = 25°C, V = 2.3 V to 3.6 V.
A BAT
PARAMETER
(4) (5)
Operating frequency range
Maximum RMS output power measured at 1
dB from IEEE spectral mask or EVM
Transmit center frequency accuracy
(1) Transmit power will be reduced by 1.5dB for V
(2) The 11g/n low rates on edge channels (2412 and 2462 MHz) have reduced TX power to meet FCC emission limits.
(3) Power of 802.11b rates are reduced to meet ETSI requirements in Europe.
(4) Channels 1 (2142 MHz) through 11 (2462 MHz) are supported for FCC.
(5) Channels 1 (2142 MHz) through 13 (2472MHz) are supported for Europe and Japan. Note that channel 14 is not supported for Japan.
T = 25°C, V = 2.3 V to 3.6 V.
A BAT
PARAMETER
(4) (5) (6)
Operating frequency range
Maximum RMS output power measured at 1
dB from IEEE spectral mask or EVM
Transmit center frequency accuracy
(1) Transmit power will be reduced by 1.5dB for V
(2) FCC channels 36, 60, 64, 100, and 140, where harmonics/sub-harmonics of fall in the FCC restricted band, have reduced output power
to meet the FCC RSE requirement.
(3) The edge channels (100 and 140) have reduced TX power to meet FCC emissions limits.
(4) FCC band covers U-NII-1, U-NII-2A, U-NII-2C, and U-NII-3 20-MHz BW modulations.
(5) Europe bands 1, 2 and 3, 20-MHz BW modulations are supported.
(6) For Japan, W52, W53 and W56, 20-MHz BW modulations are supported.
Copyright © 2019–2020, Texas Instruments Incorporated
(1)
Parameters measured at SoC pin on channel 6 (2437 MHz).
TEST CONDITIONS
1 DSSS
2 DSSS
11 CCK
6 OFDM
9 OFDM
18 OFDM
36 OFDM
54 OFDM
MCS7
< 2.8V
BAT
Table 5-5. WLAN Transmitter Characteristics: 5 GHz Band
(1)
Parameters measured at SoC pin are the average of channels 40, 56, 120, and 157 .
TEST CONDITIONS
6 OFDM
9 OFDM
18 OFDM
36 OFDM
54 OFDM
MCS7
< 2.8V
BAT
Submit Documentation Feedback
Product Folder Links:
SWRS225B – FEBRUARY 2019 – REVISED MARCH 2020
MIN TYP
2412
16.3
15.3
15.3
12.5
–25
MIN TYP
5180
15.1
15.1
15.1
13.6
-20
CC3135MOD
CC3135MOD
(2) (3)
MAX UNIT
2472 MHz
16
16
dBm
15
14
11
25 ppm
(2) (3)
MAX UNIT
5825 MHz
dBm
12
11
20 ppm
Specifications 25
