Table 7-1 lists the bill of materials for a typical application using the CC3135MOD module shown in
Figure 7-3.
QTY PART VALUE
REFERENCE
2 C1, C2 0.1 uF
1 C3 3.3 pF
2 C4, C5 100 uF
1 E1 2.4 GHz, 5 GHz
Ant
1 L1 3 nH
1 R1 10k
1 CC1 CC3135MOD
Copyright © 2019–2020, Texas Instruments Incorporated
Table 7-1. Bill of Materials
MANUFACTURER PART NUMBER
Murata GRM155R61A104KA01D
Murata GJM1555C1H3R3BB01
Murata LMK325ABJ107MMHT
Ethertronics M830520
Murata LQG15HS3N0S02D
Vishay-Dale CRCW040210K0JNED
Texas Instruments CC3135MODRNMMOBR
Submit Documentation Feedback
Product Folder Links: CC3135MOD
SWRS225B – FEBRUARY 2019 – REVISED MARCH 2020
DESCRIPTION
Capacitor, ceramic, 0.1 uF, 10 V,
±10%, X5R, 0402
Capacitor, ceramic, 3.3 pF, 50 V,
±0.1pF, C0G/NP0, 0402
Capacitor, ceramic, 100 uF, 10 V,
±20%, X5R, AEC-Q200 Grade 3,
1210
Antenna Bluetooth WLAN Zigbee®
Inductor, Unshielded, Multilayer, 3nH,
0.8 A, 0.125 Ω, SMD
RES, 10 k, 5%, 0.063 W, AEC-Q200
Grade 0, 0402
SimpleLink™ Certified Wi-Fi® Dual-
Band Network Processor Internet-of-
Things Module Solution for MCU
Applications, MOB0063A
